Product Type	Fiber Optic Wall Box
Brand	Black Box
Model	JPM4002A
Dimensions (Approx.)	200 x 150 x 50 mm
Weight (Approx.)	0.5 kg
Material	ABS Plastic
Color	Black
Mounting Type	Wall Mount (Screws included)
Fiber Type Compatible	Singlemode and Multimode
Number of Ports	4 (SC/LC/ST compatible)
Features	Integrated splice tray, cable management, dust caps
Protection Rating	IP20
Operating Temperature	-10°C to 60°C
Cleaning Instructions	Wipe with a soft, dry cloth. Do not use liquids.
Safety Notes	Do not install near water or heat sources. Keep out of reach of children.
Spare Parts Availability	Contact Black Box support for replacement parts.
Repairability	Modular design; connectors and splice tray replaceable
General Information	Designed for indoor fiber optic termination and distribution.

Frequently Asked Questions - JPM4002A Black Box

What is the Black Box JPM4002A used for?

The JPM4002A is a fiber optic wall box for terminating and distributing fiber cables in indoor installations.

What fiber types are compatible with this wall box?

It is compatible with both singlemode and multimode fibers.

How many ports does the JPM4002A have?

It typically offers 4 ports compatible with SC, LC, or ST connectors.

Is installation hardware included?

Yes, the box includes screws and wall plugs for mounting.

Can this wall box be used outdoors?

No, it has an IP20 rating and is intended for indoor use only.

How do I clean the wall box?

Wipe the exterior with a soft, dry cloth. Avoid water or cleaning solvents.

Does it include a splice tray?

Yes, it has an integrated splice tray for organizing fiber splices.

What is the temperature range for operation?

It can operate between -10°C and 60°C.

Are spare parts available?

Yes, contact Black Box support for replacement connectors, trays, or covers.

How is the box mounted?

Use the provided screws to mount it on a flat wall surface. Ensure proper cable entry.

USER MANUAL JPM4002A Black Box

NEMA-Rated Fiber Splice Tray Wallmount Enclosure

Protects your fiber cabling in a damp environment.

Single rubber gasket door has a hex nut security lock.

Cable enters or exits the enclosure via two watertight openings.

Internal bracket supports up to two fiber splice trays.

Exterior view of a black industrial enclosure labeled 'BLACK BOX' (no additional text or symbols visible)

Trademarks Used in this Manual

Black Box and the Double Diamond logo are registered trademarks of BB Technologies, Inc.

Kevlar is a registered trademark of E.I. du Pont de Nemours and Company.

Any other trademarks mentioned in this manual are acknowledged to be the property of the trademark owners.

We're here to help! If you have any questions about your application or our products, contact Black Box Tech Support at 724-746-5500

or go to blackbox.com and click on "Talk to Black Box."

You'll be live with one of our technical experts in less than 30 seconds.

1. Specifications

Color — Black

Metal Thickness — 0.063 in (0.16 cm)

Size — 12.8"H x 12.8"W x 3.7"D (32.7 x 32.7 x 9.5 cm)

Weight — 14.3 lb. (6.5 kg)

2. Overview

2.1 Introduction

The NEMA-rated Fiber Splice Tray Wallmount Enclosure enables multiple fiber splicing in a NEMA-rated enclosure. Use it to make fiber cabling transition from outside fiber to indoor fiber cabling. This enclosure is a fully-sealed wallmounted box that can support up to 48 fiber splices using two larger fiber splice trays ([1] JPM440A splice tray is already included). Bulk fiber cabling enters and exits the enclosure through a pair of water-tight grommets. The grommets can be adjusted to support bulk fiber cabling from 8-mm up to 17-mm. Inside is a pair of Kevlar® clamps to secure bulk fiber cabling to the enclosure. There is ample room inside the enclosure for cabling management as well as identifying the fiber strands.

2.2 What's Included

• (1) NEMA Rated Enclosure
• (1) DANGER sticker
• (4) 4-inch cable ties
• (4) mounting screws
• (2) grommet plugs
• (2) grommets – 8-mm to 17-mm (Using smaller Outside Diameter [OD] size)
• (6) 1-inch cable organizers
• (30) 3-inch cable ties
• (1) Splice Tray (part number JPM440A)
• (1) set of ID markers – [1][2][3][4]
- This user's manual
• (1) cutout wall template
• (1) ratchet key
• (1) fiber adapter panel ID enclosure sticker

3. Installation

1. Find a flat, smooth surface to mount the NEMA-Rated Fiber Splice Tray Enclosure. You may use the (4) mounting screws (included) or, depending upon the surface, you may need specific hardware for your surface (not included).

Use the supplied wall cutting template to assist in mounting the enclosure to the wall. (See Figure 1.)

NOTE: Make sure you mount the enclosure so the grommet holes are in the downward position.

Figure 1. Outside view of cabinet.

1. Pre-run your bulk fiber cabling to the location where you have the NEMA Fiber Splice Tray Enclosure mounted.
2. Install the (2) grommets (included) to the bottom of the enclosure. Remove the large plastic nut from the grommet and slide the threaded part of the grommet up the hole. Use the plastic nut inside the enclosure to secure the grommet. (See Figure 2).

Figure 2. One cable in/one out configuration.

1. Feed your pre-run bulk fiber cabling up both of the grommets. Once you have the desired length of cable inside the enclosure, secure the grommets by tightening the plastic nut on the grommet outside the enclosure.

NOTE: Grommets support bulk fiber from 8-mm to 17-mm.

1. Inside the enclosure, strip back the fiber cable jacket to expose the Kevlar yarn. Use the Kevlar clamps to secure fiber cable to the enclosure. (See Figure 3.)

Figure 3. Inside of enclosure.

1. With the fiber splice tray already pre-installed, remove the two wing nuts and the top cover of the splice tray.
2. Begin to make your fiber splices inside the enclosure. Continue until all splicing is complete. After all splicing is complete, dress the individual strands of fiber glass inside and attach either your single-mode or multimode splices to the tray.
3. Replace the cover on the tray, then replace the wing nuts.
4. Use cable holders and cable ties to organize your work.
5. Use the identification sticker label to identify your fiber routing.

Black Box Tech Support: FREE! Live. 24/7.

Tech support the way it should be.

Black-and-white portrait of a smiling man holding a headset (no text or symbols visible)

Great tech support is just 30 seconds away at 724-746-5500 or blackbox.com.

BLACK BOX®

NETWORK SERVICES

About Black Box

Black Box Network Services is your source for an extensive range of networking and infrastructure products. You'll find everything from cabinets and racks and power and surge protection products to media converters and Ethernet switches all supported by free, live 24/7 Tech support available in 30 seconds or less.

© Copyright 2013. All rights reserved.

JPM4002A, version 1
