LTT10 - Charger Hamilton Buhl - Free user manual and instructions

Product Type	10-Port USB Charging Station
Brand	Hamilton Buhl
Model	LTT10
Input	AC 100-240V, 50/60Hz, Max 2A
Output	8 ports x 5V/2.1A, 2 ports x 5V/1A
Total Power	96W (12V/8A)
Compatible Devices	Smartphones (Apple, Samsung, etc.), tablets (iPad, Galaxy Tab, etc.), cameras, MP4 players
Power Cord Length	5 feet (1.5 m)
Dimensions (L x W x H)	13.77 x 7.87 x 2.75 inches (35 x 20 x 7 cm)
Weight	Approximately 3 lbs (1.36 kg)
Features	Power button, blue LED indicator, storage box for cable management, cradle to hold devices upright
Safety	UL certified power adapter with voltage and current overload protection; indoor use only; keep away from moisture
Warranty	1 year from date of shipment
Included Accessories	Charging station, power cable, user manual
Usage Environment	Indoor, dry locations such as offices, classrooms, conference rooms, hotels, hospitals
Maintenance	Wipe with dry cloth; do not expose to high temperature, moisture, or dampness
Repairability	Do not modify or alter; contact manufacturer for service; modifications void warranty
Device Capacity	Up to 10 devices simultaneously (depending on thickness; remove protective cases for fit)
Certifications	UL, CE (assumed based on UL adapter)
Tips	Charging station may warm up; unplug devices when fully charged to save energy

Frequently Asked Questions - LTT10 Hamilton Buhl

How many devices can I charge at once?

You can charge up to 10 devices simultaneously using the 10 USB ports.

What are the power outputs of the USB ports?

8 ports provide 5V/2.1A (for tablets) and 2 ports provide 5V/1A (for smartphones).

Is the charging station safe for my devices?

Yes, it includes a UL certified power adapter with built-in voltage and current overload protection.

Can I charge an iPad or other tablets?

Yes, the 2.1A ports are compatible with most tablets, including iPad, Samsung Galaxy Tab, and Lenovo.

Does it include a power adapter?

Yes, a UL certified power adapter with a 5-foot cord is included.

How should I clean the charging station?

Wipe with a dry cloth. Avoid exposure to high temperature, moisture, or dampness.

Can I use it outdoors?

No, it is designed for indoor use only. Keep it away from moisture and high temperature.

What is the warranty period?

Hamilton Buhl offers a 1-year warranty from the date of shipment.

How do I register my product?

Visit www.HamiltonBuhl.com, click on Customer Care, then Product Registration, and fill out the required fields.

Can I charge different devices at the same time?

Yes, you can charge a mix of smartphones, tablets, cameras, and other USB-powered devices simultaneously.

USER MANUAL LTT10 Hamilton Buhl

10 Port USB Charging Station

Stacked smartphone charging station with network of cables, no visible text or symbols on devices

Never-Ending Learning Innovation

Introduction

This USB Charging station with 10 ports allows you to charge and store up to 10 digital devices simultaneously, like smartphones, tablets, cameras, from a single power outlet. Moreover, the button design saves you the troubles to plug and unplug your power cable after use. It is a perfect charging solution for offices, classrooms, conference rooms, airports, hospitals, hotel lobbies and public places.

Specifications

• Input: AC100-240V 50/60Hz, Max 2A
  • Output: 8 ports x 2.1A, 2 ports x 1A
• Support charge and store up to 10 digital devices simultaneously
• 5V/1A ports are compliant with the majority of cell phones such as Apple, Samsung, Blackberry, HTC, Microsoft, Huawei, Nokia, Kindle, Sony Ericsson, Nexus, etc
• 5V/2.1A ports are compliant with the majority of tablets such as Apple, Samsung, Lenovo, etc
• Put cables under the cradle to keep your desk neat
• UL power adapter included
  • Length of power cord: 5 foot
• Compact size: 13.77 (L) x 7.87 (W) x 2.75 (H) inches

Product Details

1. Power Button
2. LED Indicator
3. USB 5V/1A x 2

4. USB 5V/2.1 x 8

5. 5 Foot Power Cord

6. Storage Box
7. Cradle

How it Works

Instructions

Before charging please remove protective cover so unit can fit in slot.

1. Connect power cord to the charging station and wall outlet, then push on the power button; you will see a blue LED light indicating unit is on.

2. Connect your digital devices to charging station with your USB cable; You could put your charger cables into the storage box to keep your desk neat.

• Fold your USB charger cable; (as shown in figure 1)

①

Line drawing of a USB cable with two connectors (no text or symbols)

- Put the cable into the storage box under the cradle; (as shown in figure 2)

②

Line drawing of a portable electronic device with coiled cables and a speaker (no text or symbols)

• 5V/1A ports are compliant with the majority of cell phones such as Apple, Samsung, Blackberry, HTC, Microsoft, Huawei, Nokia, Kindle, Sony Ericsson, Nexus, etc

• 5V/2.1A ports are compliant with the majority of tablets such as Apple, Samsung, Lenovo, etc

• The Special cradle could hold your digital devices in order, like cell phones, MP4 and tablets, etc

• UL certified power adapter is included, with built-in voltage and current overload protection to keep your devices safe.

Warm Tips:

1. The charging station would generate heat as there is a process of charge and discharge while charging.
2. Please unplug your devices when fully charged to save power and protect your battery.

In the Box

• USB Charging Station 10 Ports x1
- Power Cable x1
- Manual x1

Notes

- Indoor use only, avoid exposure to high temperature, moisture or dampness

- Keep it out of the reach of infants and toddlers

- Untie the power cord when in use

- For your safety, wet hands are not allowed to touch power to avoid shock

- Do not use if it comes into contact with any liquid

- Any modifications or alterations by unprofessional persons are not permitted. This will void manufacture warranty.

Product Registration Instructions

Visit: www.HamiltonBuhl.com

1. Click on Customer Care
2. Click on Product Registration Icon
3. Please fill out all fields marked with * to register

Warranty:

Warranty begins the date item ships from our warehouse. All products, except for metal carts, have a one year warranty from original date of shipment, unless otherwise noted. Metal carts have a limited lifetime warranty on all housing components; however, carts have a one year warranty on any electrical / mechanical components.

Our Mission:

Since our founding in 1933, HamiltonBuhl continues to evolve as a leader in technology products for education and industry. Our products are embraced by educators, corporate trainers, presenters, government agencies, and hospitals for their daily presentation, from the classroom to the boardroom, HamiltonBuhl has the presentation product for you.

96W 10 ports USB Desktop Charger with 10 Slots (12V8A)

13 Hamilton Buhl

Never-Ending Learning Innovation

80 Little Falls Road

Fairfield, NJ 07004

1-800-631-0868

www.HamiltonBuhl.com
