1408 - Sewing machine ALFA - Free user manual and instructions

Product type	Sewing machine
Brand	Alfa
Model	1408
Dimensions (approx.)	40 x 18 x 30 cm
Weight (approx.)	6.5 kg
Power supply	220-240 V, 50/60 Hz
Power consumption	85 W
Number of stitch patterns	8
Stitch length adjustment	0-4 mm
Stitch width adjustment	0-5 mm
Built-in buttonhole	1-step automatic
Free arm	Yes
Top drop-in bobbin	Yes
Needle threader	Manual
Speed control	Foot pedal variable speed
Reverse stitch	Yes
Motor type	Electric, AC motor
Light bulb	LED, 1.5 W
Accessories included	Foot pedal, bobbins, needles, seam ripper, screwdriver, oil
Maintenance	Clean lint regularly; oil moving parts after 10 hours of use
Safety features	Power switch, thermal overload protection
Spare parts availability	Contact Alfa service center or authorized dealer
Warranty	2 years
Repair	Do not attempt self-repair; contact qualified technician

Frequently Asked Questions - 1408 ALFA

How do I thread the Alfa 1408 sewing machine?

First, raise the presser foot. Place a spool on the spool pin, draw thread through the top thread guide, then down into the tension discs. Pull up through the take-up lever, then down to the needle. Thread the needle from front to back. Ensure the thread is between the tension discs.

How do I adjust the thread tension?

Turn the tension dial to a higher number for tighter tension (thicker fabric) and lower number for looser tension (thinner fabric). Test on a scrap piece. The correct tension makes balanced stitches with no loops.

Why does my machine skip stitches?

Possible causes: bent or dull needle, incorrect needle size, improper threading, or lint buildup. Replace the needle, rethread, and clean the machine. Ensure the needle is inserted correctly with the flat side facing back.

How do I wind the bobbin on the Alfa 1408?

Place the bobbin on the winder spindle. Guide thread from spool to bobbin winding tension disc, then around the bobbin a few times. Push the winding lever to start. The machine will stop automatically when full. Do not overwind.

How do I change the needle?

Turn off the machine. Loosen the needle clamp screw with the screwdriver. Remove old needle. Insert new needle with the flat side facing back and the groove facing front. Push up as far as possible and tighten the screw securely.

What type of oil should I use and how often?

Use a high-quality sewing machine oil. Apply 1-2 drops on the moving parts indicated in the manual (usually the hook assembly and needle bar) after every 10 hours of use. Wipe excess oil. Do not over-oil.

Why is the bobbin thread bunching up underneath?

This is usually due to incorrect upper tension. Adjust the upper tension dial. Also check that the bobbin is inserted correctly and the thread is properly wound. Clean the bobbin area of lint.

How do I clean the sewing machine?

Turn off and unplug. Remove the needle plate and clean lint with a small brush or vacuum. Do not use compressed air as it pushes lint deeper. Oil after cleaning. Wipe the exterior with a dry cloth.

Can I sew denim or thick fabrics with the Alfa 1408?

Yes, but use a heavy-duty needle (size 16 or 18) and adjust tension accordingly. For multiple layers, sew slowly and consider using a walking foot if available. Test on a scrap first.

Where can I find spare parts for the Alfa 1408?

Contact Alfa customer service or visit an authorized dealer. Parts such as bobbins, needles, and presser feet are standard and available online. Always use genuine parts for best performance.

USER MANUAL 1408 ALFA

Simple line drawing of a telephone connected to a wall-mounted device via cable (no text or symbols)

Two technical line drawings of a mechanical device with dashed arrows indicating motion or force direction (no text or symbols)

Mechanical assembly diagram showing a motor or gear mechanism with no visible text or symbols

installation

Technical line drawing of a mechanical clamp or tool with a tool inserted, showing no text or symbols.

