Product Type	PTC Ceramic Fan Heater
Brand	N'oveen
Model	PTC09
Heating Technology	PTC (Positive Temperature Coefficient) Ceramic
Power Source	AC 120V ~ 60Hz
Power Consumption	1500W (Max)
Heat Output	5120 BTU/h
Heating Modes	Low (750W), High (1500W), Fan Only
Thermostat	Adjustable, 50°F – 90°F (10°C – 32°C)
Oscillation	Yes, 70° wide angle
Timer	0.5 – 12 hours
Dimensions (W x D x H)	7.5 x 6.3 x 10.2 inches (19 x 16 x 26 cm)
Weight	3.5 lbs (1.6 kg)
Noise Level	< 45 dB (quiet operation)
Safety Features	Overheat protection, tip-over auto shut-off, cool-touch housing, ETL certified
Remote Control	Yes (included)
Display	LED with temperature and timer readout
Color	Black / White (depending on variant)
Cord Length	5.9 ft (1.8 m)
Maintenance	Clean air intake grille with soft brush or vacuum; no user-serviceable parts
Warranty	1 year limited

Frequently Asked Questions - PTC09 N'oveen

How do I clean the N'oveen PTC09 heater?

Turn off and unplug the heater. Use a soft brush or vacuum to clean the air intake and outlet grilles. Do not use water or solvents. Wipe the exterior with a dry cloth.

What does the tip-over safety feature do?

If the heater accidentally tips over, an internal switch automatically cuts off power to prevent fire hazards. The heater must be placed upright to resume operation.

Can I leave the heater on overnight?

While the PTC09 has safety features like overheat protection and tip-over shut-off, it is not recommended to leave it unattended for extended periods. Use the timer to set an automatic shut-off.

How do I set the timer on the N'oveen PTC09?

Press the Timer button repeatedly to cycle from 0.5 to 12 hours in 0.5-hour increments. The display will show the remaining time. The heater will automatically turn off after the set time.

What is the difference between Low and High heat settings?

The Low setting uses 750W and is suitable for maintaining warmth in a small room. The High setting uses 1500W for faster, more powerful heating. Use the Fan Only mode for air circulation without heat.

Does the heater come with a remote control?

Yes, the N'oveen PTC09 includes a remote control that allows you to adjust temperature, fan speed, oscillation, and timer from a distance.

Is the heater safe for use in bathrooms?

The PTC09 is not designed for damp or wet locations. It should be used in dry indoor areas only. Keep it at least 3 feet away from water to avoid electric shock.

How does the oscillation work?

Press the Oscillation button on the unit or remote to activate side-to-side movement. The heater will rotate up to 70 degrees, distributing heat more evenly across the room.

What should I do if the heater stops working suddenly?

Check if the unit has tipped over (tip-over switch activates), if the thermostat has reached the set temperature (it will cycle on/off), or if the overheat protection has triggered. If the problem persists, contact N'oveen support.

Can I use an extension cord with the PTC09?

It is not recommended. Plug the heater directly into a wall outlet. Using an extension cord may cause overheating or fire. If absolutely necessary, use a heavy-duty cord rated for at least 15 amps.

USER MANUAL PTC09 N'oveen

TERMOWENTYLATOR CERAMICZNY

Exterior view of a modern electric power grid fan with a handle and control panel (no visible text or symbols on the device body)

Model: N'OVEEN PTC-09

INSTRUKCJA OBSŁUGI

PLEASE READ CAREFULLY – ALWAYS MAINTAIN SAFETY WHEN WORKING WITH ANY APPLIANCE FOR YOUR OWN SAFETY

1. Read all instructions before using the fan heater.
2. Only connect the fan heater to a single-phase socket with a main voltage as specified on the rating plate.
3. This appliance meets the electromagnetic compatibility requirements specified in BN 55104/95 with regard to interference with radio and TV sets.
4. Do not leave your home while the appliance is in function: ensure that the switch is in OFF position.
5. Keep combustible material such as furniture, cushions, bedding, paper, clothes, curtains etc. at least 50cm away from the fan heater.
6. If wall mounted do not fix to combustible material such as wooden, synthetic or plastic surfaces. Do not hang anything on or in front of the fan heater.
7. Always unplug the heater when not in use. Dot not pull the cord to unplug the heater.

