THPD70 - Tumble drier TEKA - Free user manual and instructions
Find the device manual for free THPD70 TEKA in PDF.
Pick your language and provide your email: we'll send you a specifically translated version.
| Product Type | Tumble dryer (condenser) |
| Brand | Teka |
| Model | THPD70 |
| Dimensions (H x W x D) | 85 cm x 60 cm x 60 cm |
| Net Weight | Approx. 40 kg |
| Power Supply | 220-240 V ~ 50 Hz |
| Rated Power | 2000 W |
| Drying Capacity | 7 kg |
| Energy Efficiency Class | B |
| Annual Energy Consumption | Approx. 560 kWh |
| Drying Programs | Cotton, Synthetics, Delicates, Mixed, Quick, Eco, Timed |
| Noise Level | 65 dB(A) |
| Lint Filter Type | Removable mesh filter |
| Door Type | Reversible hinge |
| Display | LED digital display |
| Control Type | Electronic dial and buttons |
| Child Lock | Yes |
| Anti-crease Function | Yes |
| Condenser Cleaning | Manual |
| Water Tank Capacity | 3.5 L |
| Spare Parts Availability | Available via authorized service centers |
| Reparability Index | 7.5 / 10 |
| Manual Languages | EN, FR, DE, IT, ES, NL, PT, GR |
Frequently Asked Questions - THPD70 TEKA
What is the maximum drying capacity of the Teka THPD70?
The maximum drying capacity is 7 kg for cotton programs. For synthetics and delicates, reduce the load to 3.5 kg.
How do I clean the lint filter?
Remove the lint filter located at the door opening. Clean it under running water or with a soft brush. Ensure it is completely dry before reinserting.
Does the THPD70 have a child lock?
Yes, the child lock can be activated by pressing and holding the 'Key' button for 3 seconds. The display will show a lock symbol.
What is the noise level of this dryer?
The noise level is approximately 65 dB(A) during normal operation.
Can the door hinge be reversed?
Yes, the door is reversible. You can change the opening direction by following the instructions in the user manual.
How often should I clean the condenser?
Clean the condenser every 30 cycles or when the 'Clean Condenser' indicator lights up. Use a vacuum cleaner or rinse with water.
What should I do if the dryer does not start?
Check that the door is fully closed, the power plug is connected, and the program is selected. Also check the household fuse or circuit breaker.
Is the Teka THPD70 energy efficient?
The dryer is rated energy class B, with an estimated annual energy consumption of 560 kWh. Using Eco mode reduces consumption.
Can I install the dryer on top of a washing machine?
Yes, if you use the optional stacking kit (purchased separately). Ensure the washing machine is stable and suitable for stacking.
Where can I find spare parts for the THPD70?
Spare parts are available through authorized Teka service centers. You can find the nearest service center on the Teka website.
User questions about THPD70 TEKA
0 question about this device. Answer the ones you know or ask your own.
Ask a new question about this device
No questions yet. Be the first to ask one.
Download the instructions for your Tumble drier in PDF format for free! Find your manual THPD70 - TEKA and take your electronic device back in hand. On this page are published all the documents necessary for the use of your device. THPD70 by TEKA.
