| Product Type | Server Motherboard |
| Brand | Supermicro |
| Model | H13SVW-NT |
| Form Factor | Standard ATX |
| CPU Socket | LGA 4677 (Intel Xeon W-3400/W-2400) |
| Memory Support | 8x DDR5 DIMM slots, up to 2TB ECC RDIMM/3DS RDIMM |
| Expansion Slots | 7x PCIe 5.0 x16 slots |
| Storage | 2x M.2 NVMe, 8x SATA3 via Intel PCH |
| Network | Dual 10GbE (Intel X710-TM4) |
| Dimensions (W x D) | 12 x 10.5 inches (305 x 267 mm) |
| Weight | Approx. 2.2 kg (4.85 lbs) |
| Power Supply | ATX 24-pin + 8-pin CPU, supports PMBus |
| Power Consumption | Typical 150-300W (depending on CPU and load) |
| Main Functions | High-performance workstation/server motherboard with Intel W790 chipset, supports PCIe 5.0, DDR5 ECC, dual 10GbE, IPMI 2.0 |
| Maintenance | BIOS update via USB, CMOS reset jumper, diagnostic LEDs |
| Cleaning | Use compressed air for dust; avoid liquids |
| Safety | Operate in well-ventilated area, use ESD wrist strap when handling, disconnect power before servicing |
| Spare Parts & Repairability | Replaceable CMOS battery, CPU socket cover, I/O shield. Contact Supermicro for replacement parts. |
| General Information | Supports Windows Server, Linux, VMware. Operating temperature: 10°C to 35°C. Storage: -40°C to 70°C. |
Frequently Asked Questions - H13SVW-NT Supermicro
What type of CPU does the H13SVW-NT support?
How many memory slots does the H13SVW-NT have?
What is the form factor of this motherboard?
Does the H13SVW-NT support PCIe 5.0?
What network interfaces are included?
How many storage ports are available?
Is IPMI supported for remote management?
What power connectors does the H13SVW-NT require?
Can I use non-ECC memory on this motherboard?
Where can I find the latest BIOS and drivers?
