Product Type	Portable Radio (TV/Weather/FM/AM PLL Synthesized)
Brand	Sony
Model	SRF-M37V
Frequency Bands	TV (ch 2-13), Weather (ch 1-7), FM (87.5-108 MHz), AM (530-1213 kHz)
Tuning Type	Digital PLL synthesizer with 25 memory presets
Channel Steps	FM: 0.1 MHz, AM: 10 kHz (switchable to 9 kHz)
Presets	25 (5 each for FM1, FM2, AM, TV, Weather)
Power Output	2.8 mW + 2.8 mW (at 10% harmonic distortion)
Headphone Jack	3.5 mm stereo minijack, load impedance 21 Ω
Power Source	1.5 V DC, one size AAA (R03) battery
Battery Life (Alkaline)	FM/AM: approx. 54 h, TV/Weather: approx. 31 h
Clock Display	12-hour system
Dimensions (with projecting parts)	Approx. 85 x 63 x 32 mm (w/h/d)
Dimensions (without projecting parts)	Approx. 85 x 60 x 25 mm (w/h/d)
Weight	Approx. 94 g (incl. battery and belt clip)
Accessories Included	Stereo headphones, belt clip
Warranty	1 year limited
Safety	Do not use headphones while driving; avoid high volume to prevent hearing damage; remove battery if not used for long time
Maintenance	Clean casing with soft cloth dampened with mild detergent solution
Regulatory Compliance	FCC Part 15

Frequently Asked Questions - SRF-M37V SONY

How do I set the clock on my Sony SRF-M37V?

Hold down CLOCK for more than 2 seconds. Then use TUNE/TIME SET + or - to set the hour. Press CLOCK again, then set the minute using the same buttons. Finally press CLOCK to confirm.

How do I preset radio stations?

Tune to the desired station manually. Then hold down one of the preset tuning buttons (1-5) for a few seconds until you hear confirmation beeps. The station is saved under that button for the current band.

How do I change the AM channel step?

Turn off the radio. While holding down CLOCK, press POWER for more than 5 seconds. You will hear two short beeps and the step changes. Repeat to toggle between 10 kHz and 9 kHz.

Why is '0-n' displayed and the buttons don't work?

The HOLD function is activated. Slide the HOLD switch in the opposite direction of the arrow to unlock all buttons. The '0-n' indicator will disappear.

How can I improve FM reception?

Extend the headphones cord fully; it functions as the FM antenna. Also, try moving near a window or away from metal objects. If interference is strong, set the DX/LOCAL switch to LOCAL.

What should I do if the sound is weak or interrupted?

First, check the battery level. If weak, replace the battery. Also, if you are in a vehicle or building, move closer to a window for better reception.

How do I replace the battery?

Open the battery compartment lid and install one AAA (R03) battery with correct polarity. Replace the lid. Note: if you take more than 5 minutes, clock and presets will reset.

Can I use rechargeable batteries?

The manual recommends using a dry battery. Rechargeable batteries (Ni-MH) can be used but may have shorter life and should not be charged in the radio. Do not attempt to charge a dry battery.

How do I attach the belt clip?

Align the belt clip with the slot on the back of the radio and push downward until it clicks into place. To detach, push the tab and slide upward.

What does the HOLD switch do?

Sliding the HOLD switch locks all buttons to prevent accidental operation. '0-n' appears in the display. Slide it back to unlock.

USER MANUAL SRF-M37V SONY

TV/WEATHER/FM Stereo/AM PLL Synthesized Radio

Operating Instructions

WALKIVAN

“WALKMAN” is a registered trademark of Sony Corporation to represent Headphone Stereo products. WALKMAN is a registered trademark of Sony Corporation.

TV/WEATHER/FM/AM WALKMAN

SRF-M37V

Sony Corporation ©2003 Printed in China

||

http://www.sony.net/

For customers in the USA Please register this product on line at http://www.sony.com/productregistration. Proper registration will enable us to send you periodic mailings about new products, services, and other important announcements. Registering your product will also allow us to contact you in the unlikely event that the product needs adjustment or modification. Thank you.

WARNING

You are cautioned that any changes or modifications not expressly approved in this manual could void your authority to operate this equipment.

