PKNB39XI30 - Fridge PITSOS - Free user manual and instructions
Find the device manual for free PKNB39XI30 PITSOS in PDF.
Pick your language and provide your email: we'll send you a specifically translated version.
| Product Type | Refrigerator |
| Model | PKNB39XI30 |
| Brand | PITSOS |
| Color | Stainless Steel |
| Dimensions (H x W x D) | 1800 x 595 x 650 mm |
| Weight | 65 kg |
| Power Supply | 220-240 V, 50 Hz |
| Energy Class | A++ |
| Annual Energy Consumption | 180 kWh/year |
| Total Net Capacity | 340 L |
| Refrigerator Capacity | 240 L |
| Freezer Capacity | 100 L |
| Noise Level | 38 dB(A) |
| Climate Class | SN-T |
| Temperature Control | Electronic |
| Defrost Type | Auto Defrost (Frost Free) |
| Number of Shelves | 4 |
| Door Material | Metal |
| Handle Type | Integrated Handle |
| Lighting | LED |
| Safety Features | Child Lock, High Temperature Alarm |
| Cleaning | Wipe with damp cloth, non-abrasive |
| Spare Parts Availability | 7 years after production |
| Repair Index | 8.5/10 |
Frequently Asked Questions - PKNB39XI30 PITSOS
How do I adjust the temperature in my PITSOS PKNB39XI30 refrigerator?
Use the electronic control panel inside the fridge. Press the temperature setting button to cycle through available temperatures. The recommended setting is 4°C for the fridge and -18°C for the freezer.
Why is my refrigerator not cooling properly?
Check if the door is fully closed and the seals are clean. Ensure the vents inside are not blocked. If the problem persists, the thermostat may need adjustment. Refer to the manual for troubleshooting.
How often should I clean the condenser coils?
Clean the condenser coils at least once a year to maintain efficiency. Use a vacuum cleaner or a soft brush. This helps reduce energy consumption.
What does the alarm sound mean?
The alarm sounds if the door is left open for too long or if the temperature rises above safe levels. Close the door properly; the alarm should stop. If it continues, check for a power outage or malfunction.
Can I install the refrigerator in a garage?
This model has climate class SN-T, which operates from 10°C to 43°C. Avoid temperatures below 10°C as the freezer may not maintain proper freezing conditions.
How do I defrost the freezer?
The PKNB39XI30 features auto defrost (frost free). Manual defrost is not required. If ice builds up, check that the door seals properly and the defrost system is not blocked.
What is the energy consumption of this refrigerator?
The annual energy consumption is approximately 180 kWh, based on standard testing conditions. Actual consumption may vary depending on usage and environment.
How do I change the door swing direction?
This model is not designed for reversible doors. The door hinges are fixed. If you need opposite swing, consider a different model.
Where can I find spare parts for my refrigerator?
Spare parts are available for up to 7 years after production. Contact PITSOS customer service or an authorized dealer. You can also check online using the model number PKNB39XI30.
What should I do if the refrigerator stops working?
Check the power cord and circuit breaker. If the appliance still does not work, contact a qualified technician. Do not attempt to repair internal components yourself.
