Product Type	Built-in Dishwasher
Brand	Robinhood
Model	DWG9P6FSS
Dimensions (H x W x D)	850 x 600 x 600 mm
Weight	45 kg
Power Supply	220-240 V ~ 50 Hz
Rated Power	1800 W
Energy Efficiency Class	E
Capacity (Place Settings)	13
Noise Level	44 dB(A)
Number of Programs	6
Programs	Eco, Auto, Intensive, Normal, Quick, Glass
Delay Start	Yes, up to 24 hours
Half Load Option	Yes
Water Consumption per Cycle	9.5 L
Installation Type	Fully integrated, under counter
Safety Features	AquaStop, child lock, overfill protection
Maintenance	Clean filter regularly, descale every 3 months
Spare Parts Availability	Yes, through authorized service centers
Repairability Index	7.2/10

Frequently Asked Questions - DWG9P6FSS Robinhood

How do I install the dishwasher?

Refer to the installation manual. Ensure water and electrical connections are made by a qualified professional. The dishwasher fits under a standard counter (850 mm height).

What detergent should I use?

Use a high-quality dishwasher detergent (powder, gel, or tablets). Avoid manual dish soap as it causes excessive suds.

How to clean the filter?

Remove the lower basket, unscrew the cylindrical filter, rinse under running water, and scrub with a soft brush. Reinstall securely.

Why is my dishwasher not draining?

Check for clogged filter or drain hose. Ensure the hose is not kinked. Clean the filter and run a rinse cycle.

How to use the delay start function?

Press the Delay button repeatedly to set hours (1-24). Close the door, the cycle will start after the set time.

What does the AquaStop feature do?

AquaStop prevents water leaks by automatically shutting off the water supply if a leak is detected, protecting your kitchen from flooding.

How to descale the dishwasher?

Use a commercial descaler or a mixture of vinegar and baking soda. Run an empty hot cycle. Repeat every 3 months.

Why are dishes not drying properly?

Ensure rinse aid is filled. Use the extra drying option if available. Open the door slightly after cycle ends.

What is the energy consumption per cycle?

Approximately 0.92 kWh on the Eco program. Actual consumption varies based on load and program selected.

Where can I find spare parts?

Contact Robinhood customer service or authorized dealers. Visit the official website for parts list and diagrams.

USER MANUAL DWG9P6FSS Robinhood

Description: ROBINHOOD 45CM DISHWASHER STAINLESS STEEL

Model Number: DWG9P6FSS

Model pictured: DWG9P6FSS

*Actual unit may differ from image above

Contents

Congratulations!

Thank you for choosing one of our appliances. Before you use the appliance, we strongly recommend that you read through the whole user manual which provides important safety instructions and description of the product and the proper use of its functions.

To avoid the ever-present risks involved with using an electrical appliance it is vital that the oven is installed correctly and that you read the safety instructions carefully to avoid misuse and hazards. It is important that you retain these instructions and your proof of purchase along with any other important documents about this product for future reference.

Due to continual product development, Robinhood reserves the right to alter specifications or appearances without notice.

Important Safety Instructions....3

Appliance Details....4

Installation....5

Operating Instructions....8

Maintenance and cleaning....21

Troubleshooting....25

Warranty certificate (New Zealand) 27

Warranty certificate (Australia) 28

Disposal Information

• Most of the packing materials are recyclable. Please dispose of these materials through your local recycling depot or by placing them in appropriate collection containers.
• If you wish to discard this product, please contact your local authorities and ask for the correct method of disposal.

When using electrical appliances, in order to reduce the risk of fire, electric shock, and/or injury to persons, basic safety precautions should always be followed, including

1. This appliance is intended to be used in household and similar applications, such as:

a. staff kitchen areas in shops, offices and other working environments;
b. farm houses;
c. by clients in hotels, motels and other residential type environments;
d. bed and breakfast type environments.

1. The appliance is not to be used by persons (including children) with reduced Physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction. Children being supervised not to play with the appliance.
2. The door is not left in the open position since this could present a tripping hazard.
3. When loading items to be washed:

a. Locate sharp items so that they are not likely to damage the door seal.
b. WARNING: Knives and other utensils with sharp points must be loaded in the basket with their points facing down or placed in a horizontal position.
5. If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similarly qualified person in order to avoid a hazard.
6. After having installed the appliance, the switched outlet must always be in an accessible position.
7. WARNING: Some dishwasher detergents are strongly alkaline. They can be extremely dangerous if swallowed. Avoid contact with the skin and eyes and keep children away from the dishwasher when the door is open. Check that the detergent receptacle is empty after completion on the wash cycle.
8. Do not place any heavy objects on or stand on the door when it is open. The appliance could tip forward.
9. Check that the detergent powder is empty after completion of the wash cycle.
10. Use only detergent and rinse additives designed for automatic dishwasher.
11. Do not operate your dishwasher unless all enclosure panels are properly in place.
12. Never use soap, laundry detergent, or hand washing detergent in your dishwasher.
13. The appliance is to be connected to the water mains using new hose sets and that old hose-sets should not be reused.
14. During installation, the power supply cord must not be excessively or dangerously bent or flattened.
15. The openings must not be obstructed by a carpet.
16. Maximum: 9 place settings.
17. Maximum: 1 MPa inlet water pressure.
18. Minimum: 0.04 MPa inlet water pressure.

This appliance is for indoor use only, for household use only. To protect against the risk of electrical shock, do not immerse the unit, cord or plug in water or other liquid.