This device complies with Part 15 of the FCC Rules. Operation is subject to the condition that this device does not cause harmful interference.

Trade Name: SONY

Model name: SRF-M37V

Tested To Comply

With FCC Standards

FOR HOME OR OFFICE USE

If you have any questions about this product, you may call: Sony Direct Response Center 1-(800)-222-7669 or write to: Sony Direct Response Center 12451 Gateway Blvd. Fort Myers, FL 33913

Declaration of Conformity

Trade Name: SONY

Model: SRF-M37V

Responsible Party: Sony Electronics Inc.

Address: 680 Kinderkamack Road, Oradell, NJ 07649

USA

Telephone Number: 201-930-6972

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Before You Begin

Thank you for choosing the Sony radio!

It will give you many hours of reliable service and listening pleasure. Before operating the radio, please read these instructions thoroughly and retain them for future reference.

Features

• TV/WEATHER/FM/AM 4 band PLL (phase locked loop) synthesized radio.

- Easy Preset Digital Tuning with 25 memory presets.

- 5 direct presets calls and 1 direct weather-band button.

- Ergonomic Design for belt-holder use.

Notes on AM Channel Step

The AM channel step differs depending on areas. See "Changing AM Channel Step".

Precautions

• Operate the unit only on 1.5 V DC with one size AAA (R03) battery.
• Avoid exposure to temperature extremes, direct sunlight, moisture, sand, dust or mechanical shock. Never leave the unit in a car parked under the sun.
• Should any solid object or liquid fall into the unit, remove the battery and have the unit checked by qualified personnel before operating it any further.
• In vehicles or buildings, radio reception may be difficult or noisy. Try listening near a window.
• To clean the casing, use a soft cloth dampened with a mild detergent solution.

Notes on Headphones

Road safety

Do not use headphones while driving, cycling, or operating any motorized vehicle. It may create a traffic hazard and is illegal in many areas. It can also be potentially dangerous to play your headphones at high volume while walking, especially at pedestrian crossings. You should exercise extreme caution or discontinue use in potentially hazardous situations.

Preventing hearing damage

Avoid using headphones at high volume. Hearing experts advise against continuous, loud and extended play. If you experience a ringing in your ears, reduce volume or discontinue use.

Caring for others

Keep the volume at a moderate level. This will allow you to hear outside sounds and to be considerate to people around you.

Warning

If there is lightning when you are using the unit, take off the headphones immediately.

If you have any questions or problems concerning your unit, please consult your nearest Sony dealer.

Troubleshooting

Should any problem persist after you have made the following checks, consult your nearest Sony dealer.

All buttons do not operate at all

- “○—” is displayed. Slide the HOLD switch so that “○—” disappears.

Very weak or interrupted sound, or unsatisfactory reception

- Weak battery.

• In a vehicle or in a building, move closer to a window

Display is dim, or no indication is displayed.

- Weak battery

- The unit is being used in extremely high or low temperatures or in a place with excessive moisture.

The station cannot be received when a PRESET TUNING (1 to 5)

button is pressed.

- You chose the wrong preset number.

- The memory of the station has been initialized. Preset the station again.

The power cannot be turned on, and "☐" is flashing in the

display.

• The battery have been completely exhausted.

The preset stations may be initialized, if a maintenance service is

performed.

Please note down your settings in case you want to preset them again.

Specifications

Time display

12-hour system

Frequency range

Band Range Channel step

TV 2 - 13 ch 1 channel
WEATHER 1 - 7 ch	1 channel
FM	87.5 – 108 MHz	0.1 MHz
AM	530 – 1710 kHz	10 kHz

Output

(headphones) jack ( 3.5 mm, stereo minijack) load impedance 24 Power output

2.8 mW + 2.8 mW (at 10 % harmonic distortion)

Power requirements

1.5 V DC, one size AAA (R03) battery

Dimensions

Approx. 83 · 63 · 32 mm (w/h/d) (3^3/8 · 2^1/2 · 1^5/_16 inches) incl. projecting parts and controls Approx. 83 · 63 · 25 mm (w/h/d)

(3^3 / 8· 2^1 / 2· 1 inches) not incl. projecting parts and controls

Mass

Approx. 94 g (3.32 oz.) incl. battery and belt clip.

