Product Type	Freestanding Washing Machine
Brand	Iberna
Model	LB ITL 413 T
Capacity	6 kg
Spin Speed	1200 rpm
Energy Efficiency Class	A++ (est.)
Dimensions (H x W x D)	85 x 59.5 x 52 cm (approx.)
Weight	62 kg (approx.)
Power Supply	220-240 V / 50 Hz
Water Consumption per Cycle	45 L (est.)
Noise Level (Spin)	78 dB(A) (est.)
Number of Programs	15 (including Eco, Cotton, Synthetics, Delicates, Wool, Quick 30'')
Key Functions	Delay Start, Child Lock, Half Load Detection, Variable Spin Speed
Display Type	LED
Door Opening	Left hinged, 180° opening
Drum Material	Stainless Steel
Installation Type	Freestanding, requires water inlet and drain hose
Maintenance & Cleaning	Clean filter regularly, descale every 3 months, wipe door seal
Safety Features	Child lock, overflow protection, imbalance detection
Spare Parts Availability	Common parts available online (belts, filters, pumps, etc.)
Repair Index (France)	7.5/10 (est.)
General Information	Freestanding washing machine from Iberna, suitable for household use.

Frequently Asked Questions - LB ITL 413 T IBERNA

What is the capacity of the Iberna LB ITL 413 T washing machine?

The Iberna LB ITL 413 T has a capacity of approximately 6 kg, ideal for small to medium households.

How do I clean the filter on this washing machine?

To clean the filter, locate it at the bottom right corner. Open the flap, unscrew the filter, remove lint, and rinse it under running water. Ensure the machine is empty of water before cleaning.

What does the 'Child Lock' do?

The Child Lock prevents accidental button presses during a cycle. To activate, press and hold the 'Child Lock' button for 3 seconds. A padlock icon will appear.

Why is my washing machine not spinning?

Possible causes include an unbalanced load, a clogged filter, or a blocked drain hose. Check the load distribution, clean the filter, and ensure the drain hose is not kinked.

What programs are available on the LB ITL 413 T?

This model offers 15 programs including Cotton, Synthetics, Delicates, Wool, Quick 30', Eco, and more. Refer to the program chart in the manual.

How do I start a delayed wash?

Press the Delay Start button repeatedly to set the desired delay (e.g., 3, 6, 9 hours). Then press Start/Pause. The machine will begin after the set delay.

What should I do if the machine displays an error code?

Common error codes: E01 (door lock issue), E02 (water drainage problem), E03 (water inlet issue). Check the door seal, clean filter, or ensure water supply is open. If persists, contact support.

How do I descale the washing machine?

Use a descaling agent designed for washing machines. Run an empty hot cycle (90°C) with the descaler. Repeat every 3 months to prevent limescale buildup.

What are the dimensions of the Iberna LB ITL 413 T?

Approximate dimensions are 85 cm (height) x 59.5 cm (width) x 52 cm (depth). Always measure your installation space before purchasing.

Where can I find spare parts for this model?

Spare parts such as belts, filters, pumps, and control boards are available from online retailers or authorized Iberna service centers. Check the model number when ordering.

USER MANUAL LB ITL 413 T IBERNA

Read this manual carefully as it offers practical advice to help you get the most from your washing machine.

This Instruction Manual contains everything you need to know about the everyday running of your machine. Keep it for future reference.

An Installation and Maintenance Manual is also provided which you should consult during the installation and routine maintenance of your washing machine. The manual also contains information about possible working problems, advice about the wash load, an explanation of label symbols and hints about how to remove stubborn stains.

When contacting a IBERNA or one of its Technical Assistance Centre always refer to the model (see control panel) and the registration and series numbers which are indicated at the bottom of the machine under the lower panel or on the warranty certificate. That is to say, everything that appears in the box.

Providing this information will ensure a faster and more efficient service.

