PM245P03 - Solar panel BENQ - Free user manual and instructions
Find the device manual for free PM245P03 BENQ in PDF.
Pick your language and provide your email: we'll send you a specifically translated version.
| Product Type | Photovoltaic Solar Panel |
| Brand | BenQ |
| Model | PM245P03 |
| Power Output | 245 W |
| Cell Type | Monocrystalline |
| Efficiency | ~18% |
| Dimensions (L x W x H) | 1650 x 992 x 35 mm |
| Weight | 18 kg |
| Frame Material | Anodized Aluminum |
| Glass Type | Low Iron Tempered Glass |
| Operating Temperature Range | -40°C to +85°C |
| Maximum System Voltage | 1000 V DC |
| IP Rating | IP67 |
| Warranty | 25 years linear power output, 10 years product workmanship |
| Installation | Ground mount, roof mount, or tracking system |
| Safety Certifications | IEC 61215, IEC 61730 |
| Maintenance | Periodic cleaning with water and soft cloth; inspect for damage |
Frequently Asked Questions - PM245P03 BENQ
How do I install the BenQ PM245P03 solar panel?
Installation should be performed by a certified professional. Ensure the mounting structure is secure and oriented optimally (south-facing in the northern hemisphere). Follow local electrical codes and use appropriate connectors.
What is the recommended tilt angle for maximum efficiency?
The ideal tilt angle equals your latitude. For fixed installations, a tilt angle between 30° and 45° is common. Adjust seasonally for better performance.
How do I clean the solar panels?
Use a soft brush or cloth with clean water. Avoid abrasive materials or harsh chemicals. Clean early in the morning or late evening to prevent thermal shock.
What is the lifespan of the PM245P03 panel?
BenQ solar panels typically have a lifespan of 25-30 years. They come with a 25-year linear power output warranty ensuring at least 80% of nominal power after 25 years.
Can I use this panel for off-grid applications?
Yes, the PM245P03 is suitable for off-grid systems when paired with a charge controller, battery bank, and inverter.
Does the panel work in cloudy weather?
Yes, it still generates electricity under diffuse light, though output is reduced (typically 10-25% of rated power).
What is the maximum snow load the panel can withstand?
The panel is designed to withstand snow loads up to 5400 Pa (approx. 550 kg/m²). Ensure the mounting structure can support additional weight.
How do I connect multiple PM245P03 panels?
Connect panels in series to increase voltage or in parallel to increase current. Use appropriate string sizing to avoid exceeding inverter voltage limits. Always use matching panels.
What should I do if the panel glass is cracked?
A cracked panel can pose safety and performance risks. If the damage is severe, replace the panel. Minor cracks may be temporarily sealed with silicone, but consult a professional.
Is the PM245P03 compatible with microinverters?
Yes, it is compatible with most standard microinverters. Check the microinverter's input voltage and current range to ensure compatibility.
User questions about PM245P03 BENQ
0 question about this device. Answer the ones you know or ask your own.
Ask a new question about this device
No questions yet. Be the first to ask one.
Download the instructions for your Solar panel in PDF format for free! Find your manual PM245P03 - BENQ and take your electronic device back in hand. On this page are published all the documents necessary for the use of your device. PM245P03 by BENQ.