8. Keep the air inlet and outlet free from objects: at least 1 m in front and 50 cm behind the heater.

9. The heater must not be located immediately below a socket outlet.

10. Do not let animals or children touch or play with the fan heater. Pay attention! The air outlet gets hot during operation (more than 80, or 175 F).°C

11. WARNING: In order to avoid overheating, do not cover the heater.

12. Do not use this fan heater in the immediate surroundings of a bath, a shower or a swimming pool.

13. Do not use the fan heater in the rooms with explosive gas or while using inflammable solvents, varnish or glue.

14. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.

15. Keep the fan heater clean. Do not allow any objects to enter any ventilation or exhaust opening as this may cause electric shock, or fire or damage to the heater.

16. WARNING: This heater is not equipped with a device to control the room temperature. Do not use this heater in small rooms when they are occupied by persons not capable of leaving

the room on their own, unless constant supervision is provided.

1. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.

2. Children of less than 3 years should be kept away unless continuously supervised.

3. Children aged from 3 years and less than 8 years shall only switch on/off the appliance provided that it has been placed or installed in its intended normal operating position and they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children aged from 3 years and less than 8 years shall not plug in, regulate and clean the appliance or perform user maintenance.

4. CAUTION — Some parts of this product can become very hot and cause burns. Particular attention has to be given where children and vulnerable people are present.

WARNINGS

• Do not use the appliance in the vicinity of showers, bath tubs, wash basins, swimming pools, etc.
• Always use the heater in an upright position.
• Do not use the heater to dry your laundry. Never obstruct the intake and outlet grilles (danger of overheating).
• The heater must be positioned at least 50cm from furniture or other objects.
• Do not place the appliance up against walls, furniture, curtains, etc.
• The appliance must be installed so that the switches and other controls can not be reached by persons using the bath tub or the shower.
• This appliance comes with a Y-type connection. Replacement of the feed cable must be entrusted to a technician only, because such work requires special tools.
• The appliance must not be positioned directly underneath a fixed power point.
• Do not use the appliance while it is cooling down, in order to avoid overheating with the attendant risk of fire.
• Do not use the appliance in rooms less than 4m2 area.

The heater is fitted with a safety device which will switch off the heater in case of accidental overheating (eg. Obstruction of air intake and outlet grilles, motor turning slowly or not at all).

To reset, disconnect the plug from the power for a few minutes, remove the cause of overheating then plug the appliance in again

• Remove the heater from all packaging and place it in desired location.
• Ensure that there is a safe area between the heater and furniture,curtains,etc-50cm safe area form top and sides and 120cm safe area in front.
  ·Unwind the Power Cord and plug it into the Power Outlet.

To activate the heater, turn the knob clock-wise to the 'position for cool air. Turn knob to 'I' for low power, 'II' for maximum power.

AUTO SATETY SHUT OFF

The heater has a built-in safety device, which will switch the heater OFF in case of accidental overheating. To reset the heater, follow the next steps:

·Turn the control setting to the 'O' position.
·Unplug the heater and wait 5-10 minutes for the unit to cool down.
·After the unit has cooled, plug it in and operate normally.
·Turn selector switch into desired position(Fan, Low or High).
·Turn the thermostat switch to the desired temperature positon.
- When you feel the room temperature comfortable, turn the thermostat switch anti-clockwise slowly to the minimal direction until the appliance switches off.
·The thermostat switch will keep the room temperature at the desired temperaturea automatically.
- You can also turn the thermostat switch anti-clockwise to the minimum position or turn the thermostat switch clockwise to the maximum position to make the temperature lower or higher.

CLEANING AND MAINTENANCE

• Be sure to switch off power supply and pull out the plug before cleaning.
  ·Wait for the heater to cool down sufficiently.
  ·Clean the body of the heater with a damp cloth. DO NOT ALLOW water into the appliance.
  ·DO NOT use soap or chemicals which may damage the housing of the heater.
• Allow sufficient drying time before operating again.
  ·Clean the air inlets and outlets regularly with a vacuum cleaner(with a regular use, at least twice a year).
• When the unit is not in use. we recommend that the heater is re-packed in its original packaging and stored in a cool, dry place.
