HPK350NFBD - Refrigerator Patrick - Free user manual and instructions
Find the device manual for free HPK350NFBD Patrick in PDF.
Pick your language and provide your email: we'll send you a specifically translated version.
| Product Type | Refrigerator with Freezer |
| Brand | Patrick |
| Model | HPK350NFBD |
| Capacity (approx.) | 350 L |
| Dimensions (H x W x D) approx. | 170 x 60 x 65 cm |
| Weight approx. | 60 kg |
| Energy Class | A+ |
| Defrost Type | No Frost |
| Freezer Position | Bottom |
| Number of Doors | 2 |
| Reversible Door | Yes |
| Adjustable Shelves | Yes |
| Vegetable Crisper | Yes |
| Temperature Control | Mechanical dial |
| Interior Light | Yes |
| Refrigerant | R600a |
| Climate Class | N-ST |
| Noise Level | 42 dB |
| Power Supply | 220-240 V, 50 Hz |
| Annual Energy Consumption | ~280 kWh |
| Cleaning | Unplug before cleaning; use mild detergent; avoid abrasive cleaners |
| Maintenance | Defrost drain cleaning recommended; door gasket check |
| Repairability | Spare parts available; user manual includes troubleshooting |
Frequently Asked Questions - HPK350NFBD Patrick
How do I adjust the temperature on my Patrick HPK350NFBD refrigerator?
Locate the temperature control dial inside the refrigerator compartment. Turn it clockwise for colder or counterclockwise for warmer. For initial settings, start at a medium position.
What does 'No Frost' mean and do I need to defrost this refrigerator?
No Frost means automatic defrosting; ice does not build up on the walls. You do not need to manually defrost the refrigerator or freezer sections.
How can I reverse the door opening direction?
The door is reversible. Remove the door hinge screws, lift the door, and reattach hinges on the opposite side. Refer to the installation instructions for detailed steps.
Why is water pooling at the bottom of my refrigerator?
This may be due to a blocked defrost drain. Clean the drain hole with a pipe cleaner or warm water. Ensure the drain pan is correctly positioned.
How do I clean the interior of my Patrick refrigerator?
Unplug the refrigerator. Remove all food and shelves. Wash interior surfaces with warm water and a mild detergent. Rinse and dry thoroughly before plugging back in.
What should I do if the refrigerator is not cooling properly?
Check that the temperature dial is set correctly. Ensure the door is sealing properly. Clean the condenser coils (located at the back or bottom) if dirty. Allow 24 hours for temperature to stabilize after changes.
Can I store hot food directly in the refrigerator?
No, allow hot food to cool to room temperature before placing it inside to prevent raising the internal temperature and wasting energy.
How often should I replace the water filter?
This model does not have a water dispenser or filter, so no replacement is needed.
The refrigerator is making unusual noises. Is that normal?
Some sounds like gurgling, clicking, or humming are normal (refrigerant flow, compressor). If you hear loud rattling or banging, check that the appliance is level and that shelves are secure.
Where can I find spare parts for my HPK350NFBD?
Contact Patrick customer service or authorized dealers. Provide the model number HPK350NFBD and part name. Many parts like shelves, door bins, and gaskets are available.
User questions about HPK350NFBD Patrick
0 question about this device. Answer the ones you know or ask your own.
Ask a new question about this device
No questions yet. Be the first to ask one.
Download the instructions for your Refrigerator in PDF format for free! Find your manual HPK350NFBD - Patrick and take your electronic device back in hand. On this page are published all the documents necessary for the use of your device. HPK350NFBD by Patrick.
USER MANUAL HPK350NFBD Patrick
• INSTRUCCIONES
Technical line drawing of a vehicle front panel with no visible text or symbols
• SOLUCION A PROBLEMAS