Accessories Supplied

Stereo headphones (1)

Belt Clip (1)

Design and specifications are subject to change without notice.

Installing the Battery

(See Fig. A-⑧)

1 Open the battery compartment lid and install one size AAA (R03) battery (not supplied) with correct polarity. When battery is first installed, "AM 12:00" flashes in the display. Once the current time is set, the flashing stops.

2 Close the lid.

Battery Life (Approx. hours)				(JEITA*)
When using	TV	WEATHER	FM	AM
Sony alkaline size AAA (LR 03)	31	31	34	54
Sony size AAA (R03)	12	12	13	24

* Measured by JEITA (Japan Electronics and Information Technology Industries Association) standards. The actual battery life may vary depending on the circumstance of the unit.

When to replace the battery

You can check the remaining battery power that appears in the display. The indicators are as follows:

Indicator

Full strength*

Weakening*

When the battery becomes exhausted, the unit will turn off. Replace with new battery. When you press POWER after installing the new battery, the indicator changes to "☐".

* Displayed only when the radio is turned on.

Note

Do not take more than 3 minutes to replace the battery, otherwise, your clock settings and preset stations will be initialized. Should that happen, reset the functions again.

Notes on battery

- Do not charge the dry battery. - Do not carry the dry battery together with coins or other metallic objects. It can generate heat if the positive and negative terminals of the battery are accidentally come into contact with metallic objects. - When you are not going to use the unit for a long time, remove the battery to avoid damage from battery leakage and corrosion.

To attach the battery compartment lid if it is accidentally detached (See Fig. A–b)

The battery compartment lid is designed to come off when opened with excessive force. To put it back on, see the illustration.

1 Insert one side of the lid as illustrated. 2 Push the other side to attach.

Insert the ⊖ side of the battery first.

Size AAA (R03) x 1

SONY®

Tape Cassette Player/Recorder/CD Player/Mini Disc DAT/Radio/Head Phone/Speaker/MIC/Personals

Portable Audio

LIMITED WARRANTY

Sony Electronics Inc. ("Sony") warrants this Product (including any accessories) against defects in material or workmanship as follows:

1. For a period of one (1) year from the date of purchase if this Product is determined to be defective, Sony will repair or replace the Product, at its option, at no charge the defective unit. After this one (1) year period, you must pay for the replacement unit. This warranty does not cover costs incurred in connection with the removal and re-installation of radios, speakers or accessories, nor does it cover any other contingent expenses.

2. To obtain warranty service, you must take the Product, or deliver the Product freight prepaid, in either its original packaging or packaging affording an equal degree of protection, to any Factory Sony Service facility or to the Laredo Fulfillment Center. See below for additional information.

This warranty does not cover customer instruction, installation, set up adjustments or signal reception problems.

This warranty does not cover cosmetic damage or damage due to acts of God, accident, misuse, abuse, negligence, commercial use, or modification of, or to any part of the Product, including the antenna. This warranty does not cover damage due to improper operation or maintenance, connection to improper voltage supply, or attempted repair by anyone other than a facility authorized by Sony to service the Product. This warranty does not cover Products sold AS IS or WITH ALL FAULTS, or consumables (such as fuses or batteries). This warranty is valid only in the United States.

Proof of purchase in the form of a bill of sale or receipted invoice which is evidence that the unit is within the Warranty period must be presented to obtain warranty service.

This warranty is invalid if the factory applied serial number has been altered or removed from the Product.

REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS THE EXCLUSIVE REMEDY OF THE CONSUMER, SONY SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES FOR BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON THIS PRODUCT. EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ON THIS PRODUCT IS LIMITED IN DURATION TO THE DURATION OF THIS WARRANTY.

Some states do not allow the exclusion or limitation of incidental or consequential damages, or allow limitations on how long an implied warranty lasts, so the above limitations or exclusions may not apply to you. In addition, if you enter into a service contract with the Sony Partnership within 90 days of the date of sale, the limitation on how long an implied warranty lasts does not apply to you. This warranty gives you specific legal rights, and you may have other rights which vary from state to state.