Technical line drawing of a mechanical device with no visible text or symbols

Extraction

Cambio del Pice Pensionales

Technical line drawing of a mechanical assembly with directional arrows indicating motion (no text or symbols)

cian muy Sevilla

El sup emento del brazo libre ajade a este uma mayor suprifice de trabajo, situó su extiaco-

Diagram of a mechanical tool with a screw and gear mechanism (no text or symbols)

Diagram of a mechanical assembly with a tool and component, no visible text or symbols

Line drawing of a hand holding a circular object with an arrow indicating direction (no text or symbols)

Pure mechanical diagram showing a circular component with two protruding arms and a central shaft (no text or symbols)

Illustration of a hand using a tool to adjust or install a mechanical component (no text or symbols visible)

Diagram of a mechanical assembly with arrows indicating motion direction (no text or symbols)

Illustration of hands assembling a mechanical component (no text or symbols visible)

Illustration of a hand holding a small device with a circular head and a downward arrow indicating motion (no text or symbols)

Line drawing of a hand holding a small object with a pointed tip, no text or symbols present

Illustration of a hand holding a tool with a numbered label (3) and motion lines, no text or symbols present.

Simple line drawing of a folded paper or sheet with zigzag lines and a wavy pattern on the side (no text or symbols)

Diagram of a mechanical device with an arrow indicating rotation or movement (no text or symbols present)

Line drawing of a mechanical lever or lever device (no text or symbols)

Simple line drawing of a mechanical device with no text or symbols

Illustration of hands using a compass to adjust a mechanical component, with an inset showing the circular detail of the component (no text or symbols present)

Simple line drawing of a mechanical or architectural component with no visible text, numbers, or symbols.

Placa Zurciodora

Linaes Guías de Costa

Line drawing of a sewing machine needle with base mount and support structure (no text or symbols)

Technical line drawing of a mechanical assembly with a curved component and a valve (no text or symbols)

Line drawing of a sewing machine needle stitching a fabric (no text or symbols)

Technical line drawing of a mechanical clamp or clamp device (no text or symbols)

Presetales de zig-zag

Technical line drawing of a mechanical device with no visible text or symbols

Presetales de zig-zag

Line drawing of a mechanical device with ladder and lever components (no text or symbols)

Presales de zig-zag

Technical line drawing of a mechanical device with a spring-loaded base and lever mechanism (no text or symbols)

Presetales de zig-zag

Line drawing of a sewing machine needle stitching fabric (no text or symbols)

Simple line drawing of a mechanical joint or bracket (no text or symbols)

Simple line drawing of a hand holding a piece of paper or tool, no text or symbols present

Mechanical assembly diagram showing a tool with arrows indicating motion direction (no text or symbols)

Diagram of a sewing machine needle with arrows indicating force direction (no text or symbols)

Line drawing of a sewing machine needle and foot (no text or symbols)

Simple line drawing of two identical circular objects with horizontal lines, no text or symbols present

Line drawing of a mechanical clamp or clamping device with no visible text or symbols

Technical line drawing of a mechanical device with no visible text or symbols

Technical line drawing of a mechanical linkage or support system (no text or symbols)

Technical line drawing of a sewing machine (no text or symbols visible)

Diagram of a sewing machine with a spring scale and base, no text or symbols present

Line drawing of a sewing machine needle and fabric swatch, no text or symbols present

Simple line drawing of a mechanical spring-loaded tool with no text or symbols

Diagram showing two folded paper sheets with a scroll and directional arrow, no text or symbols present

Technical line drawing of a mechanical linkage or lever assembly (no text or symbols)

pensates

Technical line drawing of a mechanical device with a paper sheet and a clamp, no text or symbols present

Line drawing of a sewing machine needle stitching fabric (no text or symbols)

Technical line drawing of a mechanical clamp or bracket assembly with no visible text or symbols

Technical line drawing of a mechanical assembly with no visible text or symbols

Technical line drawing of a mechanical assembly with a crescent-shaped component and tool interacting (no text or symbols)

la de la anzadora.

Technical line drawing of a mechanical assembly with no visible text or symbols

MANTENIMIEMTO

Line drawing of a hand operating a mechanical device with no visible text or symbols
