| Product Type | Professional Headset Microphone |
| Brand | Point Source Audio |
| Model | YSH |
| Polar Pattern | Cardioid |
| Frequency Response | 20 Hz - 20 kHz |
| Impedance | 150 ohms |
| Sensitivity | -45 dBV/Pa |
| Connector | Mini XLR (TA4F compatible) |
| Power Requirement | Phantom power (48V) or wireless beltpack |
| Dimensions (Boom Length) | Approx. 120 mm |
| Weight | 15 g |
| Cable Length | 1.2 m (standard) |
| Color | Black |
| Included Accessories | Windscreen, foam cover, clothing clip |
| Warranty | 2 years limited warranty |
| Cleaning | Wipe with a dry, soft cloth; avoid moisture |
| Intended Use | Professional audio, theater, presentation |
Frequently Asked Questions - YSH Point Source Audio
What is the polarity pattern of the YSH microphone?
The YSH microphone features a cardioid polar pattern, which effectively rejects background noise from the sides and rear, focusing on the sound source in front.
Can the YSH be used with wireless systems?
Yes, the YSH comes with a mini XLR connector (TA4F-compatible) that connects to most wireless beltpacks. Ensure your transmitter provides the necessary power (phantom power is not required with a beltpack).
How do I clean the YSH microphone?
Gently wipe the microphone body and grille with a dry, soft cloth. Do not use any liquids or solvents, as they may damage the internal components. Use the included windscreen to protect the capsule from moisture.
Is the YSH microphone suitable for outdoor use?
Yes, with the included windscreen, the YSH reduces wind noise effectively. However, avoid direct exposure to rain or heavy moisture.
What type of phantom power does the YSH require?
When used directly with an audio interface or mixer, the YSH requires 48V phantom power. Alternatively, it can be powered by a wireless beltpack.
How long is the cable on the YSH?
The standard cable length is 1.2 meters (about 4 feet), providing flexibility for most applications.
Can I replace the cable on the YSH?
The YSH has a fixed cable that cannot be replaced by the user. If the cable is damaged, please contact Point Source Audio support for repair options.
Is the YSH compatible with wireless systems from other brands?
The YSH uses a standard mini XLR (TA4F) connector. It is compatible with most wireless transmitters that accept this connector, including Shure, Sennheiser, and others.
What is the frequency response of the YSH?
The YSH offers a wide frequency response of 20 Hz to 20 kHz, capturing full-range audio with clarity.
Does the YSH come with a warranty?
Yes, it includes a 2-year limited warranty from Point Source Audio against manufacturing defects.
