| Product Type | Thermal & Optical PTZ Camera |
| Dimensions | Ø 230 mm × 350 mm |
| Weight | 5.5 kg |
| Power Supply | AC 24V / PoE+ |
| Main Functions | 360° continuous pan, thermal imaging, visible light, intelligent tracking, alarm I/O |
| Cleaning | Use soft dry cloth; avoid solvents and abrasive materials |
| Safety | Complies with CE, FCC, UL; use proper grounding and surge protection |
| Spare Parts and Repairability | Contact authorized service center; replaceable lens and sensor module |
| General Information | For outdoor use, IP66 rated, operating temperature -40°C to 65°C |
Frequently Asked Questions - TPC-PT8441D-AC Dahua Technology
How do I set up the camera for the first time?
Connect the camera to a PoE switch or AC 24V power. Use the config tool or web browser to access the default IP (192.168.1.108). Follow the wizard to set network parameters and admin password.
What is the maximum resolution of the thermal sensor?
The thermal sensor supports up to 640x512 pixel resolution, with a frame rate of 30 fps.
Can the camera be used in extreme weather?
Yes, it has an IP66 rating and operates from -40°C to 65°C, suitable for harsh outdoor environments.
How far can the thermal camera detect a human?
The detection range for a human (1.8m x 0.5m) is up to 1,800 meters under good conditions.
What type of network cable is recommended?
Use a shielded Cat6 or better cable for PoE+ and reliable data transmission, with a maximum length of 100 meters.
How do I perform a factory reset?
Press and hold the reset button inside the camera housing for 10 seconds while power is applied. The camera will reboot to default settings.
Is the camera compatible with third-party VMS software?
Yes, it supports ONVIF Profile G/T/S and can integrate with major VMS platforms like Milestone, Genetec, and Dahua VMS.
How often should I clean the camera lens?
Clean the lens every 3-6 months or when image quality degrades. Use a microfibre cloth with lens cleaner specifically for optical surfaces.
What is the warranty period?
Standard warranty is 3 years from the date of purchase. Extended warranties are available through authorized dealers.
Can I mount the camera upside down?
Yes, the camera supports inverted mounting. Use the ceiling mount accessory. Ensure the image rotation is set to 180° in the settings.
