| Product Type | Telescope (Ritchey-Chrétien Cassegrain) |
| Aperture | 304.8 mm (12 inches) |
| Focal Length | 2743 mm |
| Focal Ratio | f/9 |
| Optical Design | Ritchey-Chrétien |
| Primary Mirror Diameter | 12 inches (304.8 mm) |
| Secondary Mirror Obstruction | 34% (typical) |
| Tube Material | Carbon fiber |
| Tube Length | 28 inches (711 mm) |
| Weight (OTA only) | 70 lbs (31.8 kg) |
| Focuser | 2" Crayford-style dual speed |
| Finderscope | 8x50mm with illuminated reticle |
| Mount Compatibility | Vixen-style dovetail plate |
| Back Focus | 180 mm from rear cell |
| Cooling Fan | Yes, built-in |
| Dew Shield | Retractable |
| Maintenance | Collimation and optical cleaning as needed |
| Cleaning | Compressed air or optical cleaning kit |
| Safety | Never point at sun without proper solar filter |
| Spare Parts | Available from iOptron or authorized dealers |
| General Information | Designed for astrophotography and visual use |
Frequently Asked Questions - RC12 iOptron
How do I collimate the iOptron RC12?
Collimation should be done using a laser collimator or Cheshire eyepiece. Adjust the secondary mirror screws to center the laser spot, then fine-tune the primary mirror. The RC12 has adjustable primary mirror collimation screws at the rear.
What mount is recommended for the RC12?
A sturdy equatorial mount like the iOptron CEM70G or iEQ45 Pro is recommended. The RC12 weighs about 70 lbs, so a mount with a payload capacity of at least 100 lbs is advisable.
Can I use the RC12 for astrophotography?
Yes, the RC12 is designed for deep-sky astrophotography with its fast f/9 focal ratio and flat field. It works well with CCD and CMOS cameras. Use a field flattener or reducer for full-frame sensors.
How should I clean the mirrors?
Use compressed air to remove dust, then a optical cleaning kit with lens tissue and isopropyl alcohol. Avoid touching the mirror surface. For thorough cleaning, consult professional optical cleaning services.
What is the back focus distance?
The RC12 has a back focus of 180 mm from the rear cell. This allows plenty of space for filter wheels, OAG, and cameras. Adapters may be needed for specific setups.
Does the RC12 have a cooling fan?
Yes, it has a built-in cooling fan at the rear to help the primary mirror reach thermal equilibrium faster. Use it for best image quality during observing sessions.
How do I attach a camera to the RC12?
Use the 2-inch Crayford focuser with a camera adapter (e.g., T-ring and T-thread). The focuser has a 2-inch nosepiece compatible with standard accessories. For DSLR, attach a T-ring specific to your camera.
Is the tube made of carbon fiber?
Yes, the iOptron RC12 has a carbon fiber tube, which reduces weight and improves thermal stability. This minimizes focus shift due to temperature changes.
What eyepieces are recommended for the RC12?
High-quality eyepieces with long eye relief like Tele Vue Delos or Explore Scientific 82° are recommended. Start with a 20mm eyepiece for low power, and 5-10mm for high power.
How to prevent dew on the corrector plate?
Use a dew heater strip around the front cell connected to a dew controller. Alternatively, a dew shield (extended) can delay dew formation. The built-in retractable dew shield helps but may not be sufficient in humid conditions.