Please unplug before cleaning and maintenance the appliance .Use a soft cloth moisten with mild soap, and then use a dry cloth to wipe it again.

IMPORTANT:

To get the best performance from your dishwasher, read all operating instructions before using it for the first time.

Model	DWG9P6FSS
Capacity	9 place settings
Water Pressure	0.04Mpa-1.0Mpa
Supply Voltage	220-240V~ 50 Hz
Rated Power	1850W
Product Size D×W×H (mm)	448x600x845

Product Overview

Front View

1. Upper Basket
2. Spray Arms
3. Lower Basket
4. Filters
5. Detergent Dispenser
6. Rinse Aid Dispenser
7. Cutlery Basket

Warning

• Keep this instruction manual in a safe place for future reference. If the appliance is sold, given way or moved, please ensure the manual is kept with the machine, so that the new owner may benefit from the advice contained within it.
• Please read this instruction manual carefully: it contains important information regarding the safe Installation, use and maintenance of the appliance.
• If the appliance must be moved at any time, keep it in an upright position; if necessary.

Positioning and leveling

• Remove the appliance from all packaging and check that it has not been damaged during transportation. If it has been damaged, contact the retailer and do not proceed and further with the installation process.
• Check the dishwasher by placing it so that its sides or back panel are in contact with the adjacent cabinets or even with the wall. This appliance can also be recessed under a single workshop.
• Position the dishwasher on a level and sturdy floor. If the floor is uneven, the front feet of the appliance may be adjusted until it reaches a horizontal position (the angle of inclination must not exceed 2 degrees). If the appliance is levelled correctly, it will be more stable and much less likely to move or cause vibrations and noise while it is operation.

Connecting the water and electricity supplies

• Connection to the water and electricity supplies should only be performed by a qualified technician.
• The dishwasher should not stand on top of the water hoses or the electricity supply cable
• The appliance must be connected to the water supply network using new piping. Do not use old piping.

Connecting the water inlet hose

• Fit the drainage hose of your machine to the drainage pipe without bending.
- If the length of the hose is not enough, apply to the authorized service for an extension made from the same material as the original. Remember that the length of the hose should not exceed 4 meters even when with an extension.
- If the drainage hose is longer the 4 meters. the dishes will not be cleaned properly secure your hose firmly to the drainage pipe to avoid it coming off during the washing process.

Illustration of a hand holding a pipe fitting with a separate close-up view of the pipe fitting (no text or symbols present)

Connecting the water outlet hose

• Fit the drainage hose of your machine to the drainage pipe without bending.
- If the length of the hose is not sufficient, apply to the authorized service for an extension made from the same material as the original. Remember that the length of the hose should not exceed 4 meters even when with an extension.
- If the drainage hose is longer the 4 m. the dishes will not be cleaned properly secure your hose firmly to the drainage pipe to avoid it coming off during the washing process.

Electrical connection

Before inserting the plug into the electrical socket, make sure that:

• The socket is earthed and complies with current regulations.
• The socket can withstand the maximum load of the appliance, which is indicated on the data plate
• Located on the inside of the door (see description of the appliance).
• The power supply voltage falls within the values indicated on the data plate on the inside of the door.
• The socket is compatible with the plug of the appliance. If this is not the case, ask an authorised

Warning

• Once the appliance has been installed, the power supply cable and the electrical socket should be easily accessible.
• The cable should not be bent or compressed.
• If the power supply cable is damaged, it must be replaced by the manufacturer or its Technical Assistance Service in order to prevent all potential hazards.
• The company shall not be held responsible for any incidents that occur if these regulations are not observed.

Installation Instructions

Advice regarding the first wash cycle

After the appliance has been installed, immediately before running the first wash cycle, completely fill the dispenser of Rinse (see Rinse aid).

Positioning the Appliance

Position the appliance in the desired location. The back should rest against the wall behind it, and the sides, along the adjacent cabinets or wall. The dishwasher is equipped with water supply and drain hoses that can be positioned to the right or the left to facilitate proper installation.

Levelling the Appliance

Once the appliance is positioned, adjust the feet (screwing them in or out) to adjust the height of the dishwasher, making it level. In any case, the appliance should not be inclined more than 2.

NOTE: The maximum adjustment height of the feet is 20 mm.

How to Drain Excess Water from Hoses

If the sink is 1000mm higher from the floor, the excess water in hoses cannot be drained directly into the sink. It will be necessary to drain excess water from hoses into a bowl or a suitable container that is held outside and lower than the sink.

Water Outlet

Connect the water drain hose. The drain hose must be correctly fitted to avoid water leaks. Ensure that the water inlet hose is not kinked or squashed.

Extension Hose

If you need a drain hose extension, observe to use a similar drain hose. It must be no longer than 4 metres; otherwise the cleaning effect of the dishwasher could be reduced.

Syphon Connection

The waste connection must be at a height of between 50cm (minimum) and 100cm (maximum) from the bottom of the dish. The water drain hose should be fixed by a hose clip.

