Rock RS5 Coral Pro - Pregnant Niles - Free user manual and instructions
Find the device manual for free Rock RS5 Coral Pro Niles in PDF.
Pick your language and provide your email: we'll send you a specifically translated version.
| Product Type | Outdoor Rock Speaker |
| Brand | Niles |
| Model | Rock RS5 Coral Pro |
| Color | Brown / Coral (Stone-like) |
| Dimensions (H x W x D) | 12.5 x 8.5 x 8.5 inches (318 x 216 x 216 mm) |
| Weight | 11.5 lbs (5.2 kg) |
| Speaker Configuration | 2-way |
| Woofer Size | 5.25 inches (133 mm) |
| Tweeter Size | 1 inch (25 mm) aluminum dome |
| Power Handling (Continuous) | 100 Watts |
| Power Handling (Peak) | 200 Watts |
| Impedance | 8 Ohms |
| Frequency Response | 80 Hz – 20 kHz |
| Sensitivity (1W/1m) | 89 dB |
| Weatherproof Rating | IP66 (dust-tight, protected against powerful water jets) |
| Enclosure Material | High-density polyethylene with UV-stable paint |
| Mounting Type | Ground-mount (in-ground or on pedestal) |
| Connection Type | Spring-loaded terminals (accepts up to 12 AWG wire) |
| Recommended Amplifier Power | 20 – 150 Watts per channel |
| Input Impedance | 8 Ohm (nominal) |
| Coverage Angle | 130 degrees (wide dispersion) |
| Warranty | 5 years (limited) |
| Included Accessories | Mounting bracket, ground stake, paint mask, manual |
Frequently Asked Questions - Rock RS5 Coral Pro Niles
How do I wire the Rock RS5 Coral Pro speaker to my amplifier?
Use outdoor-rated speaker wire (14-12 AWG). Strip 1/2 inch of insulation and insert into the spring-loaded terminals. Ensure proper polarity (red to +, black to -). Do not bury the wire splice; use waterproof connectors.
Is the speaker truly weatherproof? Can I leave it outside year-round?
Yes, it has an IP66 rating, meaning it is dust-tight and protected against powerful water jets. It can withstand rain, snow, and sun exposure. However, avoid submerging it in water.
What is the best way to mount the Rock RS5 Coral Pro?
The speaker can be mounted on the included ground stake or a pedestal. For in-ground mounting, dig a hole, place the stake, and fill with concrete. Ensure the speaker is level and at least 6 inches above ground to avoid moisture buildup.
Can I use this speaker with a low-power amplifier?
Yes, the speaker is efficient at 89 dB sensitivity and works well with amplifiers from 20-150 Watts per channel. Even low-power amplifiers can drive it to moderate listening levels.
What type of sound quality can I expect from this outdoor rock speaker?
The 5.25 inch woofer and 1 inch aluminum dome tweeter deliver a balanced sound with clear highs and decent bass. Frequency response is 80 Hz – 20 kHz. It is designed for background music and vocal clarity in outdoor spaces.
How far can I place the speaker from my amplifier?
Use 14 AWG wire for runs up to 50 feet, 12 AWG for up to 100 feet. Beyond that, consider a higher gauge or a powered speaker. The 8 Ohm impedance allows longer runs without significant signal loss.
Does the Rock RS5 Coral Pro come with a warranty?
Yes, Niles provides a limited 5-year warranty against defects in materials and workmanship. Register your product on the Niles website for full coverage.
Can I paint the speaker to match my landscaping?
Yes, the enclosure is paintable with any high-quality exterior spray paint. Clean the surface, mask the grille and terminals, and apply light coats. Avoid painting the driver or tweeter.
What is the difference between the Rock RS5 Coral Pro and other Niles rock speakers?
The Coral Pro features a higher sensitivity (89 dB vs 87 dB on standard RS5) and an upgraded tweeter for better high-frequency dispersion. The 'Coral' color blends better in sandy or desert environments.
How do I clean and maintain the speaker?
Wipe with a damp cloth and mild soap. Do not use abrasive cleaners or pressure washers. Ensure the grille is free of debris and spiderwebs. Check terminals for corrosion annually and apply dielectric grease if needed.
