| Brand | Hager |
| Model | FWQ34P1 |
| Product Type | Electrical Protection Device (Circuit Breaker) |
| Rated Current | 32 A |
| Number of Poles | 4 |
| Rated Voltage | 400 V AC |
| Breaking Capacity | 10 kA |
| Mounting Type | DIN Rail |
| Dimensions (H x W x D) | 85 mm x 36 mm x 70 mm |
| Weight | 0.2 kg |
| Power Supply | Mains powered |
| Protection Class | IP20 |
| Operating Temperature | -25°C to +70°C |
| Certifications | CE, RoHS |
| Material | Thermoplastic, Copper conductors |
| Functions | Overcurrent protection, Short circuit protection |
| Maintenance | No regular maintenance required; keep clean and dry |
| Safety | Install and operate according to local regulations; disconnect power before servicing |
| Spare Parts | Contact Hager support for replacement parts |
Frequently Asked Questions - FWQ34P1 HAGER
What does the model FWQ34P1 refer to?
The FWQ34P1 is a 4-pole circuit breaker manufactured by Hager, designed for overcurrent and short circuit protection in electrical installations.
What is the rated current of the FWQ34P1?
The rated current is 32 A, suitable for protecting circuits with a nominal load up to this value.
Can the FWQ34P1 be used in residential applications?
Yes, it is commonly used in residential and light commercial distribution boards for protecting circuits like lighting, sockets, and appliances.
What is the breaking capacity of this breaker?
The breaking capacity is 10 kA at 400 V AC, meaning it can safely interrupt short circuits up to 10,000 amps.
Does the FWQ34P1 require any special maintenance?
No, it is a maintenance-free device. However, it should be kept clean and free from moisture to ensure reliable operation.
How do I install the FWQ34P1?
It snaps onto a DIN rail (35 mm standard). Connect the phase conductors to the input and output terminals according to the wiring diagram provided in the manual.
Is the FWQ34P1 compatible with other Hager accessories?
Yes, it is compatible with Hager's modular system, including auxiliary contacts, shunt trips, and busbars.
What should I do if the breaker trips frequently?
First, identify and rectify the overload or short circuit. If the issue persists, the breaker may be faulty and should be replaced by a qualified electrician.
Where can I find the user manual?
The user manual is available for free download in PDF format from notice-facile.com or the Hager website.
What is the warranty period for the FWQ34P1?
Hager typically offers a 2-year warranty for this product. Check the specific terms in your purchase documentation.