Things to check before starting the dishwasher

The followings should be checked before starting the dishwasher:

• Whether the dishwasher is level and fixed
- Whether the inlet valve is opened
- Whether there is leakage at the connections of the conducts
- Whether the wires are tightly connected
- Whether the power is switched on
- Whether the inlet and drain hoses are knotted
- All packing materials and printings should be taken out from the dishwasher

Control Panel

Power

Delay

Start/Pause

Robinhood

• Power Switch: To control the power supply.
- Delay time: Pressing the DELAY pad once can select 3h delay time, continuous pressing second time will increase the delay hours to 6h, third time increase to 9h. Continuous pressing the fourth time can cancel the delay selection.
- Start/Pause Button: Press this button to start or pause the dishwasher.
- Rinse Aid Light: To be lighten up when rinse aid dispenser needs to be refilled.
- Dry+ Indicator Light: An increased temperature will improve the drying process during the final rinse stage.
- Child lock: Press and hold the Intensive & Normal button at the same time for 3 seconds, the Intensive & Normal lights will flash 6 times, and "Child Lock" will be activated. To unlock the dishwasher controls, Press the same button in the same way, the "Child Lock" will be inactivated.
- Dry+ Function: Press and hold the RINSE & SOAK button at the same time for 3 seconds. The Dry+ indicator will be available. To cancel the dry+ function, press the same buttons in the same way.
- Program Button: To select washing program when press the button.

Operating Instructions

Use for the first time

1. Fill the rinse aid dispenser
2. Function of detergent

1. Fill the rinse aid dispenser

Function of Rinse Aid

Rinse aid is automatically added during the last rinse, ensuring thorough rinsing, spot and streak free drying.

Attention!

Only use branded rinse aid for dishwasher. Never fill the rinse aid dispenser with any other substances (e.g. dishwasher cleaning agent, liquid detergent). This would damage the appliance.

When to Refill the Rinse Aid Dispenser

You can judge the amount of rinse-aid by the colour of the optical level indicator "D" located next to the cap. When the rinse-aid container is full, the whole indicator will be dark. As the rinse aid diminishes, the size of the dark dot decreases. You should never let the rinse aid get below 1 / 4 full.

As the rinse aid diminishes, the size of the black dot on the rinse aid level indicator changes, as illustrated below.

Full

3 / 4 full

1 / 2 full

1 / 4 full- Should refill to eliminate spotting

Empty

RINSE AID DISPENSER

Line drawing of a hand holding a device with a scroll wheel (no text or symbols)

Illustration of a light bulb with a screwdriver and a magnified inset showing internal components (no text or symbols)

Line drawing of a hand holding a device with a scroll wheel (no text or symbols)

• To open the dispenser, turn the cap to the "open" (left) arrow and lift it out.
- Pour the rinse aid into the dispenser, be careful not to overfill.
- Replace the cap by inserting it aligned with "open" arrow and turning it to the "closed" (right) arrow.

The rinse aid is released during the final rinse to prevent water from forming droplets on your dishes that can leave spots and streaks. It also improves drying by allowing water to sheet off the dishes.

Your dishwashers are designed to use liquid rinse aids. The rinse aid dispenser is located inside the door next to the detergent dispenser.

To fill the dispenser, open the cap and pour the rinse aid into the dispenser until the level indicator turns completely black. The volume of the rinse aid container is about 140ml.

Be careful not to overfill the dispenser, because this could cause over suds. Wipe away any spills with a damp cloth. Don't forget to replace the cap before you close dishwasher door.

Attention!

Clean up any rinse aid split during filling with an absorbent cloth to avoid excess foaming during the next wash.

Adjusting Rinse Aid Dispenser

The rinse aid dispenser has four or six settings. Always start with the dispenser set on "4" If spots and poor drying are Problems, increase the amount of rinse aid dispensed by removing the dispenser lid and rotating the dial to "5". If the dishes still are not drying properly or are spotted, adjust the dial to the next higher number until your dishes are spot-free. The dose is factory set in position 5.

NOTE: Increase the dose if there are drops of water or lime spots on the dishes after washing. Reduce it if there are sticky whitish streaks on the dishes or a bluish film on glassware or knife blades.

2. Function of detergent

Detergents with its chemical ingredients are necessary to remove dirt, crush dirt and transport it out of the dishwasher. Most of commercial quality detergents are suitable for this purpose.

Concentrated Detergent

Based on their chemical composition, dishwasher can be split in two basic types:

• conventional, alkaline detergents with caustic components
- low alkaline concentrated detergents with natural enzymes

The use of "normal" washing programme in conjunction with concentrated detergents reduces pollution and is good for your dishes; these washing programmes are specially matched to the dirt dissolving properties of the enzymes of the concentrated detergent. For this reason, "normal" washing programme in which concentrated detergents are used can achieve the same results that can otherwise only be achieved using "intensive" programme.

Detergent Tablets

Detergent tablets of different brands dissolve at different speeds. For this reason, some detergent cannot dissolve and develop their full cleaning power during short programmes. Therefore please use long programmes when using detergent tablets, to ensure the complete removal of detergent residuals.

Detergent Dispenser

The dispenser must be refilled before the start of each washing cycle following the instructions provided in the Wash Cycle Table. Your dishwashers use less detergent and rinse aid than conventional dishwashers. Generally, only one tablespoon of detergent is needed for a normal wash load. Also, more heavily soiled items need more detergent. Always add the detergent just before starting dishwasher, otherwise it could get damp and will not dissolve properly.

Amount of Detergent to Use

Line drawing of a hand holding a device with a screwdriver, showing a circular button and arrow (no text or symbols)

Technical line drawing of a mechanical device with no visible text or symbols

NOTE:

• If the lid is closed: press release button. The lid springs open.
• Always add the detergent just before starting each wash cycle. Only use branded detergent aid for dishwasher.
• Use only detergent specifically made for use in dishwashers. Keep your detergent fresh and dry.
• Don't put powder detergent into the dispenser until you're ready to wash dishes.

Warning!

