Product Type	Charcoal Barbecue / Griddle
Brand	Fieldmann
Model	FZG 1017
Overall Dimensions (L x W)	68 x 108 cm
Cooking Surface Diameter	50.5 cm
Height (adjustable)	74 / 75.5 / 77 cm
Lid Dimensions	58 x 27 cm
Net Weight	13 kg
Fuel Type	Charcoal
Max Charcoal Capacity	4.2 kg
Cooking Grid Material	Chrome-plated steel
Thermometer	Yes
Wheels	Yes (3 wheels)
Portable	Yes
Assembly Required	Yes
Safety Features	Do not use indoors; use approved firelighters; keep children away
Usage Location	Outdoor only
Compliance	EN 1860-3 for firelighters
Maintenance	Regular cleaning of cooking grills; avoid flammable liquids
Included Accessories	Lid, cooking grid, assembly hardware

Frequently Asked Questions - FZG 1017 Fieldmann

How do I assemble the Fieldmann FZG 1017 barbecue?

Assembly is required. Follow the step-by-step instructions in the manual. Use protective gloves and ensure all parts are present before starting. The manual includes diagrams for each step.

What type of fuel should I use?

Use only charcoal. Do not use spirit, petrol, or other flammable liquids. Use firelighters that comply with EN 1860-3.

How much charcoal can I put in the barbecue?

The maximum charcoal quantity is 4.2 kg. Do not exceed this amount to avoid unsafe operation.

Can I use this barbecue indoors?

No, never use this barbecue indoors or in confined spaces (tents, caravans, etc.). It produces carbon monoxide which can be fatal.

How do I light the charcoal safely?

Place the charcoal on the grate, use approved firelighters, and wait at least 30 minutes until the charcoal is covered with a layer of grey ash before cooking. Never use alcohol or petrol.

What are the dimensions of the cooking surface?

The grilling surface has a diameter of 50.5 cm.

Is the height adjustable?

Yes, the barbecue has three adjustable heights: 74 cm, 75.5 cm, and 77 cm.

How do I clean the barbecue?

Regularly clean the cooking grills after use. Use a grill brush and warm soapy water. Ensure the barbecue is cool before cleaning. Do not use flammable liquids for cleaning.

What safety precautions should I take?

Keep children and pets away. Do not move the barbecue while it is hot. Always use on a horizontal, stable surface. Use potholders or gloves when handling hot parts.

Does the barbecue come with a thermometer?

Yes, the lid includes a thermometer to monitor cooking temperature.

USER MANUAL FZG 1017 Fieldmann

Abstract black-and-white spiral pattern with no text or symbols

FIELDMANN®

Home & Garden Performance

Line drawing of a portable grill with three wheels and a dome top (no text or symbols)

FZG 1017

Read these instructions carefully

Carefully dispose of all plastic bags and keep them out of the reach of children.

Please read the "Safety" section of this instruction booklet on the safety precautions to take before using your charcoal barbecue.

Check the components and ensure that you have all the parts listed. If not, contact your local shop, which will be able to help you

Take a moment to familiarise yourself with the content and before beginning assembly, check that all of the holes are clean and that there is no paint residue in them.

When you are ready to start assembly, ensure that you have lots of space and that the area is clean.

Do not use the barbecue in a confined and/or habitable space e.g. houses, tents, caravans, motor homes, boats. Danger of carbon monoxide poisoning fatality.

Take note of all of the following instructions:

1. The barbecue must be installed on a horizontal and stable surface before use.
2. The barbecue must be hot and the charcoal must remain lit for at least 30 minutes before beginning to cook the food. When the charcoal forms a grey layer of ash, you can start to cook.
3. Before starting to cook, wait until a layer of ash covers the charcoal.
   4.WARNING! This barbecue will become very hot, do not move it during operation!
   5.WARNING! Do not use this barbecue indoors!

4. Do not use spirit or petrol for lighting or re-lighting! Use only firelighters complying to EN 1860-3!

5. WARNING! Keep children and pets away from this barbecue.

6. This barbecue complies with the regulations in force.
7. However, using it requires a minimum amount of monitoring and precautions.
8. In particular, do not use alcohol, petrol or any other flammable liquid to light or rekindle the fire, and do not let children near the burner.
9. Regrettably, a large number of accidents occur each year. The resulting burns are particularly serious in children: because of their size, their faces are more often than not at the same height as the burner.
10. Do not increase the flames in a charcoal barbecue using a fire lighting product or any other flammable product. Regularly clean the cooking grills.
11. To avoid ingesting significant amounts of benzopyrene (a decomposition product from carcinogenic fats), keep the barbecue grill as far as possible from the heat source, or opt for an upright cooking model.
12. Fuel to use: charcoal.
    15.Maximum quantity to be used: 4.2kg

Precautions:

1. Use potholders, gloves or a utensil to adjust or move a part of the barbecue (for example, the air control lid or the handle, ash tray or non-adjustable cooking grill) during use.
2. Use protective gloves to assemble the barbecue.

Technical specifications
Grill size	68 x 108 cm
Grilling surface	50,5 cm
Grilling surface height	74 / 75,5 / 77 cm
Chrome cooking grid	√
Stacking area	×
Cover / lid	58 x 27 cm
Thermometer	√
Weight	13 kg

Any change in the text and specification reserved.

The user's manual is in the languages version.

Changes in text, design and technical specifications may vary without prior notification and We reserve the right of their change.

A29		M6 x 16	x 2
A30		M6 x 12	x 9
A31		M5 x 12	x 1
A32		M10 Nut	x 2
A33		M6 Nut	x 12

A34		M6 Nut	x 1
A35		M5 Nut	x 1
A36		∅6 x 16	x 12
A37		23 x 23	x 2

1

2

3

4

5

6

7

8

9

10
