Product Type	Remote Control
Brand	Pioneer
Model	CA-R-SSK.001
Dimensions (approx.)	10 cm x 5 cm x 2 cm
Weight (approx.)	50 g
Power Source	1x CR2025 3V Lithium Battery
Battery Life	Approximately 1 year under normal use
Wireless Technology	Infrared (IR)
Range	Up to 10 meters (line of sight)
Compatible Devices	Pioneer AV receivers, CD players, and other IR-controlled components
Main Functions	Power, volume, input selection, playback control, menu navigation
Number of Buttons	30
Programming	Pre-programmed for most Pioneer devices; learning function for others
Material	ABS plastic
Color	Black
Operating Temperature	0°C to 40°C
Storage Temperature	-20°C to 60°C
Maintenance	Clean with a soft, dry cloth. Do not use liquids or solvents.
Safety	Keep away from water and high temperatures. Remove battery if unused for long periods.
Spare Parts	CR2025 battery (widely available)
Repairability	Not user-serviceable; replace battery only
General Information	Designed to replace original remote for select Pioneer devices. Refer to compatibility list.

Frequently Asked Questions - CA-R-SSK.001 PIONEER

How do I replace the battery in my Pioneer CA-R-SSK.001 remote?

Slide the battery cover off the back, remove the old CR2025 battery, and insert a new one with the positive side facing up. Replace the cover.

What devices is the CA-R-SSK.001 compatible with?

It is designed for Pioneer AV receivers, CD players, and other infrared-controlled components. Check your device's manual for specific model compatibility.

What is the range of the remote?

The infrared range is up to 10 meters in a straight line without obstacles.

How do I pair the remote with my device?

No pairing is needed. The remote uses infrared (IR) signals and works immediately when pointed at the device. Ensure there are no obstacles.

The remote is not working. What should I do?

Check if the battery is inserted correctly and has charge. Replace with a new CR2025 battery. Clean the IR emitter and receiver with a dry cloth. Ensure no obstacles block the signal.

Can I program the remote to control non-Pioneer devices?

This model may have a learning function for some non-Pioneer devices. Refer to the manual for programming instructions. Not all brands are supported.

How do I clean the remote?

Use a soft, dry cloth to wipe the surface. Do not use water, alcohol, or abrasive cleaners.

Is the remote backlit?

No, the Pioneer CA-R-SSK.001 remote does not have backlighting. Buttons are not illuminated.

What type of battery does the remote use?

It uses a single CR2025 3V lithium coin cell battery.

How long does the battery last?

Under normal usage, the battery lasts approximately one year. Replace it when the remote becomes unresponsive or the range decreases.

USER MANUAL CA-R-SSK.001 PIONEER

Coiled automotive electrical wiring with connectors and a CANBRIDGE module (no visible text or symbols)

Close-up of a black CAMBRIDGE automotive connector with wires and connectors, no visible text or symbols on the main subject.

Close-up of a CAMBRIDGE cable connector with wires and connectors, no visible text or symbols on the main subject.

Installation must be performed by a qualified professional installer only. The manufacturer is not liable for any kind of incidental or indirect damages. 08/2014 - All rights reserved. No liability for misprints
