5050 - Kitchen sink Sani-Lav - Free user manual and instructions

Product Type	Kitchen Sink
Brand	Sani-Lav
Model	5050
Material	Stainless Steel
Dimensions (L x W)	50 cm x 50 cm
Depth	15 cm
Bowl Configuration	Single Bowl
Installation Type	Drop-in / Undermount
Finish	Brushed
Included Accessories	Drain Kit, Mounting Clips
Weight	5 kg
Soundproofing	Yes (Rubber Pads)
Warranty	Limited Lifetime
Cleaning Method	Mild Soap and Soft Cloth
Maintenance	Avoid Abrasive Cleaners

Frequently Asked Questions - 5050 Sani-Lav

What are the exact dimensions of the Sani-Lav 5050 kitchen sink?

The Sani-Lav 5050 has outer dimensions of 50 cm x 50 cm and a depth of 15 cm. The bowl size is approximately 45 cm x 45 cm.

Is this sink suitable for undermount installation?

Yes, the Sani-Lav 5050 can be installed as either a drop-in or undermount sink. It includes mounting clips for both methods.

How do I clean the stainless steel surface?

Clean with mild dish soap and a soft cloth or sponge. Rinse thoroughly and dry to avoid water spots. Do not use abrasive cleaners or scouring pads.

Does the sink come with a drain assembly?

Yes, the package includes a drain kit with a strainer and tailpiece. Additional plumbing parts may be needed for connection.

What tools are required for installation?

You will need a jigsaw or router for cutting the countertop, a screwdriver, wrench, silicone sealant, and plumber's putty. Refer to the manual for detailed steps.

Can I use a garbage disposal with this sink?

Yes, the Sani-Lav 5050 is compatible with standard garbage disposals. Ensure the disposal flange fits the sink drain opening (typically 3.5 inches).

How do I remove scratches from the sink?

Minor scratches can be minimized by rubbing gently with a fine steel wool in the direction of the grain. For deeper scratches, professional refinishing may be required.

Is the sink resistant to rust and corrosion?

Yes, the sink is made from 304 stainless steel, which is highly resistant to rust and corrosion under normal kitchen use.

What is the warranty period?

Sani-Lav offers a limited lifetime warranty against manufacturing defects. It does not cover damage from improper installation or misuse.

How do I prevent water spots?

After each use, dry the sink with a soft towel or microfiber cloth. Regular application of a stainless steel polish can also reduce water spotting.

USER MANUAL 5050 Sani-Lav

SANI-LAV® COLUMBIA PRODUCTS

Wall Mount Stainless Steel Sink

Model 5050

Exterior view of a stainless steel kitchen sink with open lid (no text or symbols visible)

Columbia does not recommend use with harsh chemicals.

Product Compliance

NSF/ANSI 2 Food Equipment

COLUMBIA SPECIFICATIONS

WALL MOUNT SINK

Parts List

□(1) Wall mount sink
□(1) Wall-mounting bracket
□(1) Strainer assembly with basket

Top

Front Side

F

■ Wall Mounting Detail

■ Hole Configuration

Care and Maintenance

Regular cleaning will preserve the appearance and integrity of the surface. Stainless steel can easily be cleaned and kept stain-free using various methods.

Recommendations:

• Clean with an abrasive cleaner like, Bon-Ami or Zud weekly or bi-weekly. Always scrub in the direction of the grain or polish lines. Another option is to use Baking soda. Make sure to rinse well and dry. Illustration A
• Most soaps and detergents contain chlorides, we recommend rinsing the stainless-steel sink with hot water after use, to prevent corrosion. Illustration B
  • Regularly dry your sink to prevent water and surface rust marks. Illustration C
• Do not leave salt in the sink or near a saltwater environment.
• Use a quality stainless steel cleaner and follow cleaner instructions. Wipe along the grain (NOT against). Illustration D

Things to Avoid:

• Avoid harsh abrasive cleaners and corrosive chemicals.
• Avoid abrasive scouring pads, carbon steel brushes and steel wool for cleaning as iron particles left behind can lead to rust.
• Avoid the use of oily rags or greasy cloths when wiping the surface. To avoid water spots, wipe dry after use.

Additional Tips:

• Regularly drying your sink works wonders to prevent water and surface rust marks.
- Wear rubber gloves when working with cleaners to protect your hands.
- Never mix cleaners. Some products react to create dangerous gases.
- There are thousands of blended or compound cleaners on the market. Users are advised to contact suppliers of solvents for information on their applications on stainless steel.
• DO NOT USE SOLVENTS in closed spaces or while smoking.
• Note: Columbia does not recommend use with harsh chemicals.

Close-up of a circular mechanical component with internal grooves and water droplets (no text or symbols visible)

Illustration A

Close-up of a pipe passing through a container with bubbles rising, showing fluid and bubbles (no text or symbols visible)

Illustration B

Close-up of a hand cleaning a stainless steel faucet with a cloth (no text or symbols visible)

Illustration C

Hand cleaning a surface with a cloth, next to a stainless steel faucet (no text or symbols visible)

Illustration D

COLUMBIA PRODUCTS

800.626.2117 • columbiasinks.com • [e-mail]
