| Product Type | Professional Loudspeaker |
| Dimensions (W x H x D) | 400 mm x 600 mm x 350 mm |
| Weight | 25 kg |
| Power Handling (RMS) | 200 W |
| Power Handling (Peak) | 400 W |
| Frequency Response | 50 Hz - 20 kHz |
| Impedance | 8 ohms |
| Sensitivity (1W/1m) | 95 dB |
| Enclosure Type | Ported |
| Input Connectors | 2 x Speakon NL4 |
| Finish | Black textured paint |
| Magnet Type | Ferrite |
| Crossover Frequency | 2.5 kHz |
| Recommended Amplifier Power | 200 - 400 W |
| Operating Temperature Range | -10°C to 50°C |
| Cleaning Instructions | Wipe with a soft dry cloth |
| Safety Precautions | Use stable mounting hardware; do not expose to moisture |
| Spare Parts & Repair | Contact authorized TOA dealer |
| General Information | Professional-grade loudspeaker for sound reinforcement |
Frequently Asked Questions - SX-2000SM TOA
How do I connect the SX-2000SM to an amplifier?
Use Speakon NL4 cables. Connect the amplifier output to the Speakon input on the speaker. Ensure proper polarity (+1/-1).
What amplifier power is recommended for this speaker?
An amplifier delivering 200-400 W RMS at 8 ohms is recommended. Avoid clipping to prevent damage.
What is the impedance of the speaker?
The SX-2000SM has a nominal impedance of 8 ohms.
How should I clean the speaker cabinet?
Wipe the cabinet with a soft dry cloth. Do not use solvents or water, as they may damage the finish.
Can I mount the speaker on a wall or ceiling?
Yes, but only use appropriate mounting hardware rated for the speaker's weight (25 kg). Ensure secure attachment to structural supports.
What is the frequency response of the SX-2000SM?
The frequency response is 50 Hz - 20 kHz, suitable for full-range sound reproduction.
The speaker is not producing sound. What should I check?
Check cable connections, amplifier power, and ensure the speaker is not in mute. Verify signal source and amplifier settings.
Is the SX-2000SM covered by a warranty?
Yes, TOA provides a limited warranty. Contact your dealer or TOA support for details specific to your region.
Does the speaker have protection against overloading?
The speaker incorporates thermal protection and a built-in crossover. However, prolonged low-frequency distortion can damage the driver.
What is the best placement for optimal sound?
Position speakers at ear level and away from corners to avoid bass buildup. For stereo, form an equilateral triangle with listening position.
