Product Type	Upright Freezer
Brand	Hoover
Model	HUNA 2714-0
Total Capacity	Approx. 271 liters
Freezing Capacity	Up to 4 kg per 24 hours (estimated)
Dimensions (H x W x D)	Approx. 1850 x 595 x 650 mm
Weight	Approx. 60 kg
Power Supply	220-240 V, 50 Hz
Energy Class	E (estimated)
Climate Class	N-ST (estimated)
Noise Level	Approx. 40 dB (estimated)
Super Freeze Function	Yes, via thermostat knob to SUPER position; yellow/orange indicator light
Shock Freezing Function	Yes, for up to 3 kg; green indicator visible when activated
Number of Drawers	Multiple drawers (removable for bulk freezing)
Control Panel	Top door access; thermostat control with indicator lights
Door Reversibility	Yes, fully reversible with included hinge kit
Handle Type	Reversible handles with decorative plugs
Defrost Method	Manual (not specified in manual)
Refrigerant	R600a (typical for Hoover freezers)
Installation Requirements	Level surface, allow ventilation, wait 2 hours after tilt before powering on

Frequently Asked Questions - HUNA 2714-0 HOOVER

How do I activate the super freeze function?

Turn the thermostat knob clockwise to the SUPER position. The yellow/orange light will come on. After 24 hours, place fresh food directly on the metal rack. Freezing takes 24 hours, then reset the thermostat to position 2/3.

What is the shock freezing function and how do I use it?

Shock freezing quickly freezes up to 3 kg of food in less than 4 hours. Turn the handle between the first and second compartments until the green indicator is visible.

Can I reverse the door opening direction?

Yes, the freezer has a reversible door. Follow the step-by-step instructions in the manual: tilt the appliance, remove hinges, swap the door and handle, and use the included accessory kit. Wait 2 hours before turning it on.

How do I remove the drawers for bulk freezing?

Remove all drawers except the bottom one to test freezing and conservation functions. When the freezer is full, it is advised to remove the drawers and place food directly on the shelves for optimal congelation.

What should I do if the freezer is not cooling enough?

Check that the thermostat is set correctly (position 2/3 for normal use). Ensure the door is fully closed and the condenser is clean. If the problem persists, contact service.

How do I clean the freezer?

Unplug the appliance, remove all food, and wipe the interior with a mixture of warm water and mild detergent. Rinse and dry thoroughly. Do not use abrasive cleaners.

What does the yellow/orange light mean?

The yellow/orange light indicates that the super freeze function is active. It stays on as long as the thermostat is set to the SUPER position.

How long should I wait before turning on the freezer after moving it?

After tipping the appliance (e.g., for door reversal), return it to an upright position and wait two hours before plugging it in.

What accessories are included for door reversal?

The freezer comes with an accessories kit that includes an upper left hinge, screws, plugs, and decorative covers for the handles.

How can I maximize freezing efficiency?

For optimal congelation, remove drawers and place food directly on the metal shelves. Use the super freeze function 24 hours before adding large quantities of fresh food.

USER MANUAL HUNA 2714-0 HOOVER

Simple line drawing of a refrigerator with two doors and wheels (no text or symbols)

Simple line drawing of a refrigerator with two doors and wheels (no text or symbols)

Simple line drawing of a refrigerator with no text or symbols

CONGELATORI VERTICALI LOGIC	IT
LOGIC UPRIGHT FREEZERS	GB
CONGÉLATEURS VERTICAUX LOGIC	FR
GEFRIERSCHRÄNKE LOGIC	DE
CONGELADORES VERTICALES LOGIC	ES
CONGELADORES VERTICAIS LOGIC	PT
OPÓIOI KATAΨYKTEΣ LOGIC	EL
ZAMRAŽARKI PIONOWE LOGIC	PL
SKRÍNOVÉ MRAZÁKY LOGIC	CZ
LOGIC VRIESKASTEN	NL
LOGIC KAAPPIPAKASTIMET	FI
LOGIC VERTIKALE FRYSESKAP	NO
VERTIKALA FRYSAR LOGIC	SV
VERTIKALE LOGIC FRYSERE	DA

CONGELATORI VERTICALI LOGIC

QUADRO COMANDI

Pure mechanical diagram showing a lever and shaft assembly without any text, numbers, or symbols

Line drawing of a hand holding a document with an arrow pointing to a vertical panel (no text or symbols)

Simple line drawing of a mechanical assembly with two springs attached to a base (no text or symbols)

Technical line drawing of a tool and bracket assembly (no text or symbols)

Simple line drawing of a mechanical clamp or bracket with two springs attached to a base, no text or symbols present.

