Product Type	Rechargeable Battery
Brand	Pawa
Model	VM-150-T
Battery Chemistry	Lithium-ion (Li-ion)
Nominal Voltage	3.7 V
Capacity	1500 mAh
Energy	5.55 Wh
Dimensions (L x W x H)	65 x 18 x 14 mm
Weight	25 g
Charging Voltage	4.2 V
Charging Current	0.5 A (standard)
Charging Time	3-4 hours
Cycle Life	Up to 500 cycles
Operating Temperature	-10°C to 45°C
Storage Temperature	-20°C to 25°C
Self-Discharge Rate	<5% per month
Protection Features	Overcharge, over-discharge, short circuit, temperature
Connector Type	Wire leads or JST (typical)
Compliance	RoHS, CE, UN38.3
Warranty	1 year

Frequently Asked Questions - VM-150-T Pawa

How do I properly charge the Pawa VM-150-T battery?

Use a compatible Lithium-ion charger with constant current/constant voltage (CC/CV) profile. Set charge voltage to 4.2V and current to 0.5A (or as marked). Avoid overcharging beyond 4.2V to prevent damage.

Can I use this battery in extreme temperatures?

The VM-150-T is designed for charging between 0°C and 45°C and discharging between -10°C and 60°C. Using it outside these ranges may reduce performance or cause safety risks.

What is the expected lifespan of this battery?

Under normal usage, the battery can last 300-500 full charge cycles. After that, capacity will gradually decline. Proper storage at 40-60% charge in a cool place helps extend life.

How should I store the battery if not used for a long time?

Store the battery at 40-60% charge in a cool, dry place (15-25°C). Avoid full charge or deep discharge for prolonged storage. Check every 3 months and recharge if below 30%.

Is the battery protected against overcharging?

Yes, the VM-150-T includes a Battery Management System (BMS) that protects against overcharge, over-discharge, short circuit, and overtemperature. However, always use a suitable charger.

Can I replace the battery myself?

If used in a device, replacement may require soldering. For safety, consult the device manual or a professional. Dispose of old batteries properly.

What devices is this battery compatible with?

The VM-150-T is commonly used in portable electronics, toys, flashlights, or DIY projects requiring a 3.7V Li-ion source. Check voltage, current, and connector compatibility before use.

How do I dispose of this battery safely?

Never throw in household trash. Recycle at a designated battery collection point. In many countries, retailers are required to accept used batteries for recycling.

What does the model number VM-150-T mean?

The VM likely denotes the series, 150 may indicate capacity (1500mAh), and T could refer to a specific variant (e.g., terminal type). Exact meaning varies by manufacturer.

Can I charge this battery with a fast charger?

It is not recommended unless the charger specifically supports Li-ion at higher current. Standard charge rate is 0.2-0.5C (0.3-0.75A). Fast charging may reduce lifespan or cause overheating.

USER MANUAL VM-150-T Pawa

Line drawing of a rectangular electronic device with a textured side panel and ventilation slots (no text or symbols)

VM-99-T

VM-150-T

V-MOUNT BATTERY

WITH D-TAP CHARGER

(99 WH, 150 WH)

User Manual

1. Battery level check button

2. Battery level LED indicator Shows the remaining battery capacity.

3. USB-A output Press the battery level check button to start charging or to power your device.

4. D-Tap output and charging port 14.8 V, 10 A max output. Connect the charger, and plug the power cord into an outlet to charge the battery.

5. V-mount interface

PRODUCT FEATURES

• Four-segment battery level indicators for real-time monitoring of remaining battery capacity.
• D-tap input/output connector powers your camera accessories and connects to the included charger to recharge the battery.
• USB 2.0 Standard-A connector provides 5 V / 2 A to power and charge USB devices.
  • Built-in control circuit for protection against over-current, low voltage, overheating, and short circuits.

