DVK6J661 - Range hood Profilo - Free user manual and instructions

Product Type	Range Hood
Brand	Profilo
Model	DVK6J661
Dimensions (W x D x H)	60 cm x 50 cm x 15 cm (height adjustable)
Weight	12 kg
Power Supply	220-240 V, 50 Hz
Motor Power	250 W
Extraction Capacity (max)	650 m³/h
Noise Level (max)	58 dB(A)
Lighting	LED, 2 x 3 W
Filter Type	Aluminum grease filter (mesh)
Optional Carbon Filter	Yes, for recirculation mode
Control Type	Push-button panel
Energy Efficiency Class	A+
Annual Energy Consumption	50 kWh/year
Airflow Efficiency Class	A
Grease Filtering Efficiency Class	B
Noise Level Class	A
Installation Type	Under-cabinet (built-in)
Exhaust Diameter	150 mm
Number of Speeds	3
Additional Features	Intensive speed, indicator for filter cleaning
Maintenance	Clean grease filter monthly; replace carbon filter every 3-6 months
Safety	Auto-off timer, motor thermal protection
Spare Parts Available	Filters, bulbs, control panel, motor

Frequently Asked Questions - DVK6J661 Profilo

How do I install the Profilo DVK6J661 range hood?

Installation must be done by a qualified technician. Ensure the hood is mounted securely under a cabinet, connected to the electrical supply, and the exhaust duct is properly fitted. Refer to the included manual for detailed steps.

How often should I clean the grease filter?

The grease filter should be cleaned every month or more often if you cook frequently. Wash it by hand with warm soapy water or in the dishwasher. Ensure it is completely dry before reinstalling.

Can I use the hood in recirculation mode?

Yes, you can use recirculation mode by installing an optional carbon filter. This is ideal when external ducting is not possible. Replace the carbon filter every 3-6 months.

Why is my range hood making excessive noise?

Excessive noise can be due to a dirty filter, loose parts, or blockage in the duct. Check the filter and clean it if necessary. Ensure the hood is securely fastened and the duct is clear.

How do I replace the LED bulbs?

LED bulbs are integrated and may require a technician to replace. Contact Profilo customer service or a qualified electrician for assistance.

What does the filter cleaning indicator mean?

The indicator lights up when the grease filter needs cleaning. After cleaning, reset the indicator by pressing and holding the speed button for 3 seconds.

Can I control the hood with a remote?

No, the Profilo DVK6J661 does not come with remote control. It is operated via the push-button panel on the front.

What is the warranty period for this hood?

The standard warranty is 2 years from the date of purchase. Keep your receipt and register the product on the Profilo website for extended coverage options.

How do I activate the intensive speed?

Press the intensive speed button (usually marked with a star or ‘B’ ) to activate a 10-minute boost at maximum power. It will automatically revert to the previous speed after 10 minutes.

Where can I find spare parts like filters?

Spare parts can be ordered from authorized Profilo dealers or online spare parts stores. Use the model number DVK6J661 to ensure compatibility.

USER MANUAL DVK6J661 Profilo

European Union flag with twelve yellow stars arranged in a circle on a blue background (no text or symbols)

ENERG

енергия · ενεργεια

DVK6J661

PROFiLO

ENERJÍ

50

kWh/yil

65/2014
