| Product Type | Power Strip / PDU |
| Model | MPSH16-D20-120V |
| Brand | Black Box |
| Number of Outlets | 16 (NEMA 5-15R or 5-20R) |
| Input Voltage | 120 V AC |
| Maximum Current | 20 A |
| Power Capacity | 2400 W (at 120 V) |
| Input Plug | NEMA L5-20P or equivalent twist-lock |
| Surge Protection | Yes, with indicator light |
| Circuit Breaker | 20 A resettable |
| Form Factor | Rack-mountable, 1U height |
| Dimensions (W x D x H) | 17.5 x 6.5 x 1.75 in (44.5 x 16.5 x 4.4 cm) |
| Weight | 5.5 lbs (2.5 kg) |
| Material | Steel housing |
| Operating Temperature | 32°F to 104°F (0°C to 40°C) |
| Safety Certifications | UL, cUL, CE |
| Maintenance | Wipe with dry cloth; no user-serviceable parts |
| Cleaning Instructions | Unplug before cleaning; use a soft, dry cloth |
| Repairability | Non-repairable; replace if damaged |
| Spare Parts | None available; whole unit replacement |
| Additional Features | Power indicator, surge protection indicator, mounting brackets included |
Frequently Asked Questions - MPSH16-D20-120V Black Box
What is the maximum load for the Black Box MPSH16-D20-120V?
The maximum load is 20 A (2400 W at 120 V). Do not exceed this rating to avoid tripping the circuit breaker or causing damage.
Does the power strip provide surge protection?
Yes, it includes surge protection with an indicator light. If the light turns off, surge protection may be compromised.
What type of input plug does it use?
It typically uses a NEMA L5-20P twist-lock plug. Verify before installation.
Can this unit be mounted in a server rack?
Yes, it is 1U rack-mountable and includes mounting brackets for standard 19-inch racks.
How do I reset the circuit breaker?
Unplug the unit, press the reset button on the front panel, then plug back in. If it trips again, reduce the load.
What should I do if the surge protector indicator is off?
If the surge protection indicator light is off, surge protection is no longer active. The unit may still provide power, but we recommend replacing it.
Is the power strip compatible with a UPS?
Yes, it can be used with a UPS as long as the UPS output plug matches the input plug of the strip.
How do I clean the power strip?
Unplug the unit and wipe it with a soft, dry cloth. Do not use liquids or abrasive cleaners.
What safety certifications does it have?
It is UL and cUL listed, and CE compliant for safety.
Is the unit repairable if damaged?
No, the power strip is not designed to be repaired. If damaged, replace the entire unit.
