FD6R - Fondue PROLINE - Free user manual and instructions

Product Type	Electric Fondue Set
Model	FD6R
Brand	Proline
Capacity	1.5 liters
Dimensions (W x D x H)	22 cm x 22 cm x 18 cm
Weight	1.2 kg
Power	800 W
Voltage	220-240 V ~ 50/60 Hz
Temperature Control	Adjustable thermostat with indicator light
Material	Stainless steel pot and aluminum heating base
Includes	6 fondue forks, pot, heating base, temperature control cable
Functions	Fondue for cheese, chocolate, oil, or broth
Safety Features	Thermal fuse, non-slip feet, cool-touch handle
Cleaning and Maintenance	Hand wash pot and forks; wipe base with damp cloth
Spare Parts and Repairability	Replacement pot, forks, and heating element available
Warranty	1 year

Frequently Asked Questions - FD6R PROLINE

What is the capacity of the Proline FD6R fondue set?

The fondue set has a capacity of 1.5 liters, suitable for 4-6 people.

Can I use the FD6R for oil fondue?

Yes, the temperature control allows setting high temperatures for oil or broth fondue. Always use caution to avoid overheating.

How do I clean the fondue pot?

Allow the pot to cool completely, then hand wash with warm soapy water. Do not immerse the heating base in water.

Are the fondue forks dishwasher safe?

No, the forks should be hand washed to prevent damage to the handles.

How do I adjust the temperature?

Turn the thermostat dial to the desired setting. The indicator light will turn off when the set temperature is reached.

What safety features does the FD6R have?

It includes a thermal fuse to prevent overheating, non-slip feet for stability, and a cool-touch handle on the pot.

Can I buy replacement parts?

Yes, replacement pots, forks, and heating elements are available from the manufacturer or authorized dealers.

What is the voltage of the fondue set?

It operates on 220-240 V AC, 50/60 Hz. Ensure your electrical outlet matches this specification.

Can I use metal utensils on the pot?

Avoid metal utensils that may scratch the non-stick coating. Use silicone, wooden, or plastic utensils.

What should I do if the fondue set stops working?

Check the power connection and thermostat setting. If it still does not work, contact customer service for repair or replacement.

USER MANUAL FD6R PROLINE

Darty Holdings SAS © 14 route d'Aulnay 93140 Bondy, France

19/07/2016

PROLINE

FD6R

FONDUE

Red and black photo of a standard flatbed cooktop with six kitchen utensils (no text or symbols visible)

INSTRUCTION MANUAL

MODEL CNTLO

CLOTHUSANWIZING

WARNINGS

This appliance is intended to be used in household and similar applications such as:
- staff kitchen areas in shops, offices and other working environments;
- farm houses;
- by clients in hotels, motels and other residential type environments;
- bed and breakfast type environments.
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
This appliance shall not be used by children from 0 year to 8 years. This appliance can be used by children aged from 8 years and above if they are continuously supervised. This

EN-1

appliance can be used by people with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.

• Keep the appliance and its cord out of reach of children aged less than 8 years.
• Cleaning and user maintenance shall not be made by children.
  The appliance is not intended to be operated by means of an external timer or separate remote-control system.
  The outer surface may get hot when the appliance is operating.
  The temperature of accessible surfaces may be high when the

EN-2

appliance is operating.❖Do not place the appliance in or near hot gas or electric burner, or permit to touch a heated oven or mini oven.❖Regarding the instructions for cleaning surfaces in contact with food or oil, refer to the section “Cleaning and Maintenance”.❖The appliance must not be immersed.❖Cooking appliances should be positioned in a stable situation with the handles (if any) positioned to avoid spillage of the hot liquids.❖WARNING: Risks of injuries if you don’t use this appliance correctly.❖The heating element surface is subjected to residual heat after use.❖The surfaces are liable to get hot during use.

Do not touch hot surface Use the handle while moving the product.Do not place the appliance in or near hot gas or electric burner, or permit to touch a heated oven or mini oven.

