| Product Type | Network Management Card |
| Model | RMCARD302 |
| Compatible UPS | CyberPower UPS with SNMP/network slot |
| Network Interface | RJ-45 Ethernet (10/100 Mbps) |
| Management Protocols | SNMP v1/v2c/v3, HTTP/HTTPS, SSH, Telnet |
| Monitoring Capabilities | Voltage, current, frequency, power, temperature, humidity |
| Alert Methods | Email, SNMP traps, Syslog, SMS (via external modem) |
| Supported Operating Systems | Windows, macOS, Linux, VMware ESXi |
| Power Supply | Powered by UPS via internal connector |
| Dimensions (L x W x H) | Approx. 110 x 70 x 25 mm |
| Weight | Approx. 100g |
| Operating Temperature | 0°C to 40°C |
| Storage Temperature | -15°C to 60°C |
| Humidity | 0% to 90% non-condensing |
| Safety Certifications | FCC, CE, RoHS |
| Package Contents | RMCARD302, quick start guide, CD with software |
| Warranty | 2 years limited |
Frequently Asked Questions - RMCARD302 CyberPower
How do I install the RMCARD302 in my CyberPower UPS?
Insert the card into the designated network management slot on the UPS. Secure with screws, connect Ethernet, and power on the UPS. The card will obtain an IP via DHCP.
How can I access the RMCARD302 web interface?
Find the card's IP address (via DHCP or using the PowerPanel software). Enter the IP in a web browser. Default login is 'admin' / 'admin'.
What monitoring features does the RMCARD302 support?
It monitors input/output voltage, current, frequency, power, battery status, temperature, and humidity (with optional sensor).
Can I receive email alerts from the RMCARD302?
Yes, configure SMTP settings in the web interface to send alerts for events like power failure, battery low, or overload.
Is the RMCARD302 compatible with all CyberPower UPS models?
It is compatible with UPS models that have an SNMP/network management slot. Check your UPS manual or CyberPower compatibility list.
How do I update firmware on the RMCARD302?
Download the latest firmware from CyberPower's website, log into the web interface, go to 'Maintenance' > 'Firmware Update', and upload the file.
Can I manage multiple RMCARD302 cards from one console?
Yes, use CyberPower PowerPanel Business Edition or an SNMP NMS to manage multiple cards centrally.
What security features are available on the RMCARD302?
Supports SNMPv3, HTTPS, SSH, access control lists, and user authentication to secure management traffic.
How do I reset the RMCARD302 to factory defaults?
Press and hold the reset button (pinhole) on the card for 10 seconds until the LED flashes. Or use the web interface 'Factory Reset' option.
Does the RMCARD302 support environmental sensors?
Yes, it has a port for optional temperature and humidity sensors (sold separately).