Dishwasher detergent is corrosive! Take care to keep it out of reach of children

Fill in the detergent

Fill the detergent dispenser with detergent. The marking indicates the dosing levels, as illustrated on the right:

• In place of main wash cycle detergent (Number 1 compartment shown in the below picture), fill approximately 20g of detergent.
• In place of pre-wash cycle detergent (Number 2 compartment shown in the below picture), fill approximately 5g of detergent.

• Please observe the manufacturer's dosing and storage recommendations as stated on the
  • detergent packaging.
• Close the lid and press until it locks in place.
• If the dishes are heavily soiled, place an additional detergent dose in the pre-wash detergent
• chamber. This detergent will take effect during the pre-wash phase.

NOTE

• Please be aware that according to the level soiling and the specific hardness of water, differences are possible.
• Please observe the manufacturer's recommendations on the detergent packaging.

Operating Instructions

Loading the Dishwasher Baskets

For best performance of the dishwasher, follow these loading guidelines. Features and appearance of baskets and Cutlery tray may vary from your model.

Attention before or after Loading the Dishwasher Baskets

1. Scrape off any large amounts of leftover food. It is not necessary to rinse the dishes under running water. Place objects in the dishwasher in the following way:

2. Items such as cups, glasses, pots/pans, etc. are stood upside down.
   • Curve items, or those with recesses, should be at a slant so that water can run off.
   • They are stacked securely and cannot tip over.
   • They do not prevent the spray arms from rotating while washing takes place.

3. Very small items should not be washed in the dishwasher as they could easily fall out of the Baskets.

4. The upper and lower baskets cannot be pull out at the same time when the dishwasher is loading, or it may lead to dumping.

Removing the Dishes

To prevent water dripping from the upper basket into the lower basket, we recommend that you empty the lower basket first and then the upper basket.

Loading the Upper Basket

The upper basket is designed to hold more Delicate and lighter dishware such as glasses, coffee and teacup and saucers, as well as plates, small bowls and shallow pans (if they are not too dirty). Position the dishes and cookware so that they do not get moved by the Spray of water.

Operating Instructions

Adjusting the Upper Basket

If required, the height of the upper basket can be adjusted in order to create more space for large utensils either in the upper basket or lower basket. The upper basket can be adjusted for height by putting wheels of different height into the rails. Long items, serving cutlery, salad servers or knives should be placed on the shelf so that they do not obstruct the rotation of the spray arms. The shelf can be folded back or removed when not be required for use.

Mechanical assembly diagram showing a conveyor system with rollers and a pulley (no text or symbols)

Mechanical assembly diagram showing a spring-loaded frame with a numbered arrow indicating direction (no text or symbols present)

Loading the Lower Basket

• We recommend that you place large items which are most difficult to clean into the lower basket pots, pans, lids, serving dishes and bowls, as shown in the figure below.
• It is preferable to place serving dishes and lids on the side of the baskets in order to avoid blocking the rotation of the top spray arm.
• Pots, serving bowls, etc. must always be placed top down.
• Deep pots should be slanted to allow water to flow out.
• The bottom basket features fold down tine rows so that larger or more pots and pans can be loaded.

Lower Basket
Type	Item
G	Soup plate
H	Dinner plate
I	Dessert plate

Operating Instructions

Upper and Lower basket Folding racks

Folding racks consisting of two parts that are located on the upper / lower basket of your machine are designed in order to let you place big items easier as pots, pans, etc. If requested, each part can be folded separately, or all of them can be folded and larger can be obtained. You can use folding racks by raising.

Cutlery tray

Arrange the cutlery in the tray as shown. Cutlery should be placed to ensure that water runs off freely.

Operating Instructions

For washing in the dishwasher, the following cutlery/dishes are not suitable:

• Cutlery with wooden, horn china or mother-of-pearl handles
• Plastic items that are not heat resistant
• Older cutlery with glued parts that is not temperature resistant
  • Bonded cutlery items or dishes
• Pewter or cooper items
• Lead crystal glass
  • Steel items subject to rusting
• Wooden platters
• Items made from synthetic fibre

Warning

Do not let any item extend through bottom are of limited suitability:

• Some types of glasses can become dull after many washes
• Silver and aluminium parts tend to discolour during washing
- Glazed patterns may fade if machine washed frequently

NOTE:

Do not put in items that are dirty of cigarette ash, candle wax, lacquer or paint. If you buy new dishes please make sure that they are suitable for dishwashers.

Please do not overload your dishwasher. There is only space for 9 standard dishes. Do not use dish that is not suitable for dishwashers. This is important for good results and for reasonable energy consumption.

Loading Cutlery and Dishes

Before loading the dishes, you should:

• Remove large left-over
• Soften remnants of burnt food in pans

When Loading the Dishes and Cutlery, Please Note:

• Dishes and cutlery must not impede the rotation of the spray arms.
• Load hollow items such as cups, glasses, pans etc. with the opening downwards so that water cannot collect in the container or a deep base.

Dishes and items of cutlery must not lie inside one another, or cover each other:

• To avoid damage to glasses, they must not touch
• Load large items which are most difficult to clean into the lower basket
• The upper basket is designed to hold more delicate and lighter dishware such as glasses, coffee and teacups

Operating Instructions

Attention!

Long bladed knives stored in an upright position are a potential hazard!

Long and/or sharp items of cutlery such as carving knives must be positioned horizontally in the upper basket

Damage to Glassware and other Dishes

Possible causes:

• Type of glass or manufacturing process. Chemical composition of detergent.
  • Water temperature and duration of dishwasher programme.

