9440 HS DG - Cooker Arçelik - Free user manual and instructions

Product Type	Gas Cooker with Electric Oven
Brand	Arçelik
Model	9440 HS DG
Energy Source (Hob)	Natural Gas / LPG (convertible)
Energy Source (Oven)	Electricity
Dimensions (H x W x D)	85 cm x 90 cm x 60 cm
Weight	Approximately 50 kg
Number of Gas Burners	4 (including one rapid burner)
Oven Capacity	70 liters
Maximum Hob Power	8.5 kW (total)
Oven Heating Elements	Top and bottom heating, grill
Oven Functions	Conventional, grill, fan-assisted
Energy Efficiency Class (Oven)	A
Safety Features	Flame failure device on all burners, triple-glazed oven door, child lock
Cleaning	Easy-clean enamel interior, removable oven door
Accessories Included	Oven rack, drip tray, grill rack
Voltage / Frequency	220-240 V / 50-60 Hz
Spare Parts Availability	Genuine parts available via authorized service centers
Warranty	2 years (standard), extended options available

Frequently Asked Questions - 9440 HS DG Arçelik

How should I install the cooker?

Installation must be performed by a qualified technician according to local regulations. Ensure proper ventilation and gas connection. The cooker must be placed on a level, heat-resistant surface and connected to a suitable gas type (natural gas or LPG) with an approved regulator.

What type of gas can I use?

The cooker can be used with natural gas or LPG. Conversion kits are available for switching between gas types. Refer to the manual for injector specifications and pressure settings.

How do I clean the hob and oven?

For the hob, wipe with a damp cloth and mild detergent; avoid abrasive cleaners. The oven interior has an enamel coating; clean with a non-abrasive cleaner. The oven door can be removed for easy cleaning. Always let the appliance cool before cleaning.

Why is my oven not heating?

Check if the oven is properly connected to power and the timer is set. If the heating elements are not glowing, they may be faulty. Also verify that the oven thermostat is set correctly. If issues persist, contact an authorized service center.

How do I replace the oven light?

Disconnect the cooker from the power supply. Remove the glass cover (usually by rotating or unclipping) and replace the bulb with a new one of the same type (typically 25W, 300°C resistant). Reattach the cover and restore power.

What is the warranty period?

The standard warranty is 2 years from the date of purchase. Extended warranty options may be available. The warranty covers manufacturing defects but not misuse or normal wear. Keep your purchase receipt.

Can I use aluminum foil in the oven?

Yes, but avoid covering the entire oven bottom or heating elements, as it can affect heat circulation and damage the appliance. Use foil only for wrapping food or lining trays, ensuring it does not touch the elements.

How do I set the timer?

Turn the timer knob to the desired time (up to 120 minutes). The oven will automatically turn off when the set time expires. Some models also have an end-of-cooking alarm. Refer to the manual for precise instructions.

Is the oven self-cleaning?

No, this model does not have a self-cleaning function. The oven interior features an easy-clean enamel coating. For heavy soiling, use a specialized oven cleaner and follow the safety instructions.

Where can I find spare parts?

Genuine spare parts are available through Arçelik authorized service centers or online spare parts retailers. Use only original parts to ensure safety and performance. The model number 9440 HS DG is essential for ordering.

USER MANUAL 9440 HS DG Arçelik

3. Derin tepsi

4. Tel izgara

1. Gaz kesme emniyeti