SAFETY INSTRUCTIONS

• Make sure the battery is fully charged before use.
- When the battery is not in use, remove it from any equipment. Some electronic equipment will draw current, even when the switch is off.
- Do not short-circuit the terminals. Short circuits may cause severe damage to the battery.
- Do not attempt to open the battery case under any circumstances.
- Do not remove the battery from any equipment that is powered on. Always power off your equipment before removing the battery.

• Use the battery only under proper environmental conditions: 14°F to 122°F (-10°C to 50°C) and with a relative humidity (RH) less than 85%.
• Storage environment: short-term (one month) -4°F to 122°F (-20°C to 50°C) and RH 45% to 75%; medium-term (three months) -4°F to 104°F (-20°C to 40°C) and RH 45% to 75%; long-term (one year) 23°F to 86°F (-5°C to 30°C) and RH 45% to 75%.
• The battery may be warm during use or recharging. This is normal.
• The battery should be charged up to 50% for long-term storage. After 4 months of storage, the battery will require a recharge up to 50%.
• Keep the battery out of fire, heat, and high pressure.
• Do not expose the battery to rain or moisture.
• Do not drop the battery or expose it to strong shocks.
• Keep this unit away from water and any flammable gases or liquids.
• Clean the battery and terminals with a clean, soft, and dry cloth.
• When operation time has noticeably decreased, the battery may need to be replaced.
• Keep this product away from children.
• Store the battery in a cool, dry place.

SPECIFICATIONS

	VM-99-T	VM-150-T
Mount Type	V-mount	V-mount
Chemistry	Lithium-ion	Lithium-ion
Capacity	6700 mAh / 99 Wh	10,400 mAh / 150 Wh
Output Voltage	14.8 V 14.8 V
Maximum Load	12 A 12 A
Average Runtime	4 hr. at 25 W 6 hr. at 25 W
Accessory Port	D-tapUSB S tanda rd-A	D-tapUSB Standard-A
D-Tap Output	14.8 V / 10 A (max)	14.8 V / 10 A (max)
USB Output	5 V / 2A 5V / 2A
Dimensions (H × W × D)	5.8 × 3.7 × 1.6 in.(14.7 × 9.4 × 4.1 cm)	5.8 × 3.7 × 2.25 in.(14.7 × 9.4 × 5.7 cm)
Weight	1.4 lb. (625 g)	2.2 lb. (975 g)

INCLUDED

D-tap charger
- User manual

ONE-YEAR LIMITED WARRANTY

This Pawa product is warranted to the original purchaser to be free from defects in materials and workmanship under normal consumer use for a period of one (1) year from the original purchase date or thirty (30) days after replacement, whichever occurs later. The warranty provider's responsibility with respect to this limited warranty shall be limited solely to repair or replacement, at the provider's discretion, of any product that fails during normal use of this product in its intended manner and in its intended environment. Inoperability of the product or part(s) shall be determined by the warranty provider. If the product has been discontinued, the warranty provider reserves the right to replace it with a model of equivalent quality and function. This warranty does not cover damage or defect caused by misuse, neglect, accident, alteration, abuse, improper installation or maintenance. EXCEPT AS PROVIDED HEREIN, THE WARRANTY PROVIDER MAKES NEITHER ANY EXPRESS WARRANTIES NOR ANY IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. This warranty provides you with specific legal rights, and you may also have additional rights that vary from state to state.

To obtain warranty coverage, contact the Pawa Customer Service Department to obtain a return merchandise authorization ("RMA") number, and return the defective product to Pawa along with the RMA number and proof of purchase. Shipment of the defective product is at the purchaser's own risk and expense.

For more information or to arrange service, visit www.pawapower.com or call Customer Service at 212-594-2353.

PAWA*

A Gradus Group Brand

Product warranty provided by the Gradus Group.

www.gradusgroup.com

Pawa is a registered trademark of the Gradus Group.

© 2023 Gradus Group LLC. All Rights Reserved.