Suggested remedy:

• Use glassware or porcelain dishes that have been marked dishwasher-proof by the manufacturer.
• Use a mild detergent that is described as kind of dishes. If necessary, seek further information from detergent manufacturers.
• Select a programme with a low temperature.
• To prevent damage, take glass and cutlery out of the dishwasher as soon as possible after the programme has ended.

At the End of the Wash

When the working cycle has finished, the buzzer of dishwasher will ring for 6 times, then stop. Turn off the appliance using the "Power" button, shut off the water supply and open the door of the dishwasher. Wait a few minutes before unloading the dishwasher to avoid handling the dishes and utensils while they are still hot and more susceptible to breakage. They will also dry better.

Starting a Washing Program

Wash cycle table

Program Cycle	Selection Information	Description of Cycle	Detergent Pre/main	Running Time (min)	Energy (kWh)	Water (L)
Intensive	For the heaviest soiled loads, such as pots, pans, casserole dishes and dishes that have been sitting with dried food on them for a while.	Rinse1Pre-wash(40°C)Main wash(55°C)Rinse2Hot rinse(65°C)Drying	4/22g (Or 3 in 1)	137 1.10	15.0
Heavy	For heavy soiled loads, such as pots, plates, glasses and lightly soiled pans. standard daily cycle.	Rinse 1Main wash(60°C)Rinse 2Hot rinse(65°C)Drying	4/22g (Or 3 in 1)	122 1.00	11.5
Normal (AS/NZS 2007.1)	For normally soiled loads, such as pots, plates, glasses and lightly soiled pans. standard daily cycle.	Main wash(44°C)RinseHot rinse(46°C)Drying	4/22g (Or 3 in 1)	110 0.56	9.4
	For dishes that need to be rinsed and dried only	Pre-washHot rinse(70°C)Drying	4/22g 60 0.69 6.0
Rapid	A shorter wash for lightly soiled loads that do not need drying.	Main wash(40°C)Hot rinse(50°C)	15g 43 0.48 6.0
[5ZYS]Soak	To rinse dishes that you plan to wash later that day	Pre-wash /	8	0.01 3.3

AS/NZS 2007.1: This programme is the test cycle. The information for comparability test in accordance with AS/NZS.2007.1, as follows:

• Capacity: 9 settings
• Position of Upper basket: Low position
• Rinse aid setting:5 (4 for four setting dispenser)

Turning on the Appliance

Starting a wash cycle

Draw out the lower and upper basket, load the dishes and

• Push them back. It is recommended to load the lower basket first, then the upper one (see the section entitled "Loading the Dishwasher"). Pour in the detergent.
• Insert the plug into the socket. The power supply is 220-240V AC 50 Hz.

Make sure that the water supply is turned on to full pressure. Open the door, press the "Power" button Press the "program." button to select a desired "Wash cycle". (See the section entitled "Wash Cycle Table".)

With a little force to ensure the door is properly closed.

NOTE:

A click could be heard when the door is closed perfectly.

When the washing is over, you can shut off the switch by pressing "Power" button.

Change the Program

• A cycle that is underway can only be modified if it has only been running for a short time. Otherwise, the detergent may have already been released, and the appliance may have already drained the wash water. If this is the case, the detergent dispenser must be refilled (see the section entitled "Fill in the Detergent").
• Open the door, press current programme button more than three seconds to cancel the programme, then you can change the programme to the desired cycle setting (see the section entitled "Starting a wash cycle"). Then, close the door.

NOTE:

If you open the door when washing, the machine pauses and warning alarm rings, the display appears E1. When you close the door, the machine will keep on working after 10 seconds.

The 6 programme lights show the state of the dishwasher:

• All program lights off --> stand by
  • One of the program lights on --> cycle running
  • One of the program lights blinking --> pause

If all the lights begin to glimmer, that indicates the machine is out of order, please turn off the main power and water supply before calling a service.

Forget to Add Dish

A forgotten dish can be added any time before the detergent cup opens.

• Open the door a little to stop the washing.
  • After the spray arms stop working, you can open the door completely.
• Add forgotten dishes.
• Close the door, the dishwasher will work after ten seconds.

Operating Instructions

Warning!

It is dangerous to open the door when washing, because the hot water may scald you.

Switch Off the Dishwasher: The digital display appears "---" and the buzzer rings 6 times, only in this case the programme has ended.

• Switch off the dishwasher by pressing the "Power" button.
• Turn off the water tap!
• Open the door carefully. Hot steam may escape when the door is opened!
• Hot dishes are sensitive to knocks. The dishes should therefore be allowed to cool down around 15 minutes before removing from the appliance.
• Open the dishwasher's door and wait a few minutes before removing the dishes. In this way they will be cooler, and the drying will be improved.

Unloading the dishwasher

• It is normal that the dishwasher is wet inside.
• Empty the lower basket first and then the upper one. This will avoid water dripping from the upper basket onto the dishes in the lower one.

Filtering System

The filter is used to avoid the big remnants and other sundries getting inside the pump. The residue can obstruct the filter in sometime.

The filter system consists of a coarse filter, a flat (Main filter) and a micro filter (fine filter).

Flat filter

Food and debris will be trapped by a special jet on the lower spray arm.

Coarse filter

Big debris, such as bone and glass that could clog the drain will be trapped in the coarse filter. To remove an item caught in this filter, gently squeeze the taps on the top of this filter and lift it out.

Micro filter

This filter holds soil and food residue in the sump area and prevents it from being redeposit on the dishes during a cycle.

• Inspect the filters for obstructions every time the dishwasher has been used.
• By unscrewing the coarse filter, you can remove the filter system. Remove any food remnants and clean the filters under running water.

