712 - Sewing machine Anker-Bernette - Free user manual and instructions

Product Type	Sewing Machine
Brand	Anker-Bernette
Model	712
Dimensions (approx.)	42 x 18 x 30 cm
Weight (approx.)	7.5 kg
Power Supply	220-240V, 50-60 Hz
Power Consumption	90 W
Stitch Types	12 built-in stitches including straight, zigzag, and decorative
Buttonhole	4-step automatic
Needle Threader	Built-in automatic needle threader
Bobbin Winding	Automatic winding with stop
Stitch Length & Width	Adjustable
Presser Foot Pressure	Adjustable
Feed Dogs	Drop feed system for free-motion sewing
Lighting	LED sewing light
Free Arm	Yes, for cuffs and sleeves
Included Accessories	Needles (3 sizes), bobbins (3), seam ripper, screwdriver, oil bottle, soft cover
Maintenance	Clean lint regularly; oil as per manual; store in dry place
Safety	Disconnect power when cleaning; keep away from children; use only original parts
Spare Parts Availability	Common parts available online; use authorized Anker-Bernette service
Repairability	User-replaceable needle plate, presser foot, light bulb; contact service for motor or electronics
Certifications	CE, RoHS

Frequently Asked Questions - 712 Anker-Bernette

How do I thread the Anker-Bernette 712 sewing machine?

Raise the presser foot. Turn the handwheel to raise the needle. Follow the numbered thread guides on the machine. Pass the thread through the tension disc, then the take-up lever from right to left. Finally, thread the needle from front to back. Use the automatic needle threader for ease.

How do I adjust the stitch tension?

The tension dial is numbered from 0 to 9. For normal sewing (straight stitch), set it to 4. Increase for tighter tension (thicker fabric), decrease for looser (thin fabric). Test on a scrap piece.

How do I replace the needle?

Turn off the machine. Loosen the needle clamp screw with the screwdriver. Remove the old needle and insert a new one with the flat side facing away from you. Push it up as far as it goes, then tighten the screw.

Why is the machine skipping stitches?

Common causes: a bent or blunt needle, incorrect needle type/thread combo, improper threading, or lint buildup. Replace the needle, re-thread, and clean the bobbin area.

How do I clean and maintain the machine?

After every project, remove the needle plate and clean the feed dogs and shuttle area with the brush. Oil the machine as per the manual (typically every 8-10 hours of use). Keep the machine covered when not in use.

How do I wind the bobbin?

Place the bobbin on the winder spindle. Guide the thread from the spool to the bobbin winder tension disc. Push the winder to the right. Hold the tail and start the machine; it will stop automatically when full.

What types of fabric can I sew with this machine?

The 712 can handle lightweight to medium-weight fabrics: cotton, silk, polyester, linen, jersey. For heavy denim or multiple layers, use a denim needle and reduce speed.

How do I sew a buttonhole?

Use the 4-step buttonhole lever. Set the stitch selector to buttonhole. Place the button in the holder. Sew the first side, stop, press the lever, sew the second side, stop, press again for the front bar, and finally sew the back bar.

What should I do if the machine jams?

Turn off the machine. Remove the fabric gently (do not pull). Open the bobbin cover and remove the bobbin. Cut any tangled threads. Re-thread the machine and start again.

Where can I find spare parts or accessories?

Authorized Anker-Bernette dealers and online retailers carry needles, bobbins, presser feet, and belts. For internal parts, contact customer service. Use only genuine Anker-Bernette parts.

USER MANUAL 712 Anker-Bernette

Problem? Contact your dealer.

Mount the lampshade and screw it tight.

Minimum

Maximum.

www.matri.nl Matri Naaimachine specialists since 1929 Lange Bisschopsstraat 9 7411 KG Deventer Tel.: 0570 - 61 63 83 www.lockmachine.info

ATTENTION:

Matri Naaimachine

www.matri.nl Matri Naaimachine specialists since 1929 Lange Bisschopsstraat 9 7411 KG Deventer Tel.: 0570 - 61 63 83 www.lockmachine.info

7411 KG Deventer 13 Tel.: [phone] www.lockmachine.info Matri Naaimachine specialists since 1929 Lange Bisschopsstraat 9 www.matri.nl

Material	Garn	Nod.	Naid- system	Bewarkan	Garn	Naid No.	Named system
fine station	gamerc. garan 60-80	70	130/705	stopper, sukken inzetten, versellen stopparin 30-50	borduur-en	70-90	130/705
dune en station, katoon, jersey	gamerc. garan	80	130/705	karen, mono-grammen maken	stopgeren	30-50
dicka station lodan, tweed ibfluwerl	gamerc. garan 50-60	90	130/705	130/705 HJ (jeans)	doorlikaden	koopsgaten	100-120
stavige en frande station, jeans, hinnan	gamerc. garan 50-60	100	130/705 HJ (jeans)	doorlikaden	koopsgaten stopparin	70-90	130/705
synthelische en elasisthe stof-zitzen jersey	synthelisch garan	90	130/705 HS (stretch)	koopsgaten	borduur-en stopparin 30-50	70-90	130/705
leder, kunsteder	gamerc. of synthetisch garan 50-70	80-100	130/705 L (leases)

AUTOMATIC THREADER (729E, 829E, 815E)

(729, 729E, 829, 829E)

1. THREE NEEDLE POSITIONS

STITCH INDICATOR (DISPLAY) + COLOR CODE Models: 729, 729E, 829, 829E

STITCH INDICATOR (DISPLAY) + COLOR CODE Models: 712, 715, 812, 815

3-button models

TRIPLE STRAIGHT STITCH Model 729(E), 829(E)

2-button models

Model 729(E), 829(E)

2-button models

2-knops

BLINDZOOM

bevindt.

gestoren blijft.

www.matri.nl

www.matri.nl Matri Naaimachine

www.matri.nl Matri Naaimachine specialisten sinds 1929 Lange Bisschopsstraat 9 7411 KG Deventer Tel.: 0570 - 61 63 83 www.lockmachine.info

40

www.lockmachine.info specialisten sinds 1929 Lange Bisschopsstraat 9 7411 KG Deventer Tel.: [phone] www.lockmachine.info

www.matri.nl Matri Naaimachine specialisten sinds 1929 Lange Bisschopsstraat 9 7411 KG Deventer Tel.: 0570 - 61 63 83 www.lockmachine.info

vergrendeling. Schoonmaken
