| Brand | JVC |
| Model | vMix KM-IP8S4 |
| Product Type | Network Camera Controller |
| Dimensions (approx) | 320 x 200 x 50 mm |
| Weight (approx) | 1.5 kg |
| Power Supply | 12V DC, 2A |
| Connectivity | Ethernet (PoE), RS-232, RS-422, SDI outputs |
| Control Protocol | VISCA over IP, ONVIF |
| Number of Supported Cameras | Up to 8 |
| Key Features | Joystick control, assignable buttons, LCD display, preset memory |
| Included Accessories | Power adapter, Ethernet cable, mounting brackets, user manual (PDF) |
| Manual Pages | 249 |
| Language | English |
| Cleaning Instructions | Use a dry, soft cloth; avoid liquids and abrasives |
| Safety Warnings | Do not expose to moisture; use only specified power supply |
| Repairability | Refer to manual for replaceable parts; contact JVC support |
Frequently Asked Questions - vMix KM-IP8S4 JVC
How do I connect the KM-IP8S4 to my network?
Connect an Ethernet cable from the controller to your network switch. Ensure PoE is available if not using the power adapter. The controller will obtain an IP address via DHCP by default.
How many cameras can I control with this device?
The KM-IP8S4 supports up to 8 cameras simultaneously using VISCA over IP or ONVIF protocols.
How do I assign a camera to a preset?
Move the joystick to the desired position, then press and hold the PRESET button and a number button (1-8) to save. Recall by pressing the number button alone.
What should I do if the controller does not power on?
Check the power connection: ensure the power adapter is plugged in or PoE is active. Verify the Ethernet cable is functional. Try a different power source.
Can I use the KM-IP8S4 with non-JVC cameras?
Yes, it supports standard VISCA over IP and ONVIF protocols, so it can control compatible cameras from other brands. Confirm camera compatibility in its manual.
How do I update the firmware?
Download the latest firmware from the JVC support website. Connect the controller via USB or Ethernet, then follow the update instructions in the manual (pages 200-210).
What is the maximum cable length for RS-232?
For reliable operation, keep RS-232 cable length under 15 meters. For longer runs, use RS-422 or a serial extender.
How do I reset the controller to factory defaults?
Press and hold the MENU button while powering on the device. Navigate to 'Factory Reset' using the joystick and confirm. All settings will be erased.
Can I control the cameras remotely via a web interface?
Yes, the KM-IP8S4 has a built-in web server. Enter its IP address in a browser to access remote control and configuration.
What types of cameras are compatible?
The controller works with PTZ cameras that support VISCA over IP or ONVIF Profile S/T. Examples include JVC KY-PZ100, Sony BRC series, and Panasonic AW series.
