LGB1152A - Carte réseau/Adaptateur Black Box - Free user manual and instructions
Find the device manual for free LGB1152A Black Box in PDF.
Pick your language and provide your email: we'll send you a specifically translated version.
| Product Type | Network Adapter |
| Brand | Black Box |
| Model | LGB1152A |
| Interface | PCI Express |
| Data Transfer Rate | 1 Gbps |
| Connector Type | RJ-45 |
| Network Standards | IEEE 802.3, 802.3u, 802.3ab |
| Dimensions (W x H x D) | 120 mm x 20 mm x 80 mm |
| Weight | 50 g |
| Power Consumption | 2.5 W |
| Operating Temperature | 0°C to 55°C |
| Storage Temperature | -20°C to 70°C |
| Operating Humidity | 10% to 90% non-condensing |
| Compatible Operating Systems | Windows, Linux, macOS |
| LED Indicators | Link/Activity |
| Certifications | FCC, CE, RoHS |
| Warranty | 1 year limited |
| Included Accessories | Low-profile bracket, quick installation guide |
| Maintenance | Keep clean and dust-free |
| Safety Precautions | Use in well-ventilated area; avoid static discharge |
| Spare Parts Availability | Contact support for replacement |
Frequently Asked Questions - LGB1152A Black Box
How do I install the LGB1152A network adapter?
Power off your computer, open the case, insert the card into an available PCIe slot, secure it, and close the case. Power on and install the drivers from the included disc or website.
What operating systems are supported?
The adapter supports Windows (7, 8, 10, 11), Linux (most distributions), and macOS (version 10.9 and later).
Why is my network adapter not recognized?
Ensure the card is fully seated in the PCIe slot. Check BIOS settings to confirm the slot is enabled. If still not recognized, try a different slot or update the motherboard BIOS.
How can I update the driver for LGB1152A?
Download the latest driver from Black Box's support website or use the device manager to search for updates automatically.
What does the LED indicator mean?
The LED is solid green when linked, blinking during activity, and off when no connection.
Can I use this adapter with a low-profile case?
Yes, the package includes a low-profile bracket for installation in slim cases.
Does the LGB1152A support Wake-on-LAN?
Yes, Wake-on-LAN is supported. Enable it in the adapter's advanced settings and configure the BIOS accordingly.
What is the maximum cable length supported?
For Gigabit Ethernet, the maximum length for a Cat5e cable is 100 meters.
Is the adapter compatible with PCIe 2.0?
Yes, it is backward compatible with PCIe 2.0 and PCIe 3.0 slots.
How to troubleshoot intermittent connectivity?
Check cable quality, ensure the driver is up-to-date, and try a different PCIe slot. Also, verify that the network switch port is functioning correctly.
