BEO 1101 - Cooker BLOMBERG - Free user manual and instructions

Product Type	Freestanding Cooker
Brand	Blomberg
Model	BEO 1101
External Dimensions (H x W x D)	595 x 594 x 550 mm
Installation Dimensions (W x D x H)	600 x 560 x 600 mm
Oven Power	3200 W
Grill Power	1100 / 2300 W
Turbo Power	1800 W
Turbo Motor	Yes
Oven Lamp	15 / 25 W
Power Supply	230 V, 50 Hz
Control Type	Knobs and buttons
Number of Cooking Functions	Multiple (oven, grill, turbo)
Self-Cleaning	No
Safety Features	Child lock, automatic shut-off
Spare Parts Availability	Check Blomberg service centers
Repairability Index	Moderate (standard components)
Included Accessories	Oven tray, grill rack
Energy Efficiency Class	Not specified (estimate A)

Frequently Asked Questions - BEO 1101 BLOMBERG

How do I set the time on my Blomberg BEO 1101 cooker?

Press and hold the clock button until the display flashes. Use the + and - buttons to set the hour, then press the clock button again to set minutes. Confirm with the clock button.

What is the maximum oven temperature?

The oven can reach up to 250°C (482°F). Use the thermostat knob to select the desired temperature.

Why is my oven not heating?

Check if the appliance is plugged in and the circuit breaker hasn't tripped. Ensure the oven function is selected properly. If the problem persists, the heating element may be faulty.

How do I clean the oven?

Use a mild detergent and a soft cloth. Avoid abrasive cleaners. For stubborn stains, use a specialized oven cleaner and follow the manufacturer's instructions.

Can I use aluminum foil in the oven?

Yes, but avoid covering the entire rack or blocking air circulation. Do not let foil touch the heating elements.

What does the turbo function do?

The turbo function uses a fan to circulate hot air evenly, allowing faster cooking and browning at lower temperatures.

How do I replace the oven light bulb?

Disconnect the cooker from power. Remove the light cover by unscrewing or unclipping it. Replace the bulb with a 25 W high-temperature resistant bulb (type G9). Reattach the cover.

Is the grill power switchable between 1100 and 2300 W?

Yes, the grill can operate at either 1100 W (inner element) or 2300 W (full surface). Select the desired power using the grill control knob.

What are the installation clearances?

Ensure a minimum clearance of 5 cm around the appliance for ventilation. The installation compartment must be at least 600 mm wide, 560 mm deep, and 600 mm high.

Where can I find spare parts?

Contact Blomberg authorized service centers or visit the official Blomberg website. Use your model number BEO 1101 to order genuine parts.

USER MANUAL BEO 1101 BLOMBERG

* Braunes Kabel = L (Phase)

Simple diagram showing a curved arrow pointing downward from a rectangular block (no text or symbols)

Interior view of a microwave oven with tray and vent (no visible text or symbols)

BEO 1440

ovendeur opent, wees

	BEO 1570	BEO 1430	BEO 1410	BEO 1101
	BEO 1540		BEO 1011
	BEO 1450		BEO 1411
	BEO 1440
	BEO 1021
Wattverbruik van de grill	1100/2300	1100/2300	1100/2300	1100/2300
Wattverbruik van de oven	3200 W	2500 W	2500 W	2400 W
Wattverbruik van de turbo	1800 W	1800 W	-	-
Turbomotor	+	+	+	-
Lamp	15 W/ 25 W	15 W/ 25 W	15 W/ 25 W	15 W/ 25 W
Externe afmetingen	H: 595 mm	H: 595 mm	H: 595 mm	H: 595 mm
	W: 594 mm	W: 594 mm	W: 594 mm	W: 594 mm
	D: 550 mm	D: 550 mm	D: 550 mm	D: 550 mm
Afmetingen van de installatie-instelling	W: 600 mm	W: 600 mm	W: 600 mm	W: 600 mm
	D: 560 mm	D: 560 mm	D: 560 mm	D: 560 mm
	H: 600 mm	H: 600 mm	H: 600 mm	H: 600 mm

Simple diagram showing a curved arrow pointing downward from a horizontal bar to a vertical wall (no text or symbols)

Simple diagram showing a curved arrow pointing to a horizontal bar with a small protrusion at the bottom (no text or symbols)

* Câble Marron = L (Live) * Câble Bleu = N (Neutre) * Câble Vert/Jaune = E (Terre)

	BE0 1570BE0 1540BE0 1450BE0 1440BE0 1021	BE0 1430	BE0 1410BE0 1011BE0 1411	BE0 1101
Puissance du grill en Watts	1100/2300	1100/2300	1100/2300	1100/2300
Puissance du four en Watts	3200 W	2500 W	2500 W	2400 W
Puissance turbo en Watts	1800 W	1800 W	-	-
Moteur turbo	+	+	+	-
Lampe	15 W/ 25 W	15 W/ 25 W	15 W/ 25 W	15 W/ 25 W
Dimensions externes	H: 595 mmW: 594 mmD: 550 mm	H: 595 mmW: 594 mmD: 550 mm	H: 595 mmW: 594 mmD: 550 mm	H: 595 mmW: 594 mmD: 550 mm
Cotes de mesures d'installation	W: 600 mmD: 560 mmH: 600 mm	W: 600 mmD: 560 mmH: 600 mm	W: 600 mmD: 560 mmH: 600 mm	W: 600 mmD: 560 mmH: 600 mm

Mise à l'heure :
