| Product Type | In-Wall Speaker |
| Brand | Niles |
| Model | DS7Si |
| Woofer Size | 7 inch polypropylene cone |
| Tweeter Size | 1 inch silk dome |
| Frequency Response | 40 Hz - 20 kHz |
| Impedance | 8 ohms nominal |
| Power Handling | 5 - 125 watts RMS |
| Sensitivity | 88 dB (1W/1m) |
| Crossover Type | 2-way sealed |
| Overall Dimensions (H x W x D) | 14.5 x 10.5 x 3.5 inches |
| Cutout Dimensions (H x W) | 12.5 x 8.5 inches |
| Weight | 5.5 lbs (2.5 kg) |
| Grille | Paintable, white aluminum mesh |
| Mounting | In-wall with included template and clamps |
| Wiring | Terminal cups with spring-loaded connectors |
| Recommended Use | Home theater or distributed audio system |
| Indoor/Outdoor | Indoor only (not weather-resistant) |
| Cleaning Instructions | Wipe grille and frame with a dry, soft cloth. Do not use liquid cleaners. |
| Safety Warnings | Turn off amplifier before wiring. Ensure secure mounting to avoid falling. |
| Spare Parts Availability | Contact Niles customer service for replacement drivers or grilles. |
| Warranty | Limited lifetime warranty (details in manual) |
Frequently Asked Questions - DS7Si Niles
What is the Niles DS7Si speaker used for?
The Niles DS7Si is a 2-way in-wall speaker designed for high-performance home theater or distributed audio systems.
Does the DS7Si require a separate amplifier?
Yes, it is a passive speaker and needs an external amplifier or receiver with 8-ohm capability.
Can the grille be painted?
Yes, the grille is paintable. Use thin, even coats of spray paint specifically formulated for speaker grilles.
What is the cutout size for installation?
The required cutout is 12.5 inches high by 8.5 inches wide (31.8 x 21.6 cm).
How do I connect the speaker wires?
Use the spring-loaded terminals on the back. Strip 1/4 inch of insulation, press the terminal, insert wire, and release.
Can I use this speaker outdoors?
No, the DS7Si is designed for indoor use only. Exposure to moisture may damage it.
What is the recommended amplifier power?
An amplifier with 5 to 125 watts RMS per channel at 8 ohms is recommended.
Is the speaker magnetic shielded?
No, this speaker is not magnetically shielded. Keep it at least 2 feet away from CRT TVs or monitors.
How do I clean the DS7Si?
Remove the grille and clean it with a dry, soft cloth. Wipe the speaker frame gently. Avoid liquid cleaners.
Where can I find replacement parts?
Contact Niles customer service or visit their website for replacement drivers, grilles, or mounting hardware.