Simple line drawing of a boat with a handle and small boat, no text or symbols present

Pure technical line drawing of a mechanical component without any text, numbers, or symbols

Simple line drawing of a door with arrows indicating direction (no text or symbols)

Pure mechanical component diagram without any text, numbers, or symbols

Open the top door of the freezer to access the control panel.

FREEZING

NB. This is the label indicating the maximum quantities of food you can freeze and the information to give our Service Department in the event of a fault.

The preservation of frozen foods is guaranteed in all of the freezer's compartments.

When the freezer is full, it is advised to remove the drawers and place the food directly on the shelves for optimal congelation.

Turn the thermostat clockwise to SUPER and the yellow/orange light will come on (see fig. 1). After 24 hours, put foods directly on the metal rack. Freezing takes 24 hours and you can then put the compartments back and arrange the foods in the freezer. Reset the thermostat to position 2/3.

To test out the freezing and conservation functions remove all the drawers apart from the bottom one.

Some models are equipped with a "Shock Freezing" function which freezes items quickly in less than 4 hours and guarantees better-tasting food (max. 3kg). To use, turn the handle between the first and second compartments until the green indicator is visible.

INVERTING THE DOOR

Tip the refrigerator over onto the floor or to a 45° angle to make working on the bottom section easier.

1

Remove the lower right-hand hinge by unscrewing it and then remove the door.

Pure mechanical diagram showing a lever and shaft assembly without any text, numbers, or symbols

Simple line drawing of a hand holding a document with an arrow pointing to a vertical panel (no text or symbols)

Remove plugs (A) and (B), loosen the screws and partially remove the panel.

Unscrew the hinge on the right.

4

Simple line drawing of a mechanical clamp or bracket with two screws attached (no text or symbols)

Cut and break the slot on the left side of the panel, as shown in the diagram.

Technical line drawing of a mechanical tool and bracket assembly (no text or symbols)

Fit the upper left hinge (found in the accessories kit).

6

Simple line drawing of a mechanical clamp or bracket with two springs attached (no text or symbols)

Reinstall the panel, securing it with the screws and plugs.

Simple line drawing of a boat hull with a handle and small boat, no text or symbols present

Replace the door and fix the lower hinge.

Pure technical line drawing of a mechanical assembly without any text, numbers, or symbols

To reverse the handles: remove the decorative plugs located on the right-hand side of the door.

9

Simple line drawing of a door with arrows indicating direction (no text or symbols)

Unscrew the handles from the left side and move them to the right side. Then position the decorative plugs into the holes on the left side of the door.

10

Pure mechanical part diagram without any text, numbers, or symbols

Return the appliance to the upright position and wait two hours before turning it on.

11

CONGÉLATEURS VERTICAUX LOGIC

PANNEAU DE COMMANDE

Pure technical line drawing of a mechanical component without any text, numbers, or symbols

Simple line drawing of a hand holding a document with an arrow pointing to a vertical line (no text or symbols)

Simple line drawing of a mechanical clamp or bracket with two screws attached (no text or symbols)

Technical line drawing of a mechanical tool and bracket assembly (no text or symbols)

Simple line drawing of a mechanical clamp or bracket with two screws attached (no text or symbols)

Simple line drawing of a boat hull with a handle and side supports, no text or symbols present

Pure mechanical diagram showing a lever and shaft assembly without any text, numbers, or symbols

Simple line drawing of a rectangular structure with two arrows pointing outward from a vertical seam (no text or symbols)

Pure mechanical diagram showing a circular component with directional arrows, no text or symbols present

