3FCL1452 - Refrigerator BALAY - Free user manual and instructions
Find the device manual for free 3FCL1452 BALAY in PDF.
Pick your language and provide your email: we'll send you a specifically translated version.
| Product Type | Freestanding Refrigerator |
| Brand | Balay |
| Model | 3FCL1452 |
| Total Gross Capacity | Approx. 320 L |
| Refrigerator Capacity | Approx. 250 L |
| Freezer Capacity | Approx. 70 L |
| Energy Class | E (EU 2010) |
| Annual Energy Consumption | Approx. 220 kWh |
| Noise Level | Approx. 42 dB(A) |
| Climate Class | SN-ST (10°C to 38°C) |
| Dimensions (H x W x D) | 185.0 x 60.0 x 65.0 cm |
| Weight | Approx. 62 kg |
| Power Supply | 220-240 V, 50 Hz |
| Number of Shelves (Refrigerator) | 4 adjustable glass shelves |
| Vegetable Drawer | 1 with humidity control |
| Door Bins (Refrigerator) | 3 |
| Freezer Drawers | 3 |
| Ice Cube Tray | 1 included |
| Cooling System | Static (fan-assisted in some models) |
| Defrosting | Automatic (refrigerator), manual (freezer) |
| Reversible Door | Yes |
| Controls | Mechanical thermostat |
| Interior Light | LED |
| Refrigerant | R600a (isobutane) |
| Spare Parts Availability | Yes, via Balay/BSH service |
Frequently Asked Questions - 3FCL1452 BALAY
How do I set the temperature on my Balay 3FCL1452 fridge?
Use the mechanical thermostat dial inside the refrigerator compartment. Typically, a higher number (e.g., 5) means colder. Adjust as needed, but avoid setting too cold to prevent freezing fresh food. The recommended temperature is around 4°C for the fridge and -18°C for the freezer.
What is the energy consumption of this model?
The Balay 3FCL1452 is rated energy class E with an estimated annual consumption of about 220 kWh. Actual consumption depends on usage, ambient temperature, and door openings.
Is the freezer defrost automatic?
No, the freezer compartment requires manual defrosting. When ice builds up (approx. 3-5 mm), unplug the appliance, remove food, and let the ice melt. Do not use sharp tools to remove ice.
How do I change the door opening direction?
The door is reversible. You will need a screwdriver and possibly a helper. Refer to the user manual for detailed steps: remove hinges, transfer hinge components to the opposite side, and rehang the door. Ensure the appliance is unplugged during the process.
What does the red light mean on the control panel?
If your model has a red warning light, it typically indicates a temperature alarm (e.g., door left open or failure). Check if the door is closed properly and the temperature is within range. If it persists, contact service.
How often should I clean the condenser?
The condenser (located at the back or bottom) should be cleaned at least once a year to maintain efficiency. Use a vacuum cleaner or soft brush. Unplug the appliance first.
Can I store hot food in the fridge?
No, allow hot food to cool to room temperature before placing it in the fridge. Hot food raises the internal temperature and can spoil other items or overwork the compressor.
Why is my fridge making unusual noises?
Normal sounds include a humming compressor, occasional clicking (thermostat), and gurgling from refrigerant flow. If a loud buzzing or rattling occurs, check if the appliance is level and clean the condenser. Persistent unusual sounds may require service.
What spare parts are available for this model?
Common spare parts include door gaskets, shelves, thermostat, temperature regulator, light bulb/LED, and hinges. They can be ordered through Balay authorized service centers or online spare parts shops.
Is the refrigerator suitable for outdoor use?
No, the climate class is SN-ST (10°C to 38°C). It is not designed for outdoor or unheated spaces where temperatures may drop below 10°C or exceed 38°C.
User questions about 3FCL1452 BALAY
0 question about this device. Answer the ones you know or ask your own.
Ask a new question about this device
No questions yet. Be the first to ask one.
Download the instructions for your Refrigerator in PDF format for free! Find your manual 3FCL1452 - BALAY and take your electronic device back in hand. On this page are published all the documents necessary for the use of your device. 3FCL1452 by BALAY.
USER MANUAL 3FCL1452 BALAY
Figuras 1
Fig. 1
1Selectordetemperatura
2Interruptordaluz
3luminação interior
1Διακόπτηςφωτισμού
Resim 1
7
8
9
BSHELECTRODOMÉSTICOS,S.A.
C/Itaroa,n°1
31620Huarte
Pamplona(NAVARRA)
A-28-893550
9000348225(8803)es/pt/el/tr
