| Product Type | Countertop Ice Machine |
| Brand | Aroma |
| Model | AIC-224B |
| Ice Production Capacity | 26 lbs per 24 hours |
| Ice Storage Capacity | 1.5 lbs |
| Ice Cube Size Options | Small and Large |
| Dimensions (W x D x H) | 10.0 x 12.0 x 14.0 inches |
| Weight | 21.0 lbs |
| Power Supply | 120V AC, 60Hz, 150W |
| Refrigerant Type | R600a |
| Control Type | Touch Button Panel with LED Display |
| Self-Cleaning Function | Yes |
| Automatic Shut-off | When bin full or water level low |
| Material | Stainless Steel exterior, ABS interior |
| Noise Level | < 45 dB |
| Water Reservoir Capacity | 2.1 L |
| Cycle Time | Approximately 6-8 minutes per batch |
| Maintenance | Regular cleaning with vinegar solution; descaling recommended |
| Safety Features | Overheat protection, low water indicator |
| Warranty | 1 year limited |
| Included Accessories | Ice scoop, instruction manual |
Frequently Asked Questions - AIC-224B Aroma
How do I clean the Aroma AIC-224B ice machine?
Unplug the unit, remove the ice basket, and wash all removable parts with warm soapy water. For the interior, use a mixture of white vinegar and water (1:1) to descale and sanitize. Rinse thoroughly before next use.
Why is the ice machine not making ice?
Common causes include: low water level, unit not level, ambient temperature too high (above 90°F), or the ice bin is full. Check the water reservoir, ensure proper placement, and wait for the compressor to cool down if overheated.
How long does it take to make ice?
The first batch typically takes 6-8 minutes, but subsequent batches may be faster. Full ice production capacity is reached after 24 hours of continuous operation.
Can I use the ice machine continuously?
Yes, the AIC-224B is designed for continuous use. However, allow the compressor to rest occasionally by turning off the unit for 30 minutes after 12 hours of operation to prolong lifespan.
What type of water should I use?
Use clean, potable tap water. Avoid distilled or highly purified water as it may affect ice clarity and taste. If your tap water is hard, consider using filtered water to reduce mineral buildup.
How do I select ice cube size?
Press the 'Size' button on the control panel to toggle between Small and Large cubes. The LED indicator shows the selected size.
The ice machine is making unusual noise. What should I do?
Normal operation includes a low hum from the compressor and a clicking sound when ice drops. If noise is excessive, ensure the unit is on a level, hard surface. Also, check for loose parts or debris in the ice basket.
Is the AIC-224B energy efficient?
Yes, it uses 150W of power and features an automatic shut-off when the bin is full or water level is low, reducing unnecessary energy consumption.
How often should I descale the machine?
Descaling every 1-2 months is recommended, depending on water hardness. Use a commercial ice machine descaler or a vinegar solution. Follow the self-cleaning cycle after descaling.
What do the indicator lights mean?
The 'Power' light indicates the unit is on. 'Add Water' flashes when the reservoir is low. 'Ice Full' lights up when the basket is full. 'Clean' reminds you to run the self-cleaning cycle.
User questions about AIC-224B Aroma
0 question about this device. Answer the ones you know or ask your own.
Ask a new question about this device
No questions yet. Be the first to ask one.
Download the instructions for your Ice machine in PDF format for free! Find your manual AIC-224B - Aroma and take your electronic device back in hand. On this page are published all the documents necessary for the use of your device. AIC-224B by Aroma.
USER MANUAL AIC-224B Aroma
Bienvenida
Technical diagram of a mechanical device with labeled parts including a cylindrical container, a threaded rod, and a multi-compartment container.natural_image
Cross-sectional diagram of an internal combustion engine cylinder (no text or labels)Dibujo 1
