DJ Bank FX - Effects machine Chauvet - Free user manual and instructions

Product Type	Effects Machine (Fog Machine)
Brand	Chauvet
Model	DJ Bank FX
Dimensions (L x W x H)	12.2 x 7.5 x 9.1 in (310 x 190 x 230 mm)
Weight	9.9 lb (4.5 kg)
Power Supply	AC 120 V, 60 Hz (or 230 V, 50 Hz depending on region)
Power Consumption	500 W
Fluid Tank Capacity	0.5 gal (1.9 L)
Fluid Consumption	Approx. 0.5 oz/min (15 mL/min) at full output
Output Volume	Up to 2,500 cu ft/min (70 m³/min)
Heat-Up Time	Approx. 2-3 minutes
DMX Channels	1 or 5 (selectable)
Control Modes	DMX, Manual, Remote (included)
Remote Control	Wired remote with on/off and timer
Recommended Fluid	Chauvet DJ Fog Fluid (water-based)
Cleaning	Run distilled water through the system after every 40 hours of use to prevent clogging
Safety Features	Thermal cut-off; automatic shut-off when fluid is low
Mounting	Can be placed on floor or hung from a truss (mounting bracket included)
Operating Temperature Range	32-104°F (0-40°C)
Warranty	2-year limited warranty

Frequently Asked Questions - DJ Bank FX Chauvet

What type of fluid should I use with the DJ Bank FX?

Use only water-based fog fluid recommended by Chauvet, such as Chauvet DJ Fog Fluid. Using other fluids may damage the heater and void the warranty.

How do I clean the DJ Bank FX?

After every 40 hours of use, run a tank of distilled water through the machine to clean the heating element. Then empty the tank and let it dry.

Can I control the DJ Bank FX with DMX?

Yes, the DJ Bank FX has selectable DMX modes (1 or 5 channels). Use a standard DMX controller and set the address via DIP switches or digital display.

What is the heat-up time?

The machine takes approximately 2-3 minutes to reach operating temperature. The indicator light will turn green when ready.

How long does a full tank last?

With continuous output, a full 0.5-gallon tank lasts about 60-90 minutes, depending on output level.

What is the included remote control?

The DJ Bank FX comes with a wired remote that allows you to turn fog output on/off and set a timer for continuous or burst operation.

Can I mount the machine?

Yes, the DJ Bank FX includes a mounting bracket for truss hanging. Ensure it is securely fastened and positioned for proper ventilation.

What should I do if the machine stops producing fog?

First, check that the fluid tank is not empty. Then verify the power and heat-up status. If still not working, clean the heater as described in the manual. Persistent issues may require service.

Is the DJ Bank FX safe to use indoors?

Yes, when used with approved fog fluid and in a well-ventilated area. Always ensure the machine is on a stable surface and away from flammable materials.

What is the warranty?

Chauvet offers a 2-year limited warranty covering defects in materials and workmanship. Registration may be required.

USER MANUAL DJ Bank FX Chauvet

CHAVET®

Value · Innovation · Performance

It's Green Thinking.

TABLE OF CONTENTS

1. Before You Begin....3

What Is Included ....3

Unpacking Instructions....3

Claims....3

Text Conventions....3

Symbols....3

Disclaimer 3

Product at a Glance....4

Safety Notes 4

2. Introduction......5

Overview......5

Dimensions 6

3. Setup....7

AC Power....7

Fuse Replacement....7

Power Linking....8

Mounting 9

Orientation....9

Rigging....9

4. Operation....10

Configuration....10

Sound-Active Mode....10

Speed....10

5. Technical Information ....11

Product Maintenance 11

6. Technical Specifications....12

Returns 13

Contact Us....13

1. BEFORE YOU BEGIN

What Is Included

- DJ Bank™ FX

- Power Cord

- Warranty Card

- Quick Reference Guide

Unpacking Instructions

Carefully unpack the product immediately and check the container to make sure all the parts are in the package and are in good condition.

Claims

If the box or the contents (the product and included accessories) appear damaged from shipping, or show signs of mishandling, notify the carrier immediately, not CHAUVET®. Failure to report damage to the carrier immediately may invalidate your claim. In addition, keep the box and contents for inspection.

For other issues, such as missing components or parts, damage not related to shipping, or concealed damage, file a claim with CHAUVET® within 7 days of delivery.

Text Conventions

Convention Meaning
1–512	A range of values
50/60	A set of values of which only one can be chosen
Settings	A menu option not to be modified
Menu > Settings	A sequence of menu options to be followed
	A key to be pressed on the product's control panel
ON	A value to be entered or selected

Symbols

Symbol Meaning
	Critical installation, configuration, or operation information. Not following these instructions may make the product not work, cause damage to the product, or cause harm to the operator.
	Important installation or configuration information. The product may not function correctly if this information is not used.
	Useful information.

Disclaimer

The information and specifications contained in this User Manual are subject to change without notice. CHAUVET® assumes no responsibility or liability for any errors or omissions, and reserves the right to revise or recreate this manual at any time. Download the latest version from www.chauvetlighting.com.

© Copyright 2013 CHAUVET®. All rights reserved.

