| Product Type | Canister Vacuum Cleaner |
| Brand | Yamazen |
| Model | YVSR-75703 |
| Dimensions (L x W x H) | 320 x 240 x 210 mm |
| Weight | 4.5 kg |
| Power Supply | 220-240 V, 50/60 Hz |
| Power Consumption | 800 W |
| Dust Capacity | 1.5 L |
| Filtration System | HEPA Washable Filter |
| Cord Length | 5 m |
| Noise Level | 72 dB(A) |
| Suction Power Control | Electronic slider |
| Accessories Included | Crevice tool, brush, floor nozzle |
| Maintenance | Regularly empty dust container and clean filter |
| Safety Features | Thermal overload protection, motor protection filter |
| Reparability | Spare parts available from manufacturer; user-replaceable filter and brush |
| Warranty | 2 years |
Frequently Asked Questions - YVSR-75703 Yamazen
How do I clean the HEPA filter?
Turn off and unplug the vacuum. Remove the filter holder, take out the HEPA filter, and rinse it under lukewarm water. Let it dry completely for 24 hours before reinstalling.
What should I do if the suction power decreases?
Check if the dust container is full or if the filter is clogged. Also inspect the hose and nozzle for blockages. Clean the filter or empty the container as needed.
Can I use this vacuum for carpets and hard floors?
Yes, the YVSR-75703 comes with a floor nozzle suitable for both carpets and hard floors. Adjust the suction power accordingly.
How often should I replace the filter?
The HEPA filter should be cleaned every 3 months and replaced every 6-12 months, depending on usage frequency and conditions.
The vacuum turns off during use. What could be the problem?
The thermal overload protection may have activated due to overheating. Unplug the vacuum and let it cool down for at least 30 minutes. Check for blockages before restarting.
How do I empty the dust container?
Press the release button to remove the dust container from the main unit. Hold it over a trash bin and press the bottom latch to open the lid and dump the contents.
Is the power cord long enough for large rooms?
The 5m cord provides a cleaning radius of about 8-9m when combined with the hose length. For larger areas, you may need to switch outlets.
Can I wash the dust container?
Yes, the dust container can be washed with mild soap and water. Ensure it is completely dry before reassembling to avoid moisture damage.
What spare parts are available?
Spare parts include filters, brush rolls, crevice tools, and hoses. Contact Yamazen customer service or visit authorized dealers.
How do I store the vacuum?
Wrap the cord around the cord hooks, attach the accessories to the holders, and store the vacuum in an upright position in a dry place.
