Product Type	Refrigerator
Brand	Balay
Model	3FIB3620
Height	1800 mm
Width	600 mm
Depth	650 mm
Weight	72 kg
Power Supply	220-240 V, 50 Hz
Energy Class	A+
Annual Energy Consumption	150 kWh
Noise Level	42 dB(A)
Refrigerant	R600a (isobutane)
Climate Class	SN, N, ST
Temperature Control	Mechanical thermostat
Shelves	3 adjustable glass shelves
Vegetable Drawer	1 humidity-controlled drawer
Door Storage	4 door balconies
Defrosting	Automatic defrost
Reversible Door	Yes
Cleaning	Wipe with mild detergent and water
Spare Parts Availability	Contact Balay service center or authorized dealer
Safety Features	Stabilizer feet, door alarm (optional)

Frequently Asked Questions - 3FIB3620 BALAY

How do I adjust the temperature on my Balay 3FIB3620 refrigerator?

Turn the thermostat dial located inside the refrigerator compartment. Usually, a higher number means colder temperature. Set to medium for normal operation.

How do I defrost the freezer?

This model features automatic defrost. However, if ice builds up, you can manually defrost by unplugging the appliance and leaving the door open. Remove ice manually and dry the interior before restarting.

What should I do if the refrigerator is not cooling properly?

Check that the thermostat is set correctly, the door is fully closed, and the condenser coils are clean. Also ensure there is adequate ventilation around the appliance.

How often should I clean the condenser coils?

Clean the coils every 6 months using a vacuum cleaner or soft brush. This improves efficiency and prevents overheating.

Can I reverse the door opening direction?

Yes, the door is reversible. Refer to the user manual for step-by-step instructions. You will need a screwdriver and possibly a helper.

What types of food can I store in the vegetable drawer?

The vegetable drawer is designed for fruits and vegetables. The humidity control helps keep produce fresh. Keep leafy greens and sensitive items in this drawer.

How do I change the interior light bulb?

Unplug the refrigerator. Remove the light cover gently and replace the bulb with a similar type (usually an LED module or incandescent bulb of max 15W). Reattach the cover and plug back in.

Is the Balay 3FIB3620 energy efficient?

Yes, it has an A+ energy rating, consuming about 150 kWh per year. To maintain efficiency, keep the door closed and avoid placing hot food inside.

What does the 'SN, N, ST' climate class mean?

This means the refrigerator is suitable for ambient temperatures between 10°C and 38°C. It can operate in a wide range of climates, from temperate to subtropical.

Where can I download the user manual?

You can download the manual for free from notice-facile.com or the Balay official website. The manual is available in PDF format.

USER MANUAL 3FIB3620 BALAY

2

Diagram of a window with raindrops falling into the floor, showing no text or symbols

3 4

Illustration of a hand placing a tray with liquid and a curved arrow indicating flow or movement (no text or symbols)

Diagram of a multi-level mechanical or architectural structure with directional arrows indicating movement (no text or symbols)

5

Line drawing of a refrigerator interior showing two shelves and a door handle (no text or symbols)

6

Diagram of a mechanical device with labeled component A, showing a cylindrical component inserted into a base plate (no text or symbols beyond label)

7

Mechanical assembly diagrams showing two views of a cylindrical device with internal components and directional arrows indicating movement (no text or symbols)

The Ground Truth image displays a single, solid horizontal line. According to Rule 2 (UNDERSCORE & LINE RULES), this is a stylistic or background line, not a placeholder underscore. Therefore, the OCR result must ignore it and output nothing or only meaningful text. The provided OCR content is "____", which consists of four underscores. This is an incorrect interpretation of the line as a fill-in-the-blank placeholder, violating the rule that stylistic lines must be ignored. The OCR has hallucinated underscores where none should exist based on the GT's visual context. Hence, the OCR result is inconsistent with the Ground Truth.

8

BSHELECTRODOMÉSTICOS,S.A.

C/Itaroa,n°1

31620Harte

Pamplona(NAVARRA)

A-28-893550

9000124999(8601)es/pt/el/tr
