Product Type	Bookshelf Speaker
Brand	PSB
Model	Imagine XB
Dimensions (H x W x D)	216 x 140 x 175 mm
Weight	2.5 kg (5.5 lbs)
Enclosure Type	Bass reflex (ported)
Driver Configuration	4-inch woofer, 1-inch tweeter
Frequency Response	50 Hz - 20 kHz
Impedance	8 ohms
Sensitivity	90 dB
Recommended Amplifier Power	10 - 80 watts RMS
Warranty (Loudspeaker)	5 years
Placement	Bookshelf or stand
Connection	Binding posts for speaker wire
Cleaning	Wipe with a damp cloth; avoid solvents
Safety	Avoid exposure to moisture and extreme temperatures

Frequently Asked Questions - Imagine XB PSB

How do I connect the PSB Imagine XB speakers?

Use standard speaker wire. Connect the positive terminal on the speaker to the positive output on your amplifier, and negative to negative. Ensure proper polarity for best sound.

What is the ideal placement for the Imagine XB?

Place the speakers on bookshelves or stands at ear level. For surround sound setups, position them at the sides or rear of the listening area as per 5.1 or 7.1 guidelines.

What is the warranty period for the Imagine XB?

PSB Speakers provides a 5-year warranty for loudspeaker drivers and cabinets. Amplifiers (if any) have a separate 1-year warranty.

Can I use the Imagine XB as a center channel speaker?

While primarily a bookshelf speaker, you can use a single Imagine XB horizontally as a center channel. However, PSB offers dedicated center channel models for optimal performance.

How should I clean my PSB Imagine XB speakers?

Use a soft, damp cloth to wipe the cabinet. Do not use abrasive cleaners or solvents. For the grille, gently vacuum or use a lint roller.

What amplifiers are recommended for the Imagine XB?

Any amplifier delivering 10-80 watts RMS per channel at 8 ohms will work well. High-quality receivers or integrated amps are ideal.

Does the Imagine XB have a bass reflex port?

Yes, it features a rear-firing bass reflex port to enhance low-frequency output. Ensure adequate space behind the speaker (at least 6 inches).

What are the dimensions of the PSB Imagine XB?

The speaker measures approximately 216 x 140 x 175 mm (H x W x D). Exact dimensions may vary slightly; refer to the specification sheet.

Is the Imagine XB magnetically shielded?

No, the Imagine XB is not magnetically shielded. If placing near a CRT television, maintain a distance of at least 12 inches to avoid image distortion.

Can I get replacement parts for the Imagine XB?

Contact PSB or an authorized dealer for replacement drivers or parts. Repairs should be done by qualified personnel to maintain warranty.

USER MANUAL Imagine XB PSB

5.1 Surround Speaker Placement

7.1 Surround Speaker Placement

4.

For detailed connection and setup instructions, please download the full multi-language Owner's Manual from www.psbspeakers.com

For additional support with your speakers please visit the PSB Lounge at www.psbspeakers.com/lounge

633 Granite Court, Pickering, Ontario

Canada L1W 3K1

Phone: [phone]

[phone]

Fax: [phone]

www.psbspeakers.com

A Member of the Lenbrook Group of Companies

LIMITED WARRANTY

PSB Speakers, a division of Lenbrook Industries Limited, warrants the following products for the periods indicated:

Products

Loudspeakers and Powered Subwoofers

How Long Does the Warranty Last?

All PSB loudspeakers and subwoofer drivers have a 5-year warranty. PSB amplifiers, including the amplifiers used in our "powered speakers" (such as powered subwoofers) have a 1 year warranty.

What is Covered and What is Not Covered?

Except as specified below, this warranty covers parts and labor to correct all defects in materials and workmanship.

The following are not covered by the warranty:

1. Damage, deterioration, malfunction or failure to meet performance specifications resulting from:

a) Accident, acts of nature, misuse, abuse, neglect or unauthorized product modification.

b) Improper installation, removal or maintenance, or failure to follow instructions supplied with the product.

c) Repair or attempted repair by anyone not authorized by PSB Speakers to repair the product.

d) Any shipment of the product (claims must be presented to the carrier).

e) Any cause other than a product defect.

2) Cleaning, initial set-up, check-ups with no defects found, or charges incurred for installation, removal or reinstallation of the product.

3) Any product on which the serial number has been defaced, modified, or removed.

4) Accessories, including but not limited to, cables, mounting hardware and brackets, and detachable power cords.

5) Any product used in any trade or business or in an industrial or commercial application.

6) Any product purchased outside the country of service, its possessions or territories.

7) Any problem other than a product defect.

8) Any product not purchased from an authorized PSB Speakers Dealer. If you're not sure a dealer is "authorized", check our dealer locator or call PSB Speakers.

Who May Enforce the Warranty?

This warranty may be enforced only by the original purchaser.

What We Will Pay For

We will pay for all labor and material expenses for items covered by the warranty. Payment of shipping charges is discussed in the next section of this warranty.

How You Can Get Service

1) If your unit needs service, please take your speaker with the original invoice or bill of sale to your PSB Speakers dealer. If you need assistance locating a PSB dealer please look on PSB's internet website or contact PSB directly.

2) You must pay any shipping charges if it is necessary to ship the product for service. However, if the necessary repairs are covered by the warranty, we will pay the return shipping charges to any destination within the country of service.

3) Wherever warranty service is required, you must present the original dated sales receipt, invoice, or other proof of purchase.

Limitation of Implied Warranties

All implied warranties, including warranties of merchantability and fitness for a particular purpose, are limited in duration to the length of this warranty.

Exclusion of Damages

PSB Speakers' liability for any defective product is limited to repair or replacement of the product at PSB's option. PSB shall not be liable for damage to other products caused by any defects in PSB's products, damages based upon inconvenience or loss of use of the product, or any other damages, whether incidental, consequential, or otherwise.

How State (Provincial) Law Relates to the Warranty

Some states do not allow limitations on how long in implied warranty lasts and/or do not allow the exclusion or limitation of incidental or consequential damages, so the above limitations or exclusions may not apply to you.

This warranty give you specific legal rights, and you may also have other rights, which vary, from State (Province) to State (Province).

This warranty is enforceable only inside the county of purchase, its possessions or territories.