INDEX

page

GUARANTEE 29

TECHNICAL DATA 30

OPENING THE LID - LOADING 31

DETERGENT DISPENSER 32

VARIABLE CAPACITY 33

PROGRAMME SELECTION 33

CONTROL DESCRIPTION 34

TABLE OF PROGRAMMES 36

GUARANTEE

1.

The appliance comes with a guarantee certificate.

2.

Complete part A and keep it in a safe place. It should be presented to the Technical Assistance Centre in the event of a repair being necessary along with the legal receipt issued by the dealer on purchase.

3.

Do not forget to send part B of the Guarantee Certificate to be validated within 15 days of purchase.

TECHNICAL DATA

Load capacity ....kg.

Voltage V.

Wash motor power rating ....W.

Spin motor power rating ....W.

Electropump power rating W.

Heating element power rating ....W.

Max. power input W.

Fuse A.

Water pressure .... MPa

Energy consumption (60° C programme) kWh

Energy efficiency rating ....

ITL 413T

5

230

360

560

30

1.850

2.300

10

0,05 min.

0,8 max.

400

75

1,35

C

OPENING THE DRUM

1.

Lift the lid (A) and open completely. Next open the drum door following these instructions:

2.

Press catch (B) and kept it pressed down.

Press the first shutter (C) to unlock the two shutters (C) and (D).

3.

Open the second shutter (D). Open the first shutter (C). Place the washing in the drum.

4.

Close the first shutter (C).

Close the second shutter (D) so that the catch on the first shutter fits correctly into the slot. Release.

5.

Ensure that both shutters are perfectly aligned and properly closed.

IMPORTANT: IT IS IMPORTANT TO MAKE SURE THAT THE DRUM IS CAREFULLY CLOSED BEFORE OPERATING THE MACHINE, OTHERWISE THE MACHINE OR LAUNDRY COULD GET DAMAGED.

2 min.

IMPORTANT: A SPECIAL SAFETY DEVICE PREVENTS THE LID FROM BEING OPENED IMMEDIATELY AFTER THE WASH HAS FINISHED. ONCE THE SPIN CYCLE HAS FINISHED, WAIT FOR 2 MINUTES BEFORE TRYING TO OPEN THE LID.

DETERGENT DISPENSER

The detergent dispenser is divided into 4 compartments:

- Compartment I, is for prewash liquid or powder detergent. The recommended quantity is 60 gm of detergent (for 5 kg of laundry).

- Compartment II, is for wash powder detergent. The recommended quantity is 120 gm of detergent (for 5 kg of laundry).

CAUTION: REMEMBER THAT SOME DETERGENTS DO NOT GET TAKEN AWAY EASILY BY THE WATER. IN THIS CASE, IT IS BEST TO PUT A «WASH BALL» STRAIGHT IN THE DRUM.

• The △ compartment is for bleach. The recommended quantity is 70 c.c.

• The ✅ compartment is for fabric conditioners, scenting agents and special additives. The recommended quantity is 50 c.c.

VARIABLE CAPACITY

This washing machine automatically adapts the water level to the type and quantity of clothes to be washed. So it is possible to obtain a «customised» wash, even in terms of energy. This system reduces water and energy consumption and provides an appreciable reduction in wash time.

PROGRAMME SELECTION

WHEN SELECTING A PROGRAMME, ENSURE THAT THE START/STOP BUTTON IS NOT ACTIVATED.

To select a programme:

• Programmes are selected by means of the corresponding control knob (A). See the table of programmes.
• Select the wash temperature by means of the corresponding control knob.
• Select the different options available by pressing the corresponding buttons.

CONTROL DESCRIPTION

MOD. ITL 413 T

Programme selector knob A

Temperature selector knob ...... B

Spin exclusion button D

1/2 load button E

ON/OFF pilot light G

ON/OFF button H

USE OF THE SELECTION CONTROLS

MOD. ITL 413 T

A
PROGRAMME SELECTOR KNOB

This control allows you to select the washing programmes.

ALWAYS ROTATE the control in a clockwise direction, never in an anticlockwise direction. Do not press the "on" button (H) before selecting the programme.