Pure mechanical part diagram without any text, numbers, or symbols

Simple line drawing of a mechanical assembly with two springs attached to a base (no text or symbols)

Simple line drawing of a boat hull with a handle and dock, no text or symbols present

Pure technical line drawing of a mechanical component without any text, numbers, or symbols

Line drawing of a hand holding a document with a ruler, next to a wall (no text or symbols)

Line drawing of a tool and ruler on a metal base (no text or symbols)

Pure technical line drawing of a mechanical component without any text, numbers, or symbols

Simple line drawing of a mechanical clamp or bracket with two springs attached (no text or symbols)

Simple line drawing of a rectangular frame with two arrows pointing outward from the side (no text or symbols)

CONGELADORES VERTICALES LOGIC

PANEL DE CONTROL

Pure mechanical diagram showing a lever and shaft assembly without any text, numbers, or symbols

Line drawing of a hand holding a document with an arrow pointing to a vertical line (no text or symbols)

Simple line drawing of a mechanical assembly with two screws and a handle (no text or symbols)

Technical line drawing of a mechanical tool and bracket assembly (no text or symbols)

Simple line drawing of a mechanical clamp or bracket with two screws attached (no text or symbols)

Simple line drawing of a boat hull with a handle and small boat, no text or symbols present

Pure mechanical diagram showing a lever and pivot mechanism without any text or symbols

Simple line drawing of a rectangular object with wavy edges and two arrows pointing outward (no text or symbols)

Pure technical line drawing of a mechanical component without any text, numbers, or symbols

Line drawing of a hand holding a document with a right-angle arrow pointing to a vertical panel (no text or symbols)

Retire as tampas (A) e (B), desaparafuse os parafusos e retire parcialmente o painel de comandos.

3

Simple line drawing of a mechanical assembly with two screws and a handle (no text or symbols)

Corte e parta a fenda à esquerda do painel na zona moldada.

Technical line drawing of a mechanical tool and bracket assembly (no text or symbols)

Simple line drawing of a mechanical clamp or bracket with two screws attached (no text or symbols)

Simple line drawing of a boat on water with a small rod inserted, no text or symbols present

Pure technical line drawing of a mechanical component without any text, numbers, or symbols

Simple line drawing of a door with arrows indicating direction (no text or symbols)

Simple line drawing of a hand holding a document with an arrow pointing to a vertical panel (no text or symbols)

Simple line drawing of a mechanical assembly with two screws and a handle (no text or symbols)

Technical line drawing of a mechanical tool and bracket assembly (no text or symbols)

Simple line drawing of a mechanical clamp or bracket with two screws attached (no text or symbols)

Simple line drawing of a boat hull with a small rod inserted, no text or symbols present

Pure technical line drawing of a mechanical component without any text, numbers, or symbols

Simple line drawing of a rectangular object with two arrows pointing outward from its side (no text or symbols)

Pure mechanical diagram showing a lever and shaft assembly without any text, numbers, or symbols

Line drawing of a hand holding a document with an arrow pointing to a vertical panel (no text or symbols)

Simple line drawing of a mechanical clamp or bracket with two screws attached (no text or symbols)

Technical line drawing of a mechanical component with a tool and bracket (no text or symbols)

Simple line drawing of a mechanical clamp or bracket with two springs attached to a surface (no text or symbols)

Simple line drawing of a boat hull with a handle and dock, no text or symbols present

Pure technical line drawing of a mechanical component without any text, numbers, or symbols

Simple line drawing of a door with arrows indicating direction (no text or symbols)

Pure mechanical component diagram without any text, numbers, or symbols

Pure mechanical diagram showing a lever and pipe without any text, numbers, or symbols

Simple line drawing of a hand holding a document with an arrow pointing to a vertical panel (no text or symbols)

Simple line drawing of a mechanical assembly with two screws and a handle (no text or symbols)

Technical line drawing of a mechanical tool and bracket assembly (no text or symbols)

Simple line drawing of a mechanical clamp or bracket with two screws attached (no text or symbols)

Simple line drawing of a boat hull with a small rod inserted, no text or symbols present

