HDQ11-10 Sd - Tumble dryer Hiberg - Free user manual and instructions

Brand	Hiberg
Model	HDQ11-10 Sd
Product Type	Tumble Dryer
Dimensions (H x W x D)	85 cm x 60 cm x 60 cm
Weight	50 kg
Power Supply	230 V, 50 Hz
Power Consumption	2000 W
Drying Capacity	11 kg
Energy Class	C
Drying Programs	Cotton, Synthetics, Delicates, Mix, Quick 30 min, Extra Dry, Iron Dry, Cupboard Dry, Sport, Shirts, Jeans, Eco
Sensor Drying	Yes
Anti-Crease Function	Yes (up to 2 hours)
Delay Start	Yes (up to 24 hours)
Drum Material	Stainless Steel
Lint Filter	Yes, clean after each cycle
Condenser Maintenance	Clean condenser unit every 3 months
Water Tank Capacity	4.5 L
Noise Level	65 dB(A)
Child Lock	Yes
Overheating Protection	Yes
Spare Parts Availability	Available from Hiberg
Repairability Index	7.5 / 10

Frequently Asked Questions - HDQ11-10 Sd Hiberg

How do I install the Hiberg HDQ11-10 Sd tumble dryer?

Place the dryer on a stable, level surface. Allow at least 10 cm clearance on all sides for ventilation. Connect the power cord to a grounded outlet (230 V). For vented models, attach the exhaust hose to a suitable outlet. For condenser models, ensure the water tank is properly inserted or connect a drain hose.

What is the maximum drying capacity of this dryer?

The maximum drying capacity is 11 kg for cotton items. For synthetics and delicates, reduce the load to about 5-6 kg to ensure efficient drying.

How do I clean the lint filter?

Open the door and pull out the lint filter located at the bottom of the door opening. Remove lint by hand or with a soft brush. Rinse under running water if necessary. Let it dry completely before reinserting. Clean after every cycle.

Why is my dryer taking too long to dry clothes?

Possible causes: overloaded drum, clogged lint filter, dirty condenser, or selected program not suitable for fabric. Clean the filter and condenser, reduce load, and select a program appropriate for the fabric type. Also ensure room temperature is above 5°C.

How do I empty the water tank?

Pull out the water tank located at the bottom front of the dryer. Empty it into a sink. Replace the tank firmly until it clicks. The indicator light will turn off. For continuous drainage, connect a hose to the drain outlet.

Can I install the dryer in a cupboard or tight space?

Yes, but ensure adequate ventilation. Maintain at least 10 cm clearance on the sides, top, and back. The room must have good airflow to prevent overheating. Do not block the ventilation grilles.

What should I do if the dryer displays an error code?

Refer to the user manual for specific error codes. Common codes: E1 (water tank full), E2 (lint filter blocked), E3 (overheating). Perform the recommended action: empty tank, clean filter, or let the dryer cool down. If the error persists, contact Hiberg support.

How do I use the delay start function?

Select your drying program and then press the Delay button. Use the +/- buttons to set the delay time (from 1 to 24 hours). Press Start. The dryer will begin drying after the set delay. This is useful to take advantage of off-peak electricity rates.

Is the dryer safe for wool or delicate items?

Yes, but use the Delicates or Wool program with low heat. Place delicate items in a mesh laundry bag. Do not overload. Check the care label on garments before drying.

Where can I find spare parts for this dryer?

Spare parts are available from Hiberg authorized dealers or online at the Hiberg website. Common parts include lint filters, door gaskets, heating elements, and belts. Use only genuine Hiberg parts to maintain warranty.

USER MANUAL HDQ11-10 Sd Hiberg

Three diagrams showing a machine on inclined planes with a cross symbol indicating force or motion, no text or labels present.

Diagram of a washing machine with a gasket and wheels, no text or symbols present

Illustration of a washing machine connected to a sink with a piping bag (no text or symbols)

Line drawing of a washing machine with an open door and internal vent, showing no text or symbols.
