SM-DPN-4S - Switch Smart-AVI - Free user manual and instructions
Find the device manual for free SM-DPN-4S Smart-AVI in PDF.
Pick your language and provide your email: we'll send you a specifically translated version.
| Product Type | 4-Port DVI Switch |
| Brand | Smart-AVI |
| Model | SM-DPN-4S |
| Number of Ports | 4 input, 1 output |
| Supported Video Resolution | Up to 1920x1200 @60Hz |
| Connector Type | DVI-D (24+1) female |
| Dimensions (W x D x H) | 17.5 x 10.5 x 4.5 cm |
| Weight | 0.5 kg |
| Power Supply | 5V DC, 1A |
| Power Consumption | < 5W |
| Switching Method | Push button or remote control (optional) |
| Supported Audio | Embedded DVI audio pass-through |
| EDID Support | Built-in EDID learning for each input |
| Material | Metal enclosure |
| Operating Temperature | 0°C to 50°C |
| Storage Temperature | -20°C to 60°C |
| Humidity | 20% to 90% non-condensing |
| Maintenance | Wipe with a dry, soft cloth. Do not use liquids. |
| Safety | Keep away from water and heat sources. Use only provided power adapter. |
| Spare Parts & Repairability | Contact Smart-AVI support for replacement parts. No user-serviceable components. |
| General Information | Compatible with DVI-D video sources and displays. Plug-and-play. |
| Package Contents | SM-DPN-4S unit, power adapter, user manual |
| Certifications | FCC, CE |
Frequently Asked Questions - SM-DPN-4S Smart-AVI
How do I switch between different video sources on the SM-DPN-4S?
Press the front panel button to cycle through inputs. Alternatively, an optional remote control can be used for quick switching.
What is the maximum resolution supported by this switch?
The SM-DPN-4S supports resolutions up to 1920x1200 @60Hz for DVI-D signals.
Does the switch require external power?
Yes, it requires a 5V DC power adapter (included). The switch does not draw power from the DVI connection.
Can I use this switch with a mix of computers and other DVI devices?
Yes, it works with any DVI-D source, including computers, laptops, and media players. Ensure all devices use DVI-D (digital) signals.
How does the switch handle EDID?
It automatically learns and stores EDID from each connected input to ensure proper video output for all sources.
Is audio supported through DVI?
Yes, if your DVI cables carry embedded audio (some graphics cards support this), the switch passes the audio through. Otherwise, use separate audio cables.
Can I use HDMI to DVI adapters with this switch?
Yes, passive adapters work. However, the signal remains DVI, so audio from HDMI will not be passed unless audio is embedded in the DVI signal.
What should I do if there is no video output?
Check power, cable connections, and try a different input. Ensure the display is set to the correct input source. EDID issues may require cycling power.
Can I mount the switch in a rack?
The SM-DPN-4S is a desktop unit and does not include rack-mount ears. If needed, you can place it on a shelf or use third-party mounting accessories.
Does the switch support hot pluggability?
Yes, you can connect or disconnect sources and displays while the switch is powered on without causing damage. However, always ensure proper grounding.
