X120-W - Light Epcom - Free user manual and instructions

Product Type	LED Light Kit
Brand	Epcom
Model	X120-W
Voltage Range	10-24 VDC
Power Consumption	36W
Current Draw	1A max
Flash Patterns	12
Mounting Type	Permanent
LED Count	6 per lamp
Technology	Gen III
Cable Configuration	Red (VCC), Black (GND), White (Pattern Select), Green (Synchronization)
Application	Emergency vehicles (external use)
Safety Warning	High intensity - do not look directly; risk of eye damage
Airbag Warning	Ensure no interference with airbag deployment
Ventilation	Adequate ventilation required
Synchronization	Via green wire connecting multiple units
Pattern Selection	Pulse white wire to VCC to change pattern
Specifications Note	Subject to change without notice

Frequently Asked Questions - X120-W Epcom

What voltage does the Epcom X120-W require?

The Epcom X120-W operates on 10-24 VDC power supply.

How many flash patterns does it have?

It offers 12 selectable flash patterns.

How do I synchronize two Epcom X120-W lights?

Connect the green wires of both lights together to synchronize them.

What do the wire colors mean?

Red is VCC (power), Black is GND (ground), White is for pattern selection (pulse to VCC), and Green is for synchronization.

Can I install the light inside the vehicle?

The device is designed for external use, but may be mounted inside with caution. Ensure adequate ventilation and no interference with airbag deployment.

Is it safe to look directly at the light when on?

No, the light is high intensity and can cause temporary blindness or permanent eye damage. Avoid direct eye exposure.

What is the power consumption of the Epcom X120-W?

It consumes 36W with a maximum current draw of 1A.

How do I change the flash pattern?

Briefly apply voltage to the white wire (pulse to VCC) to cycle through the 12 patterns.

How is the light mounted?

The mounting is permanent, designed for fixed installation on emergency vehicles.

How many LEDs does the X120-W have?

Each lamp has 6 LEDs. The kit includes two lamps, so a total of 12 LEDs.

USER MANUAL X120-W Epcom

Electrical circuit setup with black components and two pressure gauges (no text or symbols visible)

Introduction

The X12 hidden LED kit adopts the highly innovative Gen III technology as a light source with unique appearance, compact structure, easy operation and diversified flash patterns.

It is characterized by high brightness, low work intensity, easy installation and a long service time; They are also specially designed to work on all types of

emergency vehicles.

Dimensions

Please read all instructions before installing your equipment.

Technical data

• Voltage: 10-24 VDC
- 36W
- Consumption: 1 A max
- Flash patterns: 12
- Mounting: Permanent
• Total # of Leds: 6 for each lamp

Cable configuration

• Red Cable: VCC
• Black Cable: GND
• White Cable: to define type of flash (Pulse to Vcc)
• Green Cable: To synchronize with another light

Recommendations:

The equipment is designed for external use of the vehicle. The equipment must have adequate ventilation.

High intensity equipment. Do not look directly while the device is on. May cause momentary blindness and/or permanent eye damage.

WARNING You must be careful when positioning this equipment, for that the light and / or cable do not interfere with the proper functioning of the airbag of both the driver and the

passenger. Do not lend

Attention to this warning can cause serious or fatal injuries

NOTE Due to continuous product improvements, we reserve the right to change the specifications and information contained in this manual without prior notice.