Opening the filter system

Step 1: Contra rotate the Coarse filter, and then lift it up.

Mechanical assembly diagram showing a piston-like component with directional arrows, no visible text or symbols

Step 2: Lift the Flat filter up

Mechanical component diagram showing a lever and base with an arrow indicating motion (no text or symbols)

NOTE: If operate from step 1 to step 2, the filter system will be removed, while operate from step 2 to step 1, the filter system will be installed.

Filter assembly

For best performance and results, the filter assembly must be cleaned. The filter efficiently removes food particles from the wash water, allowing it to be recirculated during the cycle. For this reason, it is a good idea to remove the larger food particles trapped in the filter after each wash cycle by rinsing the semicircular filter and cup under running water. To remove the filter assembly, pull on the cup handle in the upward direction. The entire filter assembly should be cleaned once a week. To clean the coarse filter and the micro filter, use a cleaning brush. Then, reassemble the filter parts as shown in the figures above and reinsert the entire assembly in the dishwasher, positioning in its seat and pressing downward. The dishwasher must never be used without the filters. Improper replacement of the filter may reduce the performance level of the appliance and damage dishes and utensils.

WARNING!

Never run the dishwasher without the filters in place. When cleaning the filters, don't knock on them. Otherwise, the filters could be contorted, and the performance of dishwasher could be debased.

Cleaning the Spray Arms

• It is necessary to clean the spray arms regularly for hard water chemicals will clog the spray arm jets and bearings.
• To remove the spray arms, screw off the nut clockwise to take out the washer on top of the spray arm and remove the arm. Wash the arms in soapy and warm water and use a soft brush to clean the jets. Replace them after rinsing thoroughly.

Caring for the Dishwasher

• To clean the control panel, use a lightly dampened cloth then dry thoroughly.
- To clean the exterior, use a good appliance polish wax.
- Never use sharp objects, scouring pads or harsh cleaners on any part of the dishwasher.

Protect Against Freezing

If your dishwasher is left in an unheated place during the winter, ask a service technical to:

• Cut off electrical power to the dishwasher.
• Turn off the water supply and disconnect the water inlet pipe from the water valve.
• Drain water from the inlet pipe and water valve. (Use a pan to catch the water)
• Reconnect the water inlet pipe to the water valve.
• Remove the filter in the tub and the bottom and use a sponge to use up water in sump

Mechanical device with rotating lever and base component (no visible text or symbols)

Cleaning the Door

To clean the edge around the door, you should use only a soft warm, damp rag. To prevent penetration of water into the door lock and electrical components, do not use a spray cleaner of any kind. Also, never use abrasive cleaners or scouring pads on the outer surfaces because they will scratch the finish. Some papers towels can also scratch or leave marks on the surface.

Warning!

Never use a spray cleaner to clean the door panel for it could damage the door lock and electrical components. It is not allowed to use the abrasive agent or some paper towel because of the risk of scratching or leaving spots on the stainless-steel surface.

How to Keep Your Dishwasher in Shape

• After every wash, turn off the water supply to the appliance and leave the door slightly open so that moisture
• Before cleaning or performing maintenance, always remove the plug from the socket. Do not run risks.
• To clean the exterior and rubber parts of the dishwasher, do not use solvents or abrasive cleaning products. Use only a cloth and warm soapy water. To remove spots or stains from the surface of the interior, use a cloth dampened with water and a little white vinegar, or a cleaning product made specifically for dishwashers.
• When you go on holiday, it is recommended that you run a wash cycle with the dishwasher empty and then remove the plug from the socket, turn off the water supply and leave the door of the appliance slightly open. This will help the seals last longer and prevent odours from forming in the appliance.
• If the appliance must be moved, try to keep it in the vertical position. If necessary, it can be positioned on its back.
• One of the factors that cause odours to form in the dishwasher is food that remains trapped in the seals. Periodic cleaning with a damp sponge will prevent this.

Attention!

The installation of the pipes and electrical equipment should be done by professionals.

Warning!

Electrical Shock Hazard! Disconnect electrical power before installing dishwasher. Failure to do so can result in death or electrical shock.

ERROR CODES

When some malfunctions happen, the appliance will display error codes to warn you.

Codes	Meanings	Possible Causes
E1	Door open	The door is opened when the dishwasher is operating
E2	Water inlet	Water inlet malfunction
E3	Water drainage	Water drainage malfunction
E4	Temperature sensor	Temperature sensor malfunction
E5	Overflow/leakage	Overflow occurs/Water leakage occurs
E6	Water leakage	Water leakage occurs
E7	Heating element	Abnormal heating

WARNING!

If overflow occurs, turn off the main water supply before calling a service. If there is water in the base pan because of an overfill or small leak, the water should be removed before restarting the dishwasher.

Before Calling for Service

Before calling for service, check the following list for problems probable causes and what you can do.

