Product Type	Freestanding Gas Cooker
Brand	Arçelik
Model	9641 HY
Width	60 cm
Depth	60 cm
Height	85 cm (with legs)
Weight	Approx. 50 kg
Power Supply	230 V ~ 50 Hz (electric ignition) + Gas (NG/LPG)
Gas Connection	Natural Gas (NG) or LPG (conversion kit included)
Number of Gas Burners	4 (including a triple-ring wok burner)
Oven Type	Gas oven with electric grill
Oven Capacity	75 liters
Oven Functions	Bake, Grill, Fan-assisted cooking
Energy Efficiency Class	A
Cleaning	Enamel interior, removable oven door for easy cleaning
Safety Features	Flame failure safety device on all burners, child lock
Included Accessories	Deep tray, wire rack, round tray, LPG nozzle kit
Spare Parts Availability	Hoses, nozzles, grates, oven elements available from Arçelik service
Repairability	Modular design, easy access to components

Frequently Asked Questions - 9641 HY Arçelik

Can the Arçelik 9641 HY be used with both natural gas and LPG?

Yes, the cooker is supplied with nozzles for both Natural Gas (NG) and LPG. Refer to the manual for conversion instructions. The LPG nozzle kit is included in the package.

How do I clean the oven interior?

The oven has an enamel coating. Wipe with a damp cloth and mild detergent after use. Avoid abrasive cleaners. The oven door can be removed for thorough cleaning.

What should I do if a burner does not ignite?

Check that the gas supply is on and the spark electrode is clean. If using a match, light manually. For persistent issues, contact service. The flame failure device may need resetting.

What are the dimensions of this cooker?

The standard dimensions are 60 cm wide, 60 cm deep, and 85 cm high (adjustable legs). Ensure your kitchen cutout fits these measurements.

Does the oven have a fan for even cooking?

Yes, the 9641 HY features a fan-assisted oven function that distributes heat evenly for consistent baking and roasting.

How do I convert the cooker from natural gas to LPG?

The conversion requires replacing the burner nozzles and adjusting the air shutter. The LPG nozzle set (marked with 'LPG') is provided. Follow the step-by-step instructions in the manual or contact a qualified technician.

What safety features does this model have?

All burners are equipped with a flame failure device that cuts off gas if the flame goes out. The oven has a thermostatic control and the hob includes a child lock option.

Can I use a wok on the hob?

Yes, the hob includes a triple-ring burner suitable for wok cooking. Use the supplied wok support for stability.

How do I replace the oven light bulb?

Disconnect the power. Remove the glass cover (usually twisted) and replace with a 25W/300°C rated bulb. Refit the cover and restore power.

Where can I find spare parts for this model?

Spare parts such as gas hoses, nozzles, oven racks, and door seals are available from authorized Arçelik service centers. Check the manual for part numbers.

USER MANUAL 9641 HY Arçelik

3. Derin tepsi

4. Tel izgara

5. Yuvarlak tepsi

1 Hortum ucu-LPG
2 Hortum ucu-NG
3 Emniyet hortumu
4 0-ring (conta)
5 Kelepçe

Çalışma modları
