SK7139 - Cooker ELEKTRO HELIOS - Free user manual and instructions

Product Type	Freestanding Electric Cooker
Brand	Elektro Helios
Model	SK7139
Width	60 cm
Height	85 cm
Depth	60 cm
Weight	Approximately 50 kg
Energy Source	Electric (230V, 50Hz)
Power Rating	Approximately 9 kW
Number of Cooking Zones	4 (Radiant or Solid Plates)
Oven Type	Multifunction Electric Oven
Oven Functions	Conventional, Grill, Fan, Defrost
Oven Capacity	Approximately 65 Liters
Grill Element	Top grill with variable temperature
Door Type	Drop-down door with child lock
Interior Light	Oven lamp (replaceable)
Storage Drawer	Bottom storage drawer included
Control Type	Rotary knobs with temperature display
Timer	Mechanical timer with alarm
Safety Features	Child lock, auto shut-off, overheat protection
Cleaning	Enamel interior, easy-clean hob
Spare Parts Availability	Through Elektro Helios service network
Repairability Index	High (standard components)
Energy Class	A (estimated)
Included Accessories	Enamel baking tray, wire rack, grill pan

Frequently Asked Questions - SK7139 ELEKTRO HELIOS

How do I clean the hob on my Elektro Helios SK7139?

Clean the hob after each use with a damp cloth and mild detergent. For stubborn stains, use a ceramic hob scraper or specialized cleaner. Avoid abrasive sponges.

How do I replace the oven lamp in the SK7139?

Disconnect the cooker from power. Remove the glass cover by twisting it counterclockwise. Replace the bulb with a 25W/300°C oven lamp, then refit the cover.

What does the child lock feature do on this cooker?

The child lock prevents the oven door from opening during operation. To activate, turn the lock knob to the locked position. To deactivate, turn it back.

How can I save energy while using the oven?

Preheat only when necessary, use the fan function for even heat, avoid opening the door frequently, and cook multiple dishes at once. Also, turn off the oven 5-10 minutes before the end of cooking.

Why does the oven not heat up?

Check the power supply and circuit breaker. Ensure the oven timer is not set to manual mode. If the heating elements are faulty, contact service. Also inspect the temperature selector.

Can I use the grill function with the oven door open?

No, the grill function should only be used with the door closed for safety and to maintain proper temperature. The door has a special grill position that allows a small gap.

What is the storage drawer used for?

The bottom drawer can store baking trays, pans, and other oven accessories. It is not intended for food storage as it can become warm during operation.

How do I set the timer on the SK7139?

Turn the timer knob clockwise to the desired time (up to 120 minutes). The oven will switch off automatically when the time elapses. A bell will ring.

What should I do on first use?

Remove all packaging and stickers. Heat the empty oven at 250°C for about 30 minutes to burn off any manufacturing residues. Air the kitchen during this process.

Where can I find spare parts for my cooker?

Spare parts are available through the Elektro Helios service network. You can order online or contact customer service with your model number SK7139.

USER MANUAL SK7139 ELEKTRO HELIOS

Spis Liesi

B R U K S A N V I S N I N G

K Ä Y T T Ö O H J E

SK 6139

SK 7139

INNEHÅLLSFÖRTECKNING 2

SISÄLTÖ 2

Elektro EH Helios

Innehåll

SÄKERHET 3

FÖR ANVÄNDAREN

Bekanta dig med:

Bränn av ugnen

Luckspärren

Spar energi!

Ugnen

Stekning

Snabbstart

Grillning

Ugnen

Lamporna

Byte av ugnslampa

Förvaringslådan

Service

Placering i ugn
