RPA4000 - Support d'écran plat Chief - Free user manual and instructions
Find the device manual for free RPA4000 Chief in PDF.
Pick your language and provide your email: we'll send you a specifically translated version.
| Product Type | Flat Panel Mount |
| Brand | Chief |
| Model | RPA4000 |
| Weight Capacity | 125 lbs (56.7 kg) |
| VESA Compatibility | 200x200 mm to 600x400 mm |
| Tilt Range | +/- 15 degrees |
| Swivel Range | +/- 90 degrees |
| Level Adjustment | +/- 3 degrees |
| Mounting Pattern | Single or dual stud (wood or concrete) |
| Material | Heavy-gauge cold-rolled steel |
| Finish | Black powder coat |
| Dimensions | 20 x 20 x 2 inches (51 x 51 x 5 cm) |
| Weight | 5 lbs (2.3 kg) |
| Screen Size | 32 to 70 inches |
| Power Supply | Not applicable (mechanical mount) |
| Maintenance | Wipe with dry cloth; check fasteners periodically |
| Safety | Designed for use with UL-listed displays; must be installed per manual |
| Spare Parts | Contact Chief customer service for replacement parts |
| Repair | No user-serviceable parts; professional repair recommended |
| Included Accessories | Mounting hardware, adapter brackets, manual |
Frequently Asked Questions - RPA4000 Chief
What is the maximum weight capacity of the Chief RPA4000?
The maximum weight capacity is 125 lbs (56.7 kg).
What VESA patterns does the RPA4000 support?
It supports VESA patterns from 200x200 mm to 600x400 mm.
Can the mount tilt and swivel?
Yes, it offers +/- 15 degrees tilt and +/- 90 degrees swivel for optimal viewing angles.
What type of wall can I install this mount on?
The mount can be installed on wood studs or concrete walls using the included hardware.
Is the mount compatible with my display?
Check your display's weight (≤125 lbs) and VESA pattern. It fits most 32-70 inch flat panels.
Does the mount come with all necessary hardware?
Yes, it includes mounting hardware, adapter brackets, and a detailed manual.
How do I clean and maintain the mount?
Wipe with a dry cloth and periodically check that all bolts are tight. Avoid liquid cleaners.
Can I install the RPA4000 on a single stud?
Yes, it is designed for single or dual stud installation, but always verify structural support.
What is the warranty on this mount?
Chief typically offers a limited lifetime warranty. Check the manual for details or contact customer support.
Where can I find replacement parts if needed?
Contact Chief customer service for spare parts or repair options. Do not attempt to modify the mount.