Electronically published by CHAUVET® in the United States of America.

Author	Date	Editor	Date
Albert Leon	05/23/13	T. Yeago	05/23/13

Product at a Glance

Use on Dimmer	X	Auto Programs	X
Outdoor Use	X	Auto-ranging Power Supply	P
Sound-Activated	P	Replaceable Fuse	P
DMX	X	User-Serviceable	X
Master/Slave	X

Safety Notes

These notes include important information about the mounting, usage, and maintenance of this product; read before using the product.

• Always connect the product to a grounded circuit to avoid the risk of electrocution.
- Always disconnect the product from the power source before cleaning or replacing the fuse.
- Avoid direct eye exposure to the light source while the product is on.
• Make sure the power cord is not crimped or damaged.
- Never disconnect the product from power by pulling or tugging on the cord.
- If mounting the product overhead, always secure to a fastening device using a safety cable.
• Make sure there are no flammable materials close to the product when operating.
- Do not touch the product's housing when operating because it may be very hot.

• Always make sure that the voltage of the outlet to which you are connecting the product is within the range stated on the decal or rear panel of the product.
• The product is for indoor use only! (IP20) To prevent risk of fire or shock, do not expose the product to rain or moisture.
• Always install the product in a location with adequate ventilation, at least 20 in (50 cm) from adjacent surfaces.
• Be sure that no ventilation slots on the product's housing are blocked.
  • Never connect the product to a dimmer.
  • Make sure to replace the fuse with another of the same type and rating.
• Never carry the product from the power cord or any moving part. Always use the hanging/mounting bracket.
• The maximum ambient temperature (Ta) is 104° F (40° C). Do not operate the product at higher temperatures.
  • In the event of a serious operating problem, stop using the product immediately.
• Never try to repair the product. Repairs carried out by unskilled people can lead to damage or malfunction. Contact the nearest authorized technical assistance center.
• This product is not intended for permanent installation.

- Keep this User Manual for future use. If you sell the product to another user, be sure to give this document to the next owner.

2. INTRODUCTION

Overview

Back Panel View

Dimensions

3. SETUP

AC Power

The DJ Bank™ FX has an auto-ranging power supply and it can work with an input voltage range of 100\~240 VAC, 50/60 Hz.

To determine the product's power requirements (circuit breaker, power outlet, and wiring), use the current value listed on the label affixed to the product's back panel, or refer to the product's specifications chart. The listed current rating indicates the product's average current draw under normal conditions.

Always connect the product to a protected circuit (circuit breaker or fuse). Make sure the product has an appropriate electrical ground to avoid the risk of electrocution or fire.

Never connect the product to a rheostat (variable resistor) or dimmer circuit, even if the rheostat or dimmer channel serves only as a 0–100% switch.

Fuse Replacement

Disconnect the product from power before replacing the fuse.

1. Disconnect the product from power.
2. Wedge the tip of a flat-head screwdriver into the slot of the fuse holder.
3. Pry the fuse holder out of the housing.
4. Remove the blown fuse from the holder.
5. Replace with a fuse of the exact same type and rating.
6. Insert the fuse holder back in place and reconnect power.

A spare fuse is not included; however, the safety cap has room for a spare.

Power Linking

The product provides power linking via the Edison/IEC outlet located in the back of the unit.

Power Linking Diagram

You can power link up to 94 DJ Bank™ FX units on 120 VAC or up to 97 DJ Bank™ FX units on 230 VAC.

The power linking diagram shown above corresponds to the North American version of the product ONLY! If using the product in other markets, you must consult with the local CHAUVET® distributor as power linking connectors and requirements may differ in your country or region.

Mounting

Before mounting the product, read and follow the safety recommendations indicated in the Safety Notes.

Orientation

The DJ Bank™ FX may be mounted in any position; however, make sure adequate ventilation is provided around the product.

Rigging

• Before deciding on a location, always make sure there is easy access to the product for maintenance and adjustments.
• Make sure that the structure or surface onto which you are mounting the product can support the product's weight (see the Technical Specifications).
• When mounting the product overhead, always use a safety cable. Mount the product securely to a rigging point, such as an elevated platform or a truss.
• When rigging the product onto a truss, you should use a mounting clamp of appropriate weight capacity. The bracket has 13-mm holes, which are appropriate for this purpose.
• When power linking multiple products, you must always consider the length of the power linking cable and mount the products close enough for the cable to reach.
• The bracket adjustment knobs allow for directional adjustment when aiming the product to the desired angle. Only loosen or tighten the bracket knobs manually. Using tools could damage the knobs.
• The mounting bracket also allows for surface mounting. When mounting the product on the floor, make sure that the product and cables are away from people and vehicles.

Mounting Diagram

4. OPERATION

Configuration

Plug in the DJ Bank™ FX to a suitable power outlet.

Sound-Active

To adjust the built-in Sound-Active mode, follow the instructions below:

Mode

1. Turn the music on.

2. Adjust the sound sensitivity adjustment knob until the product starts responding to the beat of the music.

The product will only respond to low frequencies of music (bass and drums).

Speed

To adjust the speed of the lights, do the following:

- Set the speed adjustment knob to the desired position, from minimum to maximum.
