Mythos MYX110-70FPC - Kitchen sink FRANKE - Free user manual and instructions

Product Type	Kitchen Sink
Brand	Franke
Model	Mythos MYX110-70FPC
Material	18/10 Stainless Steel
Finish	Stainless Steel (brushed)
Overall Dimensions	740 x 440 mm
Bowl Dimensions	700 x 400 x 200 mm
Bowl Capacity	56 Liters
Bowl Radius	25 mm
Installation Type	Undermount
Minimum Cabinet Base	800 mm
Cut-Out Dimensions	700 x 400 mm, corner radius 25 mm
Cut-Out Template Included	Yes
Waste Outlet	Semi Integrated Waste
Overflow	Yes
Tap Holes	No (requires benchtop mounting)
Remote Waste Control	Yes, push button (requires 35 mm hole in benchtop)
Sound Deadening	Sound Deadening Pads
Included Accessories	DT288 Extension Drainer, RM081 Rollamat
Available Accessories (optional)	PB835 Push Button Waste, CBP082 Chopping Board, SB398 Strainer Bowl
Warranty	50 Years
Food Preparation Area	Food Preparation Centre

Frequently Asked Questions - Mythos MYX110-70FPC FRANKE

What is the material of the Franke Mythos MYX110-70FPC sink?

The sink is made of 18/10 stainless steel, which is a high-quality, durable, and corrosion-resistant material commonly used in professional kitchens.

What are the overall dimensions of the sink?

The sink measures 740 x 440 mm overall, with a bowl size of 700 x 400 x 200 mm and a capacity of 56 liters.

Can I install a tap directly on the sink?

No, the sink has no tap holes. The tap must be installed on the benchtop. The sink does have a semi-integrated waste outlet and overflow.

How does the remote waste control work?

The sink features a push button remote waste system. A 35 mm hole is required in the benchtop for the push button mechanism, allowing you to open and close the waste without reaching into the water.

What is the recommended base cabinet width for undermount installation?

A minimum 800 mm cabinet base is recommended to ensure proper support and easy installation.

Does the sink come with a cut-out template?

Yes, a cut-out template is included. However, it is recommended to use the actual sink as a template for accurate installation. The cut-out dimensions are 700 x 400 mm with a 25 mm corner radius.

What accessories are included with the sink?

The sink comes with a DT288 Extension Drainer and a RM081 Rollamat (a protective mat). Optional accessories include a push button waste, chopping board, and strainer bowl.

How do I clean and maintain the stainless steel sink?

Clean with mild soap and warm water, using a soft cloth. Avoid abrasive cleaners or scouring pads. For stubborn stains, use a stainless steel cleaner. Wipe dry to prevent water spots and maintain the brushed finish.

What is the warranty period for this sink?

Franke offers a 50-year warranty for the Mythos MYX110-70FPC sink, covering defects in material and workmanship under normal domestic use.

Is the sink designed for food preparation?

Yes, the sink features a Food Preparation Centre area, making it convenient for washing and preparing ingredients. The large bowl and accessories like the chopping board enhance its functionality.

USER MANUAL Mythos MYX110-70FPC FRANKE

Top-down view of a minimalist kitchen sink with a circular hole on the top surface (no text or symbols)

ACCESSORIESPRODUCT INFORMATION -

Included Accessory

Available Accessory

Installation	Undermount
Dimensions	740 x 440mm
Cabinet Base	800mm
Bowl Size	700 x 400 x 200mm/56L
Bowl Radius	25mm
Cut-Out Size	700 x 400mm, cr=25
Cut-Out Template	Yes
Waste Outlet	Semi Integrated Waste
Overflow	Yes
Tap Holes	No
Remote Waste	Yes (35mm hole required in benchtop)
Finish	Stainless Steel
Warranty	50 Years

NOTE: Cut-out dimensions are a guide only, please use the actual sink as your template.

DT288 Extension Drainer

RM081 Rollamat

PB835 Push Button Waste

CBP082 Chopping Board

SB398 Strainer Bowl

FEATURES & BENEFITS

Food Preparation Centre

18/10 Stainless Steel

Push Button Remote Waste

Sound Deadening Pads