If you wish to modify the position of the control or select another programme once a cycle has commenced, press the ON/OFF button. Press again to recommence once the modification has been completed.

B
TEMPERATURE SELECTOR KNOB

This control allows you to select the temperature of your wash. If you wish to carry out a cold wash, turn the knob until the cold symbol 📍 coincides with the selector mark.

THE KNOB CAN BE TURNED IN BOTH DIRECTIONS.

Do not exceed the maximum temperature recommended for each cycle in the table of programmes.

D
SPIN EXCLUSION BUTTON

This button excludes the spin cycle from the wash programme. This option is recommended for special fabrics.

E
1/2 LOAD BUTTON

The water load for a small wash may be reduced by pressing the 12 load button. This saves water, detergent and electricity. The amount of detergent used should be reduced in proportion to the load.

IMPORTANT: NEVER PRESS THE HALF LOAD BUTTON WHEN WASHING PURE NEW WOOL AND VERY DELICATE FABRICS.

G
ON/OFF PILOT LIGHT

H
ON/OFF BUTTON

TABLE OF PROGRAMMES

MOD. ITL 413 T

NON-DELICATES

TYPE OF FABRIC	PROGRAMME	MAX. LOAD IN KG	SEL. PROG.	SEL. TEMP. C°	DETERGENT
					I	II	△
Cotton, linen	VERY DIRTYSheets, solid-block coloured and white tablecloths, napkins, underwear	5	1	From out to .90°	●	●	●	●
	NORMAL DIRTYSheets, solid-block coloured and white tablecloths, napkins, underwear	5	2*	From out to .90°		●	●	●
Cotton, mixed and non delicates	Cotton resistant	3,5	3	From out to .60°		●		●
Cotton, mixed	Lightly soiled - Delicates colours	3,5	4	From out to .40°		●		●
	BleachingOrganic slams	—	△	—			●	●
Cotton	Energetic rinseConditioner, fragrance, softener	—	△	—				●
Cotton, linen	Energetic spin	—	◎	—

MIXED SYNTHETICS

Mixed non- delicates	VERY DIRTY Shirts, shoots, baby clothes, whites	2	5	From odd to...602	●	●		●
Synthetics (Hayon, Acrylics)	NORMAL DIRTY Non-delicate shirts, slouses, coloured skirts	2	6 *	From odd to...602		●		●
Delicate synthetics	Delicate Colours	2	7	From odd to...502		●		●
	LIGHTLY SOILED	2	8	From odd to...402		●		●
Mixed, synthetics, delicates		—		—				●
	Delicate rinse Conditioner, fragrance, softener
	Delicate spin	—		—				●
Clothes which do need to be spun	WATER DISCHARGE		Z	—

EXTREM. DELIC. FABRICS

Synthetics (Rayon, Acrylics)	Curtains, skirts, blouses, shirts	1	9	Tram cold in..40#	●	●		●
Woolians	WOOL "machine washable"	1,5	10★	Tram cold in..40#		●		●
Mixed, synthetics, woolen delicates	Delicate rinse Conditioner, fragrance, softener	—		—				●
	Delicate spin	—		—

Programme *, according to EN 60456 Regulations.

The first program in each group is the longest and thus ensures the most effective wash at a given temperature. The other programs should be selected for clothes which are only lightly soiled or are particularly delicate.

NOTE:

1. If the wash load is very dirty it is best to reduce the load weight to 3 kg.
2. In programmes 5-6-7-8-9-10, the washing machine stops with water in the drum at the end of the rinse cycle to prevent creasing.
   The cycle may be ended in two ways: - Move the programme selector forward one step. - Select programme Z (water discharge). In this case, disconnect the ON/OFF button before making the selection on the control.
3. Programmes 1 and 2 have an automatic bleaching option. Simply place the bleaching agent in the △ compartment.
4. The washing machine is designed to incorporate fabric softener automatically in the last rinse of each washing cycle.
5. Programmes 1-5-9 are with prewash.
