Portland Air 400 - Tent Vango - Free user manual and instructions

Brand	Vango
Model	Portland Air 400
Product Type	4-person inflatable tent
Pitched Dimensions (L x W x H)	440 x 240 x 195 cm
Packed Dimensions (L x W x H)	75 x 45 x 40 cm
Weight	16.5 kg
Capacity	4 persons + room for gear
Flysheet Material	Polyester 75D 190T with waterproof coating
Inner Tent Material	Breathable polyester
Groundsheet Material	Polyethylene (PE)
Hydrostatic Head (Flysheet)	4000 mm
Hydrostatic Head (Groundsheet)	6000 mm
Poles / Beams	Vango AirBeam® inflatable tubes
Pump Type	Included double-action pump
Ventilation	Diamond Clear windows with mesh panels
Doors	1 main door, 1 secondary door
Windows	2 large windows with roll-up curtains
Pegs	14x Vango rock pegs
Guy Ropes	8x reflective guylines
Setup Type	Inflatable (AirBeam®)
Color	Green / Grey
Warranty	1 year

Frequently Asked Questions - Portland Air 400 Vango

How do I inflate the Vango Portland Air 400?

Use the included double-action pump to inflate each AirBeam® tube. Ensure all valves are closed before pumping. Do not over-inflate; stop when the beam is firm but not rock hard.

What is the recommended inflation pressure?

The recommended pressure is around 8-9 PSI (0.55-0.62 bar). Use the pressure gauge if available.

How do I deflate and pack the tent?

Open all valves fully to release air. Flip the tent over and press down to expel remaining air. Roll towards the beams to remove air. Pack in the carry bag provided.

Can I repair a puncture in the air beams?

Yes, use a Vango repair kit. Clean the area, apply adhesive patch, and allow 24 hours to cure before inflation.

Is the tent waterproof?

Yes, the flysheet has a hydrostatic head of 4000 mm and the groundsheet 6000 mm, making it highly water resistant.

How many people can sleep comfortably?

The tent is designed for 4 adults in separate sleeping compartments or a family of 2 adults and 2 children.

Are the windows ventilated?

Yes, the Diamond Clear windows have mesh panels that can be opened for ventilation while keeping insects out.

How do I clean the tent?

Use mild soap and cold water. Avoid washing machines. Rinse thoroughly and air dry before storing.

Can I use the tent in windy conditions?

The tent is stable but always pitch with the main entrance facing away from the wind. Use all guy ropes and pegs for extra security.

What is the packed size?

The packed dimensions are approximately 75 x 45 x 40 cm, weighing 16.5 kg.

USER MANUAL Portland Air 400 Vango

③
Airspeed®

B.

C.

i.
TBS®II

iii.

EN - This tent should be erected by at least 2 people
CZ - Tonto stan by měl být postaven nejměně 2 osoby
DE - Dieses Zelt sollte von mindestens zwei Personen aufgestellt werden
FR - Cette tente doit être érigée par au moins 2 personnes
IT - Questa tenda deve essere eretto da almeno 2 persone
NL - Deze tent moet worden omgeven door minstens 2 personen

B.

C.

Vango makes every effort to ensure the accuracy of our information. We do however have a policy of continuous improvement and we therefore reserve the right to change or amend colours and specifications without prior notice. ©AMG Group Ltd.