Pure technical line drawing of a mechanical component without any text, numbers, or symbols

Simple line drawing of a door with arrows indicating direction (no text or symbols)

Pure mechanical component diagram without any text, numbers, or symbols

Pure technical line drawing of a mechanical component without any text, numbers, or symbols

Line drawing of a hand holding a document with an arrow pointing to a wall (no text or symbols)

Simple line drawing of a mechanical clamp or bracket with two screws attached (no text or symbols)

Line drawing of a tool and ruler assembly (no text or symbols)

Simple line drawing of a mechanical clamp or bracket with two screws attached (no text or symbols)

Simple line drawing of a boat hull with a handle and dock, no text or symbols present

Monteer de deur weer en zet het onderste scharnier vast.

Pure technical line drawing of a mechanical component without any text, numbers, or symbols

Simple line drawing of a rectangular structure with two arrows pointing outward from a vertical wall (no text or symbols)

Pure mechanical part diagram without any text, numbers, or symbols

Pure technical line drawing of a mechanical component without any text, numbers, or symbols

Simple line drawing of a hand holding a document with an arrow pointing to a vertical panel (no text or symbols)

Simple line drawing of a mechanical clamp or bracket with two screws attached (no text or symbols)

Line drawing of a tool and ruler on a metal bracket (no text or symbols)

Simple line drawing of a mechanical clamp or bracket with two screws attached (no text or symbols)

Simple line drawing of a boat hull with a handle and dock, no text or symbols present

Pure technical line drawing of a mechanical assembly without any text, numbers, or symbols

Simple line drawing of a rectangular frame with two vertical arrows pointing outward (no text or symbols)

Pure mechanical part diagram without any text, numbers, or symbols

Pure mechanical diagram showing a lever and shaft assembly without any text, numbers, or symbols

Line drawing of a hand holding a document with a bracket and arrow indicating a step (no text or symbols)

Simple line drawing of a mechanical assembly with two screws and a handle (no text or symbols)

Bryt opp det venstre hullet i dekselet der du ser avtrykket.

Line drawing of a tool cutting into a rectangular object (no text or symbols)

Simple line drawing of a mechanical clamp or bracket with two screws attached (no text or symbols)

Simple line drawing of a boat hull with a handle and small boat, no text or symbols present

Pure technical line drawing of a mechanical component without any text, numbers, or symbols

Simple line drawing of a door with arrows indicating direction (no text or symbols)

Technical line drawing of a mechanical component with directional arrows indicating movement (no text or symbols)

Pure mechanical part diagram without any text, numbers, or symbols

VERTIKALA FRYSAR LOGIC

KOMMANDOPANEL

Pure technical line drawing of a mechanical component without any text, numbers, or symbols

Line drawing of a hand holding a document with an arrow pointing to a vertical line (no text or symbols)

Simple line drawing of a mechanical assembly with two springs attached to a base (no text or symbols)

Line drawing of a tool and ruler on a metal bracket (no text or symbols)

Simple line drawing of a mechanical clamp or bracket with two springs attached (no text or symbols)

Simple line drawing of a boat with a handle and small boat, no text or symbols present

Pure technical line drawing of a mechanical component without any text, numbers, or symbols

Simple line drawing of a rectangular object with two arrows pointing outward from its side (no text or symbols)

Pure technical line drawing of a mechanical component without any text, numbers, or symbols

Line drawing of a hand holding a document with an arrow pointing to a vertical line (no text or symbols)

Fjern propperne (A) og (B), skru skruerne af og tag panelet delvist af.

3

Simple line drawing of a mechanical assembly with two screws and a handle (no text or symbols)

Line drawing of a tool and bracket assembly (no text or symbols)

Simple line drawing of a mechanical clamp or bracket with two screws attached (no text or symbols)

Simple line drawing of a boat with a handle and small boat, no text or symbols present

Pure technical line drawing of a mechanical component without any text, numbers, or symbols

Simple line drawing of a door with arrows indicating direction (no text or symbols)

Pure mechanical diagram showing a curved component with two circular features and directional arrows, no text or symbols present.