EN-3

EN-4

IMPORTANT SAFETY INSTRUCTIONS

• Place the appliance on a stable flat surface while in use.
• When using the appliance, please make sure that adequate air space is provided above and on all sides of the appliance for circulation.
• Always turn the temperature control to the MIN position and then disconnect the appliance from the mains socket when not in use, before moving or cleaning.
• Do not position and use this appliance near flammable materials such as curtains.
• The use of any accessories not recommended by the manufacturer may cause injury.
• Extreme caution must be used when moving fondue containing hot oil or other hot liquids.

PARTS

1. Fondue forks (6)

2. Fondue fork holder

3. Fondue pot

4. Handle

5. Heating base

6. Thermostat knob

BEFORE FIRST USE

Before using the appliance for the first time, clean the fondue pot, holder and forks in warm soapy water. Rinse and dry them thoroughly. Wipe surfaces of heating base with a slightly damp cloth and dry.

EN-5

OPERATION

1. Place the heating base on a level, stable, heat-resistant surface, away from any edge.
2. Plug the heating base into the mains socket.

- Make sure that the thermostat knob is set at the MIN position.

1. Turn the thermostat knob to the MAX position to heat up the heating base for 5-8 minutes.

• The red indicator light will illuminate.
- When you using the appliance for the first time, there may be a slight odour and smoke emitted. This should disappear after a few minutes and it is normal.

1. Add the required amount of chocolate, cheese and other ingredients in the fondue pot.

2. Do not fill the fondue pot with ingredients past the MAX fill line.
   • To melt quickly and evenly, it is recommended to use diced or
   grated cheese and chocolate broken in small pieces.

3. Place the pot on the heating base.

1. Position the fork holder on the top of the fondue pot.

2. Make sure that the rim of the fork holder sits firmly on the edge of the fondue pot.

3. Adjust the thermostat knob to the required setting.
4. During cooking, the red indicator light will cycle on and off to maintain the set temperature.
5. Stir constantly until the mixture is melted and smooth.
6. Use the fondue forks to prick foods for cooking or dipping. Be careful not to scratch the non-stick surface when placing forks in the pot.
7. Dipping foods should be cut into bite-sized pieces. Meats can be cut into cubes or strips. For potatoes, it is best to steam them until tender but still firm.

EN-6

To make oil fondue, it is recommended to heat up the oil on we but please be extremely careful when pouring the hot oil oil fondue pot.

1. After cooking, turn the thermostat knob to the MIN position and disconnect the appliance from the mains socket.
   • The red indicator light will go out.

CLEANING AND MAINTENANCE

Unplug the appliance and allow it to cool down to room temperature before cleaning.

Clean the fondue pot, holder and forks in warm soapy water. Rinse and dry them thoroughly.

Clean the heating base using a slightly damp cloth.

Do not immerse it in water or any other liquid.

Never use any abrasive or chemical cleaning agents.

Surfaces in contact with food should be cleaned regularly to avoid cross contamination from different types of food, the use of hot clean water with a mild detergent is advisable when dealing with surfaces that come into contact with food.

Correct food hygiene practises should always be followed at all times to avoid possibility of food poisoning /cross contamination.

SPECIFICATIONS

Ratings: 220V-240V\~ 50/60Hz

500W

EN-7

DISPOSAL

As a responsible retailer we care about the environment.

As such we urge you to follow the correct disposal procedure for the appliance and packaging materials. This will help conserve natural resources and ensure that it is recycled in a manner that protects health and the environment.

You must dispose of this appliance and its packaging according to local laws and regulations.

Because this appliance contains electronic components, the appliance and its accessories must be disposed of separately from household waste when the appliance reaches its end of life.

Contact your local authority to learn about disposal and recycling.

The appliance should be taken to your local collection point for recycling. Some collection points accept appliance free of charge.

We apologise for any inconvenience caused by minor inconsistencies in these instructions, which may occur as a result of product improvement and development.

Darty Holdings SAS © 14 route d'Aulnay 93140 Bondy, France

19/07/2016

EN-8