Problem	Possible Causes	What to Do
Dishwasher doesn't run	Fuse blown, or the circuit breaker acted	Replace fuse or reset circuit breaker. Remove any other appliances sharing the same circuit with the dishwasher.
	Power supply is not turned on	Make sure the dishwasher is turned on and the door is closed securely. Make sure the power cord is properly plugged into the wall socket.
	Water pressure is low	Check that the water supply is connected properly, and the water is turned on.
Drain pump doesn't stop	Overflow	The system is designed to detect an overflow. When it does, it shuts off the circulation pump and turns on the drain pump.
Noise	Some audible sounds are normal	Sound from detergent cup opening.
	Utensils are not secure in the baskets or something small has dropped into the basket	To ensure everything is secured in the dishwasher.
	Motor hums	Dishwasher has not been used regularly. If you do not use it often, remember to set it to fill and pump out every week, which will help keep the seal moist.
Suds in the tub	Improper detergent	Use only the special dishwasher detergent to avoid suds. If this occurs, open the dishwasher and let suds evaporate. Add 1 gallon of cold water to the tub. Close and latch the dishwasher, then start the "soak" wash cycle to drain out the water... Repeat if necessary.
	Spilled rinse agent	Always wipe up rinse agent spills immediately.
Stained tub interior	Detergent with colorant was used	Make sure that the detergent is the one without colorant.
Dishes and flatware not clean	Improper programImproper basket loading	Select a stronger program.Make sure that the action of the detergent dispenser and spray arms are not blocked by large dishware.
Spots and filming on glasses and flatware	1- Extremely hard water2-Low inlet temperature3-Overloading the dishwasher4-Improper loading5-Old or damp powder detergent6-Empty rinse agent dispenser7-Incorrect dosage of detergent	To remove spots from glassware:1-Take out all metal utensils out of the dishwasher.2-Do not add detergent.3-Choose the longest cycle.4-Start the dishwasher and allow it to run for about 18 to 22 minutes, then it will be in the main wash.5-Open the door to pour 2 cups of white vinegar into the bottom of the dishwasher.6-Close the door and let the dishwasher complete the cycle. If the vinegar does not work: Repeat as above, except use 1/4 cup (60 ml) of citric acid crystals instead of vinegar.
Cloudiness on glassware	Combination of soft water and too much detergent	Use less detergent if you have soft water and select the shortest cycle to wash the glassware and to get them clean.
Yellow or brown film on inside surfaces	Tea or coffee stains	Using a solution of 1/2 cup of bleach and 3 cups of warm water to remove the stains by hand.WARNING: You have to wait for 20 minutes after a cycle to let the heating elements cool down before cleaning interior; otherwise, burns will happen.
	Iron deposits in water can cause an overall film	You have to call a water softener company for a special filter.
White film on inside surface	Hard water minerals	To clean the interior, use a damp sponge with dishwasher detergent and wear rubber gloves. Never use any other cleaner than dishwasher detergent for the risk of foaming or suds.
The detergent dispenser lid cannot be closed properly	Clogged detergent residue is blocking the catch	Clean the detergent from the catch.
Detergent left in dispenser cups	Dishes block detergent Cups	Re-loading the dishes properly.
Steam	Normal phenomenon	There is some steam coming through the vent by the door latch during drying and water draining.
Black or grey marks on dishes	Aluminium utensils have rubbed against dishes	Use a mild abrasive cleaner to eliminate those marks.
Water standing on the bottom of the tub	This is normal	A small amount of clean water around the outlet on the tub bottom keeps the water seal lubricated.
Dishwasher leaks	Overfill dispenser or rinse aid spills	Be careful not to overfill the rinse aid dispenser.Spilled rinse aid could cause over suds and lead to overflowing. Wipe away any spills with a damp cloth.
	Dishwasher isn't level	Make sure the dishwasher is level.

Terms and Conditions

The following conditions apply in respect of the warranty given in this certificate:

1. Monaco Corporation Limited ("Monaco") warrants the following Robinhood products against manufacturing defects and faulty materials, under normal use and subject to the exclusions in this certificate, for a period of:

2. Rangehood, Ovens, Cooktops, Dishwashers, Refrigeration - 24 months from date of original purchase for domestic use.

3. Uniduct – 12 months from date of original purchase for domestic use.
4. Ironing centre – 12 months from date of original purchase for domestic use.
5. Sinks sets– 5 years on stainless steel sink including draining bench from date of original purchase for domestic use, 6 months on all stainless steel accessories, including wire rack, colander and tray from date of original purchase for domestic use.
6. Laundry Tub - 5 years on stainless bowl, 24 months on Tap, Cabinet and other components from the date of original purchase for domestic use.

"Original purchase", when used in this certificate, means purchase by the customer directly from Monaco or one of its approved suppliers.

1. This warranty is limited to the repair or replacement, at our option, within the warranty period of any component part which we at our discretion determine to contain faulty materials or a manufacturing defect in breach of this warranty. This warranty is subject to terms and conditions set out in this certificate.
2. The warranty only applies within New Zealand.
3. The customer must produce the original invoice or other purchase documentation as proof of the original purchase date.

Warranty exclusions

1. The warranty does not apply where, in Monaco's opinion:

2. The defect is caused by misuse, wear and tear, dirt, fire or accidental damage. The product has been repaired or serviced by an unauthorised person.

3. The product was not installed in accordance with our instructions.

4. The product was purchased overseas or was not designed for use in New Zealand. The product was not used, cleaned or cared for in accordance with our instructions.
   • The product was used outdoors.

5. In addition, this warranty does not extend to damage or defects which in our opinion, directly or indirectly arise from or are due to:

6. Exposing the product to acidic or corrosive materials or chemicals such as dyes, solvents, denture cleaner or acetone; Using inappropriate household cleaning products such as abrasive cream or powder cleansers, furniture polish, bleach, mentholated spirits, drain cleaners, sugar soap, metal pads and strongly alkaline or acidic cleaners;
   • Heat damage, including from washing the product at high temperatures;

7. Impact or mishandling the product, including the impact caused by objects scraped along, thrown or dropped on the product surface or excessive weight being placed on the product;
   • Structural or support changes in or affecting the building or the application where the product has been installed;

8. Failure to clean or maintain the product as recommended; or any other causes specified in the product information as being excluded from this warranty.

