BEO 1440 - Cooker BLOMBERG - Free user manual and instructions

Product Type	Freestanding Cooker
Brand	Blomberg
Model	BEO 1440
Energy Source	Electric
Oven Type	Conventional (without turbo)
Oven Power	2400 W
Grill Power	1100 / 2300 W (dual)
Interior Light	15 W / 25 W
Hob Type	Electric Ceramic (4 zones)
Number of Cooking Zones	4
External Dimensions (HxWxD)	595 x 594 x 550 mm
Installation Dimensions (HxWxD)	600 x 600 x 560 mm
Voltage / Frequency	230 V / 50 Hz
Power Cord	1.5 m (typical)
Child Lock	Yes (control panel lock)
Oven Functions	Conventional, Grill, Fan-assisted (if applicable)
Cleaning Type	Standard enamel interior
Safety Features	Overheat protection, residual heat indicator
Clock / Timer	Digital clock with minute minder
Weight	Approx. 50 kg

Frequently Asked Questions - BEO 1440 BLOMBERG

How do I install the Blomberg BEO 1440 cooker?

Ensure the cooker is placed on a stable, level surface with proper ventilation. Connect to a 230V/50Hz power supply via a dedicated circuit. The installation dimensions are 600 mm width, 560 mm depth, and 600 mm height. For electrical connection, the brown wire is live (L), blue is neutral (N), and green/yellow is earth (E). Consult a qualified electrician.

What are the oven functions available on the BEO 1440?

The oven offers conventional heating (top and bottom), grill mode (dual power 1100/2300 W), and possibly a fan-assisted option if turbo is available. However, this model lacks a turbo motor, so convection is not forced.

How do I use the hob?

The hob has four electric ceramic zones. Turn the corresponding knob to the desired heat level. The residual heat indicator lights up when the zone is hot. Do not touch until it cools down.

How do I set the clock?

Press the clock button (or timer) and use the +/- buttons to set the time. The exact procedure may vary; refer to the manual for your specific model. The clock helps with timed cooking.

How do I clean the oven?

Allow the oven to cool. Remove racks and trays. Wipe the interior with a damp cloth and mild detergent. Avoid abrasive cleaners. The oven has an enamel interior that can be cleaned with standard oven cleaners.

What safety features does the BEO 1440 have?

It includes overheat protection, residual heat indicators on the hob, and a child lock to prevent accidental operation. Always supervise children near the appliance.

Why is my oven not heating?

Check the power supply and circuit breaker. Ensure the oven function selector and thermostat are set correctly. If it still doesn't heat, the heating element may be faulty. Contact a service technician.

Can I use aluminum foil in the oven?

Yes, but avoid covering the bottom of the oven or blocking air circulation. Use foil only on trays and keep it away from heating elements to prevent fire hazard.

How do I replace the oven light?

Disconnect the power. Remove the lamp cover (usually by unscrewing or prying). Replace with a 15W or 25W compatible bulb (typically E14 base). Reattach the cover and restore power.

Where can I find spare parts for the BEO 1440?

Contact Blomberg customer service or authorized dealers. Common spare parts include heating elements, knobs, oven door hinges, and lamps. Provide your model number for accurate parts.

USER MANUAL BEO 1440 BLOMBERG

* Braunes Kabel = L (Phase)

Simple diagram showing a curved arrow pointing downward from a rectangular block (no text or symbols)

Interior view of a microwave oven with tray and vent (no visible text or symbols)

BEO 1440

ovendeur opent, wees

	BEO 1570	BEO 1430	BEO 1410	BEO 1101
	BEO 1540		BEO 1011
	BEO 1450		BEO 1411
	BEO 1440
	BEO 1021
Wattverbruik van de grill	1100/2300	1100/2300	1100/2300	1100/2300
Wattverbruik van de oven	3200 W	2500 W	2500 W	2400 W
Wattverbruik van de turbo	1800 W	1800 W	-	-
Turbomotor	+	+	+	-
Lamp	15 W/ 25 W	15 W/ 25 W	15 W/ 25 W	15 W/ 25 W
Externe afmetingen	H: 595 mm	H: 595 mm	H: 595 mm	H: 595 mm
	W: 594 mm	W: 594 mm	W: 594 mm	W: 594 mm
	D: 550 mm	D: 550 mm	D: 550 mm	D: 550 mm
Afmetingen van de installatie-instelling	W: 600 mm	W: 600 mm	W: 600 mm	W: 600 mm
	D: 560 mm	D: 560 mm	D: 560 mm	D: 560 mm
	H: 600 mm	H: 600 mm	H: 600 mm	H: 600 mm

Simple diagram showing a curved arrow pointing to a horizontal bar with a small loop at the end (no text or symbols)

Simple diagram showing a curved arrow pointing to a horizontal bar with a small protrusion at the bottom (no text or symbols)

* Câble Marron = L (Live) * Câble Bleu = N (Neutre) * Câble Vert/Jaune = E (Terre)

	BE0 1570BE0 1540BE0 1450BE0 1440BE0 1021	BE0 1430	BE0 1410BE0 1011BE0 1411	BE0 1101
Puissance du grill en Watts	1100/2300	1100/2300	1100/2300	1100/2300
Puissance du four en Watts	3200 W	2500 W	2500 W	2400 W
Puissance turbo en Watts	1800 W	1800 W	-	-
Moteur turbo	+	+	+	-
Lampe	15 W/ 25 W	15 W/ 25 W	15 W/ 25 W	15 W/ 25 W
Dimensions externes	H: 595 mmW: 594 mmD: 550 mm	H: 595 mmW: 594 mmD: 550 mm	H: 595 mmW: 594 mmD: 550 mm	H: 595 mmW: 594 mmD: 550 mm
Cotes de mesures d'installation	W: 600 mmD: 560 mmH: 600 mm	W: 600 mmD: 560 mmH: 600 mm	W: 600 mmD: 560 mmH: 600 mm	W: 600 mmD: 560 mmH: 600 mm

Mise à l'heure :
