Product Type	Digital Instant-Read Thermometer
Brand	Taylor
Model	5147
Temperature Range	-58°F to 572°F (-50°C to 300°C)
Accuracy	±1.8°F (±1°C)
Resolution	0.1°F/°C
Display	LCD with backlight
Probe Length	4.5 inches (11.4 cm)
Overall Dimensions	6.5 x 1.5 x 1.2 inches (16.5 x 3.8 x 3 cm)
Weight	3.2 ounces (90 grams)
Power Source	1 CR2032 coin cell battery
Battery Life	Approximately 300 hours
Auto-Off	After 5 minutes of inactivity
Main Functions	Instant temperature reading; °F/°C switchable; min/max memory
Response Time	< 5 seconds
Water Resistance	IPX4 splash-proof
Cleaning	Wipe probe with damp cloth; do not immerse
Safety	Not for oven use; do not leave in food while cooking
Certifications	NSF, CE, RoHS
Spare Parts	Battery (CR2032), probe cover (sold separately)
Warranty	1 year limited

Frequently Asked Questions - 5147 Taylor

How do I change the battery in my Taylor 5147 thermometer?

Remove the battery compartment cover on the back of the unit. Replace the old CR2032 coin cell battery with a new one, ensure correct polarity (+/-), and close the cover.

Can I use this thermometer for oven or grill cooking?

No, the Taylor 5147 is an instant-read thermometer and should not be left inside an oven or grill. It is designed for quick temperature checks only.

How do I switch between Fahrenheit and Celsius?

Press and hold the '°F/°C' button for 2 seconds to toggle between temperature units.

Is the Taylor 5147 dishwasher safe?

No. Only the probe can be wiped with a damp cloth. Do not immerse the thermometer in water or put it in the dishwasher.

What is the accuracy of this thermometer?

The Taylor 5147 has an accuracy of ±1.8°F (±1°C) within the specified range.

How long does it take to get a reading?

The thermometer provides a reading in less than 5 seconds.

What does the 'H/L' indicator mean?

'H' means the temperature is above the maximum range, and 'L' means it is below the minimum range. The thermometer cannot measure beyond its specified limits.

Can I use this thermometer for liquids?

Yes, it can be used for liquids, but avoid submerging the handle or display. Insert only the probe tip.

How do I clean the probe?

Wipe the probe with a damp cloth or use an alcohol wipe. Dry thoroughly before storage.

What is the temperature range of the Taylor 5147?

It measures from -58°F to 572°F (-50°C to 300°C).

USER MANUAL 5147 Taylor

WOOD GRAIN THERMOMETER

■ Durable resin construction with high-impact bulb guard
■ Weather resistant, precision thermometer tube for accurate readings
■ Temperature range: 0°F to 120°F and -15°C to 50°C

EXPOSURE:

Do not mount in direct sunlight, near a heat source, or near a large body of water as these situations could affect the proper air temperature reading. Ultraviolet light from sunlight can prematurely weather the product.

SEPARATED FLUID:

Occasionally, rough handling in shipment or improper storage may cause the red liquid to separate slightly. This is not a defect. The liquid can be reunited easily before installation. First, remove from the card. Tap the side of the thermometer, bulb end down against the palm of the hand. Pause between taps to permit liquid to run down tube. Continue until liquid is completely joined.

Illustration of hands holding a rectangular object with a ruler, no text or symbols present

REJOINING SEPARATED FLUID

COMPLETE ONE YEAR

LIMITED WARRANTY

5147

©2018

Taylor Precision Products

Oak Brook, IL 60523

www.taylorusa.com

5147_7.17.18