9. Variations with the colour or gloss within the product or any ageing or fading of colour, shine or gloss level over time are not covered by this warranty. The warranty does not cover visual imperfections or blemishes in the surface and edges of the product that were not brought to your supplier's attention at the time you inspected the product.

10. Costs incurred on installation or removal of a product, or any reinstallation of a product, or any associated costs, are not covered by this warranty.
11. Monaco will not be liable for consequential or indirect loss or damage whatsoever and however arising out of or in connection with the supply, performance or removal of the product, including (but not limited to) loss of profit, loss of revenue, loss of contract, loss of goodwill or increased cost of workings, even if due to the negligence of Monaco or any of its approved suppliers, employees or agents.
12. Charcoal filters and light bulbs are not covered by this warranty
13. This warranty and the statements contained in this certificate or other documents given to you do not exclude, restrict or modify the application of any term implied into this warranty by statute, provided that (to the extent any statutory provision permits Monaco to limit its liability for a breach of an implied condition or warranty) Monaco's liability for such breach is limited to the payment of the cost of replacing the product, repairing the product or acquiring an equivalent product.
14. Subject to clause 5, our obligations under this warranty are limited to those set out in this certificate, and this warranty is expressly instead of all other warranties, express or implied, including any implied warranty of merchantability or fitness for a particular purpose and notwithstanding any course of dealing between the parties or custom and usage in trade to the contrary.

Terms and conditions are subject to change.

Warranty Certificate (Australia)

Terms and Conditions

If you are a consumer under the Australian Consumer Law, our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and for compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure.

1. Shriro Australia Pty Limited ("Shriro") also warrants the following Robinhood products against manufacturing defects and faulty materials, under normal use and subject to the exclusions in this certificate, for a period of:

• Rangehood, Ovens, Cooktops, Dishwashers, Refrigeration - 24 months from date of original purchase for domestic use.
- Uniduct – 12 months from date of original purchase for domestic use.
- Ironing centre – 12 months from date of original purchase for domestic use.
- Sinks sets– 5 years on stainless steel sink including draining bench from date of original purchase for domestic use, 6 months on all stainless steel accessories, including wire rack, colander and tray from date of original purchase for domestic use.
- Laundry Tub - 5 years on stainless bowl, 24 months on Tap, Cabinet and other components from the date of original purchase for domestic use. "Original purchase", when used in this certificate, means purchase by the customer directly from Shriro or one of its approved suppliers.

1. This warranty is limited to the repair or replacement, at our option, within the warranty period of any component part which we at our discretion determine to contain faulty materials or a manufacturing defect in breach of this warranty. This warranty is subject to terms and conditions set out in this certificate.

2. The warranty only applies within Australia.

3. For warranty service outside of capital city metropolitan area or 30 km from nearest authorised service agent you will be liable for reasonable travelling expenses and the cost of transport of the product or parts to and from the service agent

4. To make a claim under this warranty, you must produce the original invoice or other purchase documentation as proof of the original purchase date. You must send your claim to Shriro Australia Pty Limited, 104 Vanessa Street, Kingsgrove, NSW, 2208, within 7 days of any alleged defect or failure of the product first becoming apparent. You are responsible for the expense of making a claim under this warranty.

This warranty is given by:

Shriro Australia Pty Ltd, ABN: 28 002 386 129

Telephone: [phone]

Facsimile: 1800 628 577

Email: [e-mail]

www.robinhood.com.au

Attention: Customer Services Manager

Warranty exclusions

1. The warranty does not apply where, in Shriro's opinion:

2. The defect is caused by misuse, wear and tear, dirt, fire or accidental damage. The product has been repaired or serviced by an unauthorised person.

3. The product was not installed in accordance with our instructions.
   • The product was purchased overseas or was not designed for use in Australia.
   • The product was not used, cleaned or cared for in accordance with our instructions.
   • The product was used outdoors.

4. All Robinhood Rangehoods are suitable for indoor use only and not suitable over BBQs or charcoal cookers designed for outdoor use.

5. In addition, this warranty does not extend to damage or defects which in our opinion, directly or indirectly arise from or are due to: exposing the product to acidic or corrosive materials or chemicals such as dyes, solvents, denture cleaner or acetone; using inappropriate household cleaning products such as abrasive cream or powder cleansers, furniture polish, bleach, mentholated spirits, drain cleaners, sugar soap, metal pads and strongly alkaline or acidic cleaners; heat damage, including from washing the product at high temperatures; impact or mishandling the product, including the impact caused by objects scraped along, thrown or dropped on the product surface or excessive weight being placed on the product; structural or support changes in or affecting the building or the application where the product has been installed; failure to clean or maintain the product as recommended; or any other causes specified in the product information as being excluded from this warranty.

6. Variations with the colour or gloss within the product or any ageing or fading of colour, shine or gloss level over time are not covered by this warranty. The warranty does not cover visual imperfections or blemishes in the surface and edges of the product that were not brought to your supplier's attention at the time you inspected the product.

7. We will not be responsible under this warranty for, nor pay the costs of, removing the existing product, or reinstalling the new product, or any associated costs or damages.

8. Charcoal filters and light bulbs are not covered by this warranty.

The benefits given by this warranty are in addition to other rights and remedies of consumers under any law in relation to the goods which cannot be excluded.

This warranty certificate is not intended to create a contract between Shriro Australia Pty Limited and the purchaser.