The Address of the Laredo Fulfillment Center is:

Laredo Fulfillment Center 10227 Crossroads Loop Suite B Laredo, TX 78045

For your convenience, Sony Electronics Inc. has established telephone numbers for frequently asked questions: To locate the servicer or dealer nearest you, or for service assistance or resolution of a service problem, or for product information or operation, call:

Sony Customer Information Service Center 1-(800)-222-7669 Or visit the Sony Web Site: www.sony.com

For an accessory or part not available from your authorized dealer, call: 1-(800)-488-SONY (7669)

D 455714603

B

C

Preventing Accidental Change

— HOLD Function

Slide HOLD in the direction of the arrow

"0—n" is displayed, indicating that all the function buttons are locked.

To cancel HOLD, slide HOLD in the opposite direction of the arrow so that "o—" disappears.

Setting the Clock

The display will flash "AM 12:00" when the battery is first inserted.

1 Hold down CLOCK for more than 2 seconds.

The beep sounds and the hour flashes in the display

2 Press TUNE/TIME SET + or – until the correct hour appears in the display.

Each press changes the digit(s) by one.

When you keep the button pressed, the digit(s) change rapidly.

The beep sounds and the minute starts to flash. Repeat step 2 to set the minute. After setting the minute, press CLOCK again. The two beeps sound and the clock starts from 0 seconds.

12-hour system: "AM 12:00" = midnight

"PM 12:00" = noon

Changing AM Channel Step

The AM channel step differs depending on areas. The channel step of this unit is factory-set to 10kHz . Change the settings as shown below to be able to listen to the radio.

Area Channel step

North and South American countries 10kHz

Other countries 9kHz

Note When the AM channel step is changed, the preset stations for AM will be initialized.

1 Press POWER to turn off the power.

2 While holding down CLOCK, keep pressing POWER for more than 5 seconds.

Two short beeps sound, and the AM channel step will be changed.

- "AM 9" (or "AM 10") is displayed for about 2 seconds.

If you proceed to step 2 again, the channel step changes again.

Improving the Reception

TV/WEATHER/FM

Extend the headphones cord which functions as the TV/

WEATHER/FM antenna (See Fig. B-①)

AM. Rotate the unit horizontally for optimum reception. A ferrite bar antenna is built in the unit.

(See Fig. B-①).

Set TV/WB/FM SENS to LOCAL if interference is

prevalent and reception is too strong. Under

normal conditions, set it to DX

Playing the Radio

— Manual Tuning

1 Connect the headphones to the Ⓞ (headphones) jack.

2 Press POWER to turn on the radio.

3 Press BAND to select the band

Each press changes the band as follows:

→AM FM1 FM2→

→TV

nge the band to WEATHER, press WB. You can return to the

ous frequency by pressing BAND.

nd FM2 are differentiated only for Preset tuning. For Manual

g of FM stations, select either band.

and memorizes the frequency you had tuned previously.

4 Press TUNE/TIME SET + or - to tune in to the desired station. Two short beeps sound when the minimum frequency of each band is received during tuning.

5 Adjust the volume using VOL

To turn off the radio, press POWER.

Presetting Your Favorite Station

— Preset Tuning

You can preset up to 10 stations in FM (5 stations in FM1, 5 stations in FM2), and 5 stations in each AM, TV, WEATHER.

Presetting a station

1 Follow steps 1 to 4 in "Playing the Radio" and manually tune in to the station you wish to preset.

2 Press the preset tuning 1 to 5 button you wish to preset for more than a few seconds.

You will hear two confirmation beeps and preset number appears in

the display.

To preset another station, repeat these steps.

To change the preset station, tune in to the desired station and hold

down the preset tuning 1 to 5 button. The new station will replace the previous station on the preset button.

Example: Display window when you preset FM 90.0 MHz in the preset tuning 2 button for FM2.

Tuning in a Preset Station

1 Press POWER

2 Press BAND or WB to select the band.

3 Press the desired preset tuning button.

4 Adjust the volume using VOL.

Note

Holding down the desired preset tuning button for more than a few seconds will replace the previous station on the preset tuning button with the station you tuned in to.

Using the Belt Clip (See Fig. C)

Use the belt clip when attaching the unit to your belt.

To detach the belt clip, see fig. C-①.

To attach the belt clip, see fig. C-①
