4GV815E - Freezer LYNX - Free user manual and instructions

Product Type	Chest Freezer
Brand	Lynx
Model	4GV815E
Total Capacity	150 L
Freezing Capacity	10 kg / 24 h
Energy Efficiency Class	A+
Annual Energy Consumption	220 kWh
Climate Class	SN-N
Noise Level	42 dB
Dimensions (W x D x H)	600 x 600 x 850 mm
Weight	35 kg
Power Supply	220-240 V, 50 Hz
Refrigerant	R600a
Defrost Type	Manual
Temperature Control	Mechanical dial
Interior Light	No
Door Lock	Yes
Adjustable Feet	Yes
Baskets Included	1 wire basket
Low Frost Technology	No
Spare Parts Availability	7 years
Repairability	User-replaceable thermostat, door gasket, hinges
Key Accessories	Ice cube trays (optional)

Frequently Asked Questions - 4GV815E LYNX

How do I set the temperature on my Lynx 4GV815E freezer?

Use the mechanical dial inside the freezer. Typically, a number from 1 (warmest) to 7 (coldest) controls the thermostat. Start at a medium setting and adjust as needed.

How often should I defrost the freezer?

Defrost when frost buildup reaches about 5 mm (0.2 inches). Depending on usage and humidity, this could be every 6 to 12 months. Plan ahead and move food to a cooler bag.

What is the energy consumption of the 4GV815E?

The annual energy consumption is approximately 220 kWh. Actual consumption varies based on temperature settings, door openings, and ambient temperature.

Can I install the freezer in an unheated garage?

Yes, if the ambient temperature stays within the climate class SN-N range (+10°C to +32°C). In very cold conditions, the compressor may not run, risking food thaw.

How do I clean the freezer?

Unplug the freezer, defrost completely. Wipe interior with a solution of mild detergent and warm water. Rinse and dry thoroughly before reconnecting.

What should I do if the freezer is too noisy?

Check if it's level using the adjustable feet. Ensure it's not touching walls or cabinets. Noise up to 42 dB is normal. If unusual sounds continue, contact service.

Does the freezer have a lock?

Yes, the door lock is included for added security. Use the provided key to lock/unlock. Always remove the key to prevent accidental lock-in of children.

How long can I store food in case of power failure?

The freezer will keep food frozen for about 24 hours if left unopened. Avoid opening the lid during the outage.

How do I change the light bulb?

This model does not have an interior light. Use a flashlight or external lighting when accessing the contents.

Where can I get spare parts or service?

Contact Lynx authorized service centers or visit the official website. Common parts like handles, hinges, thermostat, and door gaskets are available for 7 years after purchase.

USER MANUAL 4GV815E LYNX

ES Indice

4

5

7

527580
